Installation, Operation & Maintenance Instructions
DESCRIPTION
Speakman SentinelPro™ Combination, SLV-5090-ADA includes: Trim (CPT-5001), Shower Arm with Wall
Flange (S-2500), Hand Shower with Flow Control (VS-100-PC), Shower Arm Bracket, 60in Shower Hose
with Built-in Vacuum Breaker, 24in ADA Combination Grab/Slide Bar (VS-153-ADA), and Diverter Tub Spout
(S-1556). This combination does not include the Shower Valve.
This combination should be installed with one of the following
Speakman SentinelPro™ Thermostatic/Pressure Balance Shower Valves
CPV-TP:
CPV-TP-PXC:
CPV-TP-PXE:
SPECIFICATIONS
CPT-5001 T/P VALVE TRIM:
FINISH: Polished Chrome
COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard
S-2500 SHOWER ARM WITH WALL FLANGE:
CONNECTIONS: ½" NPT Male Inlet & Outlet
FINISH: Polished Chrome
VS-1001-ADA-PC HANDICAP SHOWER COMBINATION:
VS-100-PC HAND SHOWER WITH FLOW CONTROL:
CONNECTIONS: ½" NPSM Male Inlet
FLOW RATE: 2.5 gpm (9.5 L/min)
FINISH: Polished Chrome
COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard
SHOWER ARM BRACKET:
CONNECTIONS: ½" NPSM Male Inlet; ½" NPSM Female Outlet
FINISH: Polished Chrome
60in SHOWER HOSE (w/ BUILT-IN VACUUM BREAKER):
CONNECTIONS: ½" NPSM Female Inlet & Outlet
FINISH: Polished Chrome
VS-153-ADA 24in ADA COMBINATION GRAB/SLIDE BAR:
FINISH: Polished Chrome
COMPLIANCE: Meets 250 lbs pull test for Grab Bars per ANSI Standard; Meets requirements of ADA
Lever Handle for adjusting Slide Bar
400 Anchor Mill Rd. New Castle, DE 19720
SPEAKMAN
SLV-5090-ADA
SENTINELPRO™ COMBINATION SERIES
Thermostatic/Pressure Balance Shower Valve
Sweat & Thread Connections
Thermostatic/Pressure Balance Shower Valve
PEX F1807 Crimp Inlet Connections
Thermostatic/Pressure Balance Shower Valve
PEX F1960 Cold-Expansion Inlet Connections
SPEAKMAN
07/31/18
www.speakman.com
®
®
Phone: 800-537-2107
92C-SLV-5090-ADA-01
Fax: 800-977-2747
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Speakman SENTINELPRO COMBINATION SLV-5090-ADA
Summary of Contents for Speakman SENTINELPRO COMBINATION SLV-5090-ADA
- Page 1 SENTINELPRO™ COMBINATION SERIES DESCRIPTION Speakman SentinelPro™ Combination, SLV-5090-ADA includes: Trim (CPT-5001), Shower Arm with Wall Flange (S-2500), Hand Shower with Flow Control (VS-100-PC), Shower Arm Bracket, 60in Shower Hose with Built-in Vacuum Breaker, 24in ADA Combination Grab/Slide Bar (VS-153-ADA), and Diverter Tub Spout (S-1556).
- Page 2 S-1556 DIVERTER TUB SPOUT: CONNECTIONS: ½” Copper Slip-fit FINISH: Polished Chrome INSTRUCTIONS See individual products for installation of the components and warranty information. ROUGH-IN SPEAKMAN ® 400 Anchor Mill Rd. New Castle, DE 19720 Phone: 800-537-2107 Fax: 800-977-2747 07/31/18 www.speakman.com...
-
Page 3: Maintenance
Cover your drain to prevent loss of parts. Be sure to wear eye protection while cutting pipe. MAINTENANCE Your new Speakman Product is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically with a soft cloth. The use of harsh... - Page 4 Temporarily place Handle over splines and adjust the valve to the OFF position (as per the Valve Instructions). Then, align Handle vertically as shown below. Secure Handle to Spindle with the included #8 Screw. SPEAKMAN CPT-5001 / CPT-5401 REPAIR PARTS ® ITEM NO.
- Page 5 SPEAKMAN CPT-5001 ROUGH-IN DIAGRAM ® 1" 25mm HOLE FOR SHOWER ARM 6'-6" [2 METERS] TO FLOOR 7.50in 191mm 5-1/2" (140MM) DIA. 4.31in 1/2" NPT MALE HOLE FOR 110mm 1/2" SWEAT VALVE ACCESS CONNECTION 1/2" NPT MALE 1/2" NPT MALE 1/2" SWEAT 1/2"...
-
Page 6: Rough-In Dimensions
Pipe Fitting within the wall. Firmly tighten, 1/2" NPT THREADS BOTH ENDS and make sure Shower Arm (2) Outlet is For additional assistance or service please contact: pointing in a downward position. 45.00° " SPEAKMAN INLET ® Company 42mm " 21mm 400 Anchor Mill Road New Castle, DE 19720 7"... -
Page 7: Operation
MAINTENANCE The finish of your SPEAKMAN VERSATILE® hand held shower and all the other components can be cleaned by using mild soap and warm water. Dry immediately with a soft, clean cloth for best results. The flow control device limits water flow to 2.5 gallons per minute, and is in the base of the handheld. - Page 8 SPEAKMAN ® 400 Anchor Mill Rd. New Castle, DE 19720 Phone: 800-537-2107 Fax: 800-977-2747 9/08/17 www.speakman.com 92-2681-02...
-
Page 9: Tools And Supplies
½ hour then rinse thoroughly. Brush off any remaining mineral deposits if necessary. DO NOT USE the vinegar/water treatment on any finish other than Chrome. For additional assistance or service please contact: SPEAKMAN ® Company 400 Anchor Mill Road New Castle, DE 19720... - Page 10 ROUGH IN DIMENSIONS 50 RUBBER TIPPED SPRAYS " 79.38 " 215.90 PAUSE BUTTON 1/2-14 NPSM MALE THREADED INLET 1" 25.40mm .714in 18.14mm " ACROSS 10.16mm FLATS FLOW CONTROL INSERTED INTO HANDLE " 30.18 VS-100-PC Max. Flow Rate: 2.5 gpm (9.5L/min) Min.
- Page 11 MAINTENANCE Your new Speakman Product is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically with a soft cloth. The use of harsh chemicals and abrasives on any of the Speakman custom finish products may damage the finish and void the product warranty.
- Page 12 Mounting Bracket. 1/4 turn clockwise to lock into the desired position. LOCK UNLOCK NOTE: Upper mounting hole is intentionally off center to allow for easier installation. SPEAKMAN SPEAKMAN VS-153-ADA ROUGH-IN DIAGRAM ® VS-153-ADA-30 / VS-153-30-RT ROUGH-IN DIAGRAM ® NOTES: NOTES: 1.34in 1.34in...
- Page 13 SPEAKMAN SPEAKMAN VS-153-ADA REPAIR PARTS VS-153-ADA-36 ROUGH-IN DIAGRAM ® ® NOTES: 1.34in 33.91mm COMPLIANCE: ADA COMPLIANT 50.80mm TYP. • Meets the ANSI standard 250 lbs. pull-test for grab bars and ADA lever handle for adjusting slide bar. 2.78in • The VS-153-ADA Slide Bar meets ADA pull force 70.73mm...
- Page 14 1/4”-20 UNC-2A THREAD Slide spout (1) over exposed stub out pipe until flush to wall. Center the spout (1) on the wall and tighten set screw (2) from underneath with Allen wrench. 92-3277-R2...
