Proxicast ANT-120-006 Manual

ANT-120-006
5-8 dBi Omni-Directional 3G/4G/LTE Aerial Antenna
Applications
• Direct Replacement for Low Gain Antennas
included with many Cellular Products
• 3G/4G/LTE Routers & Modems
• Cellular Amplifiers
• Optional Magnetic Base
Product Features
• Compatible with most Cellular Modems/Routers
• Compatible with all 3G/4G/LTE Networks
• 5 – 8 dBi Peak Gain
• Omni-Directional
• Integrated SMA Male Connector
• Swivels 90° & Rotates 360°
• No Ground Plane Required
General Description
The Proxicast 3G/4G Aerial is a mid/high-gain 3G/4G omni-directional antenna. The "rubber-duck" style aerial is
an 11 in. (280 mm) dipole antenna that provides 5 to 8 dBi of gain for use on all 2G, 3G and 4G/LTE/xLTE/AWS
frequency bands (698~960, 1710~2170, and 2500~2700 MHz) used by U.S. and Canadian cellular carriers
such as Verizon Wireless, AT&T Wireless, T-Mobile, Rogers, Bell Mobility and Telus as well as most other
cellular operators worldwide.
The polycarbonate antenna swivels 90 degrees and rotates 360 degrees for optimal positioning and maximum
signal reception and has an integrated SMA male plug connector and ground-plane. This antenna is a smart
choice for mobile or stationary applications where extra gain is required.
Compatible with all SMA-based equipment including modems and routers from Cisco, Cradlepoint, Digi,
Pepwave, Proxicast, Sierra Wireless, Sixnet/Red Lion and many others.
Optional magnetic bases make this a stand-alone antenna and provide compatibility with a wide variety of
modems, hotspots, and other cellular equipment.
For MIMO applications use 2 identical antennas.
Data Sheet: Rev C 05/28/19
© Copyright Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-120-006
ANT-120-006-SMA
ANT-120-006-TS9
ANT-120-006-295
- 1 of 8 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
5-8 dBi Omni-Directional
3G/4G/LTE Aerial Antenna
1 Antenna + 1 Magnetic Base +
10ft Coax w/ SMA Male Connector
(ANT-120-MB3)
1 Antenna + 1 Magnetic Base +
10ft Coax w/ TS9 Male Connector
(ANT-120-MB9)
1 Antenna + 1 Magnetic Base +
10ft Coax w/ UML290/295 Male
Connector (ANT-104-290)
