SilverStone SFX Series Manual

750w sfx fully modular 80 plus platinum power supply
Hide thumbs Also See for SFX Series:

Advertisement

Table of Contents

SFX Series
SX750
750W SFX fully modular 80 Plus Platinum power supply
Support standard SFX form factor
Silent running 92mm dual ball bearing fan with minimum 18dBA
All Japanese capacitors
High efficiency with 80 PLUS Platinum certification
Class-leading single +12V rail
Strict ±3% voltage regulation and low ripple & noise
100% modular cables
All cable with flexible flat arrays

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFX Series and is the answer not in the manual?

Questions and answers

Related Manuals for SilverStone SFX Series

Summary of Contents for SilverStone SFX Series

  • Page 1 SFX Series SX750 750W SFX fully modular 80 Plus Platinum power supply Support standard SFX form factor Silent running 92mm dual ball bearing fan with minimum 18dBA All Japanese capacitors High efficiency with 80 PLUS Platinum certification Class-leading single +12V rail Strict ±3% voltage regulation and low ripple &...

  • Page 3: Specification

    SPECIFICATION SFX Form Factor SST-SX750-PT 750W Switching Power Supply With Active PFC 80Plus Platinum This specification defines ATX multiple output switching power supply. The parameters of this supply are defined in this specification for Family using. This specification defines max continuous output at 750W with 100 to 240Vac input, power supply with five outputs;...

  • Page 4: Dc Output Characteristics

    2. DC Output characteristics: 2.1 Output voltage regulation Requirements: The power supply output voltage must stay within the following voltage limits shown in Table2 when operating at steady state. Table2 Parameter Range Nom. Unit +3.3V ±3% +3.20 +3.30 +3.39 Volts ±3% +4.85 +5.0...

  • Page 5: Ripple And Noise

    2.3 Output Transient Response: Table 4 summarizes the expected output transient step sizes for each output. The transient load slew rate is = 1.0 A/μs. Table 4 Maximum Step Size (% of rated Maximum Step Size Parameter output amps) +3.3V 30% load 30% load +12V...
  • Page 6 Differential noise test setup Figure 1 2.5 Efficiency: 2.5.1 In the 115Vac/60Hz input voltage the power supply efficiency is more than 89%. Table6 Load Efficiency(%) Power Factor >0.95 100% Note: There is a 1% tolerance in mass production 2.5.2 ERP 5VSB Efficiency Table7 Efficiency target +5VSB LOAD...

  • Page 7: Capacitive Loading Conditions

    2.6 Remote on/off control When the logic level "PS-ON" is low, the DC outputs are to be enabled. When the logic level is high or open collector, the DC outputs are to be disabled. 2.7 Overshoot: The overshoot of the DC output voltage caused by switching AC power or switch PSON# should be less than 10% of the normal output, and no reverse polarity voltage should be produced.
  • Page 8 3.3 Altitude: Table11 Opera ng ≤2000m Storage ≤3000m 3.4 Cooling mode: Forced air cooling. 3.5 Random Vibration: Non-operating 0.01 g²/Hz at 5 Hz, sloping to 0.02 g²/Hz at 20 Hz, and maintaining 0.02 g²/Hz from 20 Hz to 500 Hz. The area under the PSD curve is 3.13 grams. The duration shall be 10 minutes per axis for all three axes on all samples.

  • Page 9: Power Supply Timing

    4.4 Over Temperature Protection: The power supply will be protected against over temperature conditions caused by loss of fan cooling or excessive ambient temperature. In an OTP condition the PSU will shut down. When the power supply temperature drops to within specified limits, the power supply shall be in latch mode.
  • Page 10 Table14 Parameter Description Required AC power on time <2s Power-on time < 200ms Rise time 0.2 – 20 ms PWR_OK delay 100 – 250ms PWR_OK rise time < 10 ms AC loss to PWR_OK hold-up time > 12 ms PWR_OK inactive to DC loss delay >...

  • Page 11: Fan Speed Control

    7. Reliability: The demonstrated MTBF shall be 100,000 hours of continuous operation at 25℃ and full load and nominal voltage. The MTBF of the power supply shall be calculated in accordance with MIL-HDBK-217F. The DC FAN is not included. 8. Mechanical: 8.1 Physical dimension: L100mm*W125mm*H63.5mm 9.
  • Page 12 A single PCIe 8pin cable and connector’s maximum current rating is connectés fonctionnent dans ces limites. La garantie de SilverStone 12.5A, which is 150W (+12V x 12.5A). So SilverStone’s warranty will not ne couvre pas les dommages ou les dysfonctionnements résultant cover damages or malfunction resulting from the use of a graphics card d'utilisations dépassant ces connecteurs et leurs câbles associés.
  • Page 13 电源供应器接头过度使用定义 разъёма составляет 5A, что равно 60Вт (+12В x 5A) или 25Вт (+5В x 5A). Пожалуйста, убедитесь, что подключенные устройства работают в этих пределах. Гарантия SilverStone не будет 单条PCIe 8pin电源线与接头的最大额定电流为12.5A，瓦特数150W распространяться на неисправности, возникающие в результате использования этих коннекторов или подключаемых к ним кабелей.
  • Page 14 มั น สามารถรองรั บ กระแสได้ ส ู ง สุ ด 5 แอมป์ ห รื อ หมายถึ ง 60 วั ต ต์ (+12V x 5A) (+12V x 12.5A) ดั ง นั ้ น การรั บ ประกั น จากทาง SilverStone หรื อ (+5V + 5A) จะไม่...
  • Page 15 Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ※付属の電源コードは当該製品専用です。他の機器に使用しないでください。 Please refer to SilverStone website for latest specifications updates.
  • Page 16 NO. G11239190...

This manual is also suitable for:

Sx750Sst-sx750-pt
