ANT-130-005
Ultra Low-Profile 2.4/5.8 Wi-Fi Omni-Directional Antenna
Applications
• Kiosks
• Vending Machines
• Digital Signage
• Point-of-Sale Terminals
• Vehicles
• Video Surveillance
•
Covert Installations
Product Features
• Extremely Low Profile ~ 0.6 in. high x 1.8 in dia.
• Hole / Screw Mounted
• Weatherproof, Compact & Light-weight
• Vandal Resistant – no exposed cable
• RP-SMA Male Connector
• Compatible with 2.4 & 5.8 GHz Wi-Fi Systems
• Compatible with most 802.11 a/b/g/n/ac Access
Points & Routers
General Description
This extremely low profile (< 0.6 inches tall) fixed mount omni-directional antenna provides 2 dBi of gain and
works on all 2.4 & 5.8 GHz Wi-Fi frequency bands worldwide.
Permanently mounts via a 1/2 in. (12 mm) hole with locking internal nut. Resists vandalism with no exposed
coax cable. Includes low-loss coax fed through center mounting post.
Designed for applications requiring an inconspicuous low-profile external antenna such as kiosks, vending
machines, equipment panels, conference rooms, etc. Can also be vehicle mounted for buses, vans, trucks or
other mobile installations.
Integrated Reverse Polarity SMA male plug connector mates with RPSMA female jack on access points,
routers, etc.
For MIMO applications mount 2 or more identical antennas at least 5 inches apart.
This antenna is also available for Cellular frequencies (3G/4G/LTE). See ANT-120-003.
Data Sheet: Rev C 08/10/20
© Copyright Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
ANT-130-005
- 1 of 5 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
Proxicast Ultra Low-Profile
Wi-Fi Omni-Directional
2 dBi Screw Mount Antenna
with 6 ft coax & RP-SMA male
