ANT-520-421
4G/5G + Wi-Fi + GPS 7-in-1 MIMO Antenna (Top Hat)
Applications
•
Buses, Vans, Trucks
•
Police / Fire / Ambulance Vehicles
•
Boats
•
Kiosks
Product Features
• Combines 4x Ultra-Wideband Flex elements
+ 2x Wi-Fi + 1x GPS antennas into a single
streamlined enclosure
• Low Profile: 2.7 inches tall
• Up to 4x4 MIMO on 5G and 6x6 MIMO on WiFi
• Weatherproof & Impact Resistant
• Compatible with most Cellular/Wi-Fi/GPS Devices
• Omni-Directional 7 dBi Peak Gain
• 15 ft Low-Loss Coax Leads
General Description
This 7-in-1 low-profile, heavy-duty, multi-element combo antenna cost-effectively combines high efficiency and
peak gain in a compact easy to install form factor. Suitable for fleet management, mobile video, remote
monitoring and recreational vehicle applications.
Featuring 1 GPS element, 2 dedicated 2 Tri-Band WiFi elements & 4 ultra-wideband flex elements for WiFi or
Cellular, this antenna is ideally suited for 2x2, 4x4 and 6x6 MIMO vehicular modems and routers.
The 4 ultra-wideband elements can be used for any radio system between 600 and 6000 MHz including all
4G/5G bands used by commercial and public safety operators worldwide (600 – 6000 MHz). Four SMA-to-
RPSMA adapters are included to allow the flex elements to also be used for 3x3 to 6x6 WiFi configurations.
All WiFi generations through WiFi-7 and 4.9 GHz public safety bands are supported. FirstNet, LTE Unlicensed
(LTE/U), Licensed-Assisted Access (LAA), Multefire and OnGo (CBRS) Radio Systems are also supported.
The active L1 band GPS element has a 28 dB low noise amplifier (LNA).
The antenna has its own ground-plane and can radiate on any mounting surface such as metal, plastic or
fiberglass without affecting performance.
Each antenna element includes a 15 ft (4.5m) low-loss pre-terminated coax cable.
Installation requires only a 1.5 in diameter hole. The included rubber gasket and mounting nut seal the opening
from water and dust making in IP67 compliant.
Data Sheet: Rev B 09/06/23
