ANT-121-002 (-004)
Vandal Resistant 4G/5G Omni-Directional Antenna
Applications
• Kiosks
• Vending Machines
• Digital Signage
• Video Surveillance
• Point-of-Sale Terminals
•
SCADA / Telemetry / PLCs
Product Features
• Vandal Resistant
• Low Profile ~ 3 inches Tall
• Weatherproof
• Compatible with all 4G, 5G, FirstNet Networks
• Compatible with most Cellular Modems/Routers
• 3 – 6 dBi Peak Gain
• Omni-Directional
• SMA Male Connector on Low-Loss Coax
General Description
This low profile (~3 inches tall) fixed mount omni-directional antenna is a solution for today's state-of-the-art
multi-antenna wireless systems (5G & 4G/LTE). It offers 3 to 6 dBi of gain and support for all 4G/5G cellular
frequency bands on AT&T, Verizon, T-Mobile, Bell, Rogers, Telus and other carriers worldwide.
Ideal for use in vending machines, meter housings, equipment sheds, NEMA enclosures or other locations
requiring a low-profile vandal resistant external antenna. Also suitable for vehicle mounting on buses, vans,
trucks or other mobile installations.
Permanently mounts via a 1/2 in. (13 mm) hole. Resists vandalism with no exposed coax cable, high impact
ABS radome shell and a thick threaded mounting post. Includes low-loss LMR 195 coax fed through the center
mounting post. Includes an "L" bracket for optional wall mounting. Completely waterproof (IP67).
Integrated SMA male plug connectors mate with SMA female jacks found on most cellular modems and routers.
The 2 lead version of this antenna is part # ANT-121-M22 and the 4x4 MIMO version is ANT-121-M44
For optimum performance this antenna should be mounted on a flat, horizontal metal surface at least 8 inches in
diameter.
Data Sheet: Rev E 10/01/23
© Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-121-002
ANT-121-004
- 1 of 12 Disclaimer: Subject to change without notice
-
www.proxicast.com
Description
Vandal Resistant Low Profile
4G/5G Omni-Directional Screw
Mount Antenna - 10 ft Coax
Lead
Vandal Resistant Low Profile
4G/5G Omni-Directional Screw
Mount Antenna – 18 in Coax
Lead
