Speakman Commander SC-4074-LD Instructions

INSTRUCTIONS FOR MODELS
SC-4074-LD
SC-4074-E-LD
For additional assistance or service please contact:
SPEAKMAN
®
Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerservice@speakman.com
www.speakman.com
92-SC-4074-LD-05
TOOLS AND SUPPLIES
Adjustable Slip Joint Thread Seal Phillips
Wrench Wrench Tape Screwdriver
HELPFUL TOOLS & SUPPLIES:
Supply Basin Pipe Hacksaw
Hoses Wrench Wrench
Tubing Utility Safety
Cutter Knife Glasses
SAFETY TIPS
Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.
MAINTENANCE
Your new Lavatory Faucet is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid
abrasive cleaners, steel wool, and harsh chemicals
as these will dull the finish and void your warranty.
WARRANTY
Additional warranty information can be found at:
www.speakman.com
IMPORTANT
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur. This faucet has
an operating range of 20-80 psi.
OUTLET FLOW RATE
1.5 gpm aerator (SC-4074-LD Faucet).
0.5 gpm spray outlet (SC-4074-E-LD Faucet).
1
Shut off water supplies. Remove old faucet. Place
faucet through mounting holes in sink. Secure
faucet to sink using mounting nuts (1) provided.
2
Make connections to water lines. Use 1/2" IPS
faucet connections (1) or use the coupling
nuts (3) with 3/8" O.D. ball-nose risers (2).
Use wrenches to tighten connections. Do not
overtighten.
3
IMPORTANT: After installation is completed,
remove aerator. Turn on water supply and allow
both hot and cold water to run for at least one
minute each. While water is running, check
for leaks. Replace aerator or install 0.5gpm
spray outlet.
