Installation, Operation & Maintenance Instructions
DESCRIPTION
Speakman Neo™ Collection Combination Series, SLV-1450-ADA includes: Trim with integral Diverter Handle
(CPT-1401), Low Flow Multi Function Hand Shower (VS-3010-E2), ADA Pause Switch (VS-156), Supply Ell
(VS-155), Slide Bar (SA-1002), and Diverter Tub Spout (S-1557). This combination does not include the
Shower Valve.
This combination should be installed with one of the following
Speakman Sentinel Mark II® Pressure Balance Diverter Shower Valves
CPV-PB-DV:
CPV-PB-DV-PXC: Thermostatic Diverter Shower Valve
CPV-PB-DV-PXE: Thermostatic Diverter Shower Valve
This combination should be installed with one of the following
Speakman Sentinel Mark II® Thermostatic Diverter Shower Valves
CPV-T-DV:
CPV-T-DV-PXC: Thermostatic Diverter Shower Valve
CPV-T-DV-PXE: Thermostatic Diverter Shower Valve
SPECIFICATIONS
CPT-1401 SENTINEL MARK II® DIVERTER SHOWER VALVE TRIM:
COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard
VS-3010-E2 LOW FLOW MULTI FUNCTION HAND SHOWER:
CONNECTIONS: ½" NPS Male Inlet
FLOW RATE: 2.0 gpm (7.6 L/min)
COMPLIANCE: ASME A112.18.1/CSA B125.1 Standard & WaterSense Certified
VS-156 ADA PAUSE SWITCH:
CONNECTIONS: ½" NPS Male Inlet, ½" NPS Female Outlet
COMPLIANCE: ASME A112.18.1/CSA B125.1
VS-155 SUPPLY ELL:
CONNECTIONS: ½" NPT Female Inlet, ½" NPS Male Outlet
SPEAKMAN
SLV-1450-ADA
NEO™ COLLECTION COMBINATION SERIES
Thermostatic Diverter Shower Valve
Sweat & Thread Connections
PEX F1807 Crimp Inlet Connections
PEX F1960 Cold-Expansion Inlet Connections
Thermostatic Diverter Shower Valve
Sweat & Thread Connections
PEX F1807 Crimp Inlet Connections
PEX F1960 Cold-Expansion Inlet Connections
SPEAKMAN
Phone: 800-537-2107
12/10/18
www.speakman.com
®
®
Fax: 800-977-2747
92C-SLV-1450-ADA-01
Advertisement
Table of Contents
Related Manuals for Speakman NEO COMBINATION Series
Summary of Contents for Speakman NEO COMBINATION Series
- Page 1 NEO™ COLLECTION COMBINATION SERIES DESCRIPTION Speakman Neo™ Collection Combination Series, SLV-1450-ADA includes: Trim with integral Diverter Handle (CPT-1401), Low Flow Multi Function Hand Shower (VS-3010-E2), ADA Pause Switch (VS-156), Supply Ell (VS-155), Slide Bar (SA-1002), and Diverter Tub Spout (S-1557). This combination does not include the Shower Valve.
- Page 2 SA-1002 SLIDE BAR S-1557 DIVERTER TUB SPOUT: CONNECTIONS: ½” Copper Slip-fit COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard INSTRUCTIONS See individual products for installation of the components and warranty information. SPEAKMAN ® Phone: 800-537-2107 Fax: 800-977-2747 12/10/18 www.speakman.com 92C-SLV-1450-ADA-01...
- Page 3 ROUGH-IN SPEAKMAN ® Phone: 800-537-2107 Fax: 800-977-2747 12/10/18 www.speakman.com 92C-SLV-1450-ADA-01...
-
Page 4: Maintenance
FOR DEEP MOUNT APPLICATION MAINTENANCE For additional assistance or service please contact: Your new Speakman Product is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically with a soft cloth. The use of harsh SPEAKMAN ®... - Page 5 SPEAKMAN CPT-1401 REPAIR PARTS ® ITEM NO. PART NO. DESCRIPTION RPG05-0874 SCREWS AND SPLINE ADAPTERS SPEAKMAN CPT-1401 ROUGH-IN DIAGRAM ® 1" 25mm 1/2" SWEAT HOLE FOR 6'-6" [2 METERS] CONNECTION SHOWER ARM TO FLOOR " " 66.27mm 140mm " HOLE FOR 2.0in...
-
Page 6: Tools And Supplies
To reduce mineral build-up, turn the handle to FLOOD For additional assistance or service please contact: WATER WILL NOT FLOW position to let the water drain out after every use. THROUGH THE HOSE IF SPEAKMAN THE WRONG SIDE IS ® Company CONNECTED. -
Page 7: Rough-In Dimensions
ROUGH IN DIMENSIONS REPAIR PARTS 1/2"-14 NPSM FEMALE THREADED INLET MARKED 4” 2-1/4” "ATTACH THIS CHECK 102mm VALVE END TO THE 58mm WATER SUPPLY" 61" 165mm 9-1/2” 240mm VS-130-XX BRACKET ASSEMBLY * XX = FINISH 1/2"-14 NPSM FEMALE 1/2-14 NPSM THREADED OUTLET THREADED INLET... - Page 8 THREAD TOOLS AND SUPPLIES .96” MAINTENANCE (24.4mm) 1.36” Your new Speakman Product is designed for years Thread Seal (34.5mm) of trouble-free performance. Keep it looking new by Tape cleaning it periodically with a soft cloth. The use of harsh chemicals and abrasives on any of the Speakman custom finish products may damage the 1/2”...
- Page 9 92-VS- 1 55-R1...
- Page 10 1/4” the wall. MAINTENANCE Your new Speakman Product is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically with a soft cloth. The use of harsh chemicals and abrasives on any of the Speakman custom finish products may damage the finish and void the product warranty.
- Page 11 SPEAKMAN SPEAKMAN SA-1002 REPAIR PARTS ® SA-1002 ROUGH-IN DIAGRAM ® " 2 11 60mm " 69mm 1 15 " 50mm 23 5 25 3 " " 600mm 654mm " 118mm " 20mm ITEM NO. PART NO. DESCRIPTION DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
-
Page 12: Rough-In Diagram
Cover your drain to prevent loss of parts. Be sure to wear eye protection while cutting pipe. For additional assistance or service please contact: MAINTENANCE SPEAKMAN Your new Speakman product is designed for years ® Company of trouble-free performance. Keep it looking new by 400 Anchor Mill Road cleaning it periodically with a soft cloth.
