Proxicast ANT-131-002 Manual

ANT-131-002
Vandal Resistant Tri-Band WiFi Omni Antenna
Applications
• Kiosks
• Vending Machines
• Digital Signage
• Video Surveillance
• Point-of-Sale Terminals
•
SCADA / Telemetry / PLCs
Product Features
• Vandal Resistant
• Low Profile ~ 3 inches Tall
• Weatherproof
• Compatible with all WiFi standards
( a/b/g/n/ac/ax/bne)
• Compatible with most WiFi Access Points/Routers
• 3 – 5 dBi Peak Gain
• Omni-Directional
• RP-SMA Male Connector on 10 ft Low-Loss Coax
General Description
This low profile (~ 3 inches tall) fixed screw mount omni-directional antenna provides 3 to 5 dBi of gain and
works on all 2.4, 5.8 and 6-7 GHz WiFi frequency bands worldwide.
Ideal for use in vending machines, meter housings, equipment sheds, NEMA enclosures or other locations
requiring a low-profile vandal resistant external antenna. Also suitable for vehicle mounting on buses, vans,
trucks or other mobile installations.
Permanently mounts via a 5/8 in. (16 mm) hole with locking internal nut. Resists vandalism with no exposed
coax cable, high impact ABS radome shell and an extra thick threaded mounting post. Includes 10 ft of low-loss
RG58U coax fed through center mounting post. Includes "L" bracket for optional wall mounting.
Integrated RP-SMA male plug connector mates with RP-SMA female jack found on most WiFi access points
and routers.
Completely waterproof (IP67) when properly installed with post extending into a water-tight enclosure. Not
waterproof when used exclusively with wall bracket.
For optimum performance this antenna should be mounted on a flat, horizontal metal surface at least 8 inches in
diameter.
Data Sheet: Rev C 02/08/24
© Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-131-002
- 1 of 6 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
Vandal Resistant Low Profile
Triple Band WiFi Omni-
Directional Antenna - 3-5 dBi
Gain - Fixed Mount - 10 ft
Coax Lead
