ANT-120-007
5 dBi Omni-Directional 3G/4G/LTE Paddle Antenna
Applications
• Direct Replacement for Low Gain Antennas
included with many Cellular Products
• 3G/4G/LTE Routers & Modems
• Cellular Amplifiers
• Optional Magnetic Base
Product Features
• Compatible with most Cellular Modems/Routers
• Compatible with all 3G/4G/LTE Networks
• 3 – 5 dBi Peak Gain
• Omni-Directional
• Integrated SMA Male Connector
• Swivels 90° & Rotates 360°
• No Ground Plane Required
General Description
The Proxicast Flat Swivel Paddle Antenna is a high-efficiency mid-gain 3G/4G/GPS omni-directional antenna.
The "rubber-duck" style antenna is an 7.7 inch (196 mm) omni-directional antenna that provides up to 5 dBi of
gain and supports all 2G, 3G and 4G/LTE/xLTE/AWS frequency bands (698-2700 MHz) used by U.S. and
Canadian cellular carriers such as Verizon Wireless, AT&T Wireless, T-Mobile, Rogers, Bell Mobility and Telus
as well as most other cellular operators worldwide.
This antenna also covers the GPS frequency (1575 MHz) and can be used as a passive GPS antenna or as a
multiplexed cellular + GPS antenna.
The polycarbonate antenna swivels 90 degrees and rotates 360 degrees for optimal positioning and maximum
signal reception and has an integrated SMA male plug connector and ground-plane. This antenna is a smart
choice for mobile or stationary applications where extra gain is required.
Compatible with all SMA-based equipment including modems and routers from Cisco, Cradlepoint, Digi,
Pepwave, Proxicast, Sierra Wireless, Sixnet/Red Lion and many others.
For MIMO applications use 2 identical antennas.
Compatible with Proxicast's 3-inch SMA Magnetic Antenna Base (ANT-120-MB3).
Data Sheet: Rev C 09/23/19
© Copyright Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-120-007
ANT-120-007-2PK
ANT-120-007-MAG
- 1 of 8 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
Universal Wide-Band 5 dBi
Omni-Directional 3G/4G/LTE
Paddle Swivel Antenna
2 Pack of Identical Antennas
1 Antenna + 1 Magnetic Base
+ 10 ft Coax w/ SMA Male
Connector (ANT-120-MB3)
