Proxicast ANT-126-004 Manual

ANT-126-004
8.5 dBi Omni-Directional 4G/5G/WiFi Bullet Antenna
Applications
• 4G/5G Routers, Modems & Hotspots, Amps
• Unlicensed 900 MHz & 2.4/5.8 GHz Wi-Fi
• Signal Challenged Locations Requiring
High Gain Omni-Directional Antennas
• Installations Requiring an Aesthetic Solution
• Outdoor and Marine Installations
• Pole, Rail, Wall & Deck Mount Options
Product Features
• Compatible with all Cellular Modems/Routers
• Compatible with all 4G/LTE, 5G & Wi-Fi Networks
• Integrated N Female Connector
• No Ground Plane Required
• Durable White or Black ABS Radome
• Stainless Steel Mounting Bracket & Hardware
• Only 8.7 inches Tall (excluding mount)
General Description
Proxicast's small, light-weight, easy-to-install permanent mount omni-directional antenna improves transmit and
receive signals for all 4G/LTE and sub-6 GHz 5G frequencies on Verizon, AT&T, T-Mobile, US Cellular, Bell
Mobility, Rogers, Telus, Sasktel, Telcel, Movistar, Digicel and many other cellular operators worldwide.
The highly efficient omni-directional radiator design provides high gain without the cellular tower location and
alignment hassles of directional antennas. It can also be used as an antenna for 900 MHz and 2.4/5.8 GHz
unlicensed radio systems such as Wi-Fi.
Its compact size and white or black finish and the included all stainless-steel mounting bracket and U-bolts,
nickel-plated N connector and ABS radome resist corrosion making this antenna perfect for outdoor or marine
applications. Pole/Wall and Standard 1"-14 Marine Mount options are possible with optional mounting hardware.
With the appropriate adapter cable (not included), this antenna is compatible with 4G/5G cellular modems,
routers, gateways, hotspots and signal amplifiers from companies such as CalAmp, Cisco, Cradlepoint, Digi,
MoFi, Netgear, Inseego, Pepwave, Proxicast, Sierra Wireles and ZTE.
For MIMO applications use 2 identical antennas spaced approximately 2 ft apart horizontally. Proxicast's
XBOOM Cross-Over Bracket (ANT-800-XB1) makes it easy to mount 2 antennas on a single vertical mast.
Data Sheet: Rev C 11/02/22
© Copyright Proxicast, LLC. All rights reserved.
Ordering Information
Part No.
Proxicast 8.5 dBi Omni-Directional 4G/5G/WiFi
Outdoor Bullet Shaped Antenna
ANT-126-004-WM
ANT-126-004-BM
- 1 of 11 - Disclaimer: Subject to change without notice
www.proxicast.com
Description
Stainless Deck Mount - White
Stainless Deck Mount - Black
• 1-877-777-7694
