Gemini Series
Gemini 900A Gold
Cybenetics Gold 900W ATX Redundant Power Supply
900W+900W 24hour and well working performance at 50°C fully continuous power output
▓
ATX form factor
▓
Cybenetics Gold Certification
▓
1+1 ATX redundant configuration
▓
▓ All Japanese electrolytic capacitors
Hot swappable design
▓
Convenient pull-out handle bars
▓

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gemini Series and is the answer not in the manual?

Questions and answers

Related Manuals for SilverStone Gemini Series

Summary of Contents for SilverStone Gemini Series

  • Page 1 Gemini Series Gemini 900A Gold Cybenetics Gold 900W ATX Redundant Power Supply 900W+900W 24hour and well working performance at 50°C fully continuous power output ▓ ATX form factor ▓ Cybenetics Gold Certification ▓ 1+1 ATX redundant configuration ▓ ▓ All Japanese electrolytic capacitors Hot swappable design ▓...

  • Page 2: Ac Input Requirements

    Gemini Series Gemini 900A Gold SST-GM900A-GF / SST-GM900A-GFU 1+1 ATX Redundant Switching Power Supply Cybenetics Gold efficiency certified. 900W+900W 1.GENERAL DESCRIPTION AND SCOPE The PS/2 redundant is a power sub-system made up of a cage and redundant, hot swappable power supply modules. The cage is intended to be mounted in the system and not redundant or hot swappable.
  • Page 3 Table1: AC Input Rating PARAMETER RATED Voltage (110) 100-127 Vrms 140 Vrms Voltage (220) 200-240 Vrms 264 Vrms Frequency 47 Hz 63 Hz 2.3 Power Factor The power factor shall be greater than 0.95 at full load / 100 Vrms input voltage conditions, and 0.9 at full load / 240Vrms input voltage conditions 2.4 Input Under Voltage Brown-out( AC UVP)
  • Page 4 2.8 AC Line Fuse The power supply shall incorporate one input fuse on the LINE side for input over-current protection to prevent damage to the power supply and meet product safety requirements. Fuses should be slow blow type or equivalent to prevent nuisance trips.

  • Page 5: Dc Output Specification

    Table 3: AC Line Surge Transient Performance AC Line Surge Duration Surge Operating AC Voltage Line Frequency Performance Criteria Continuous Nominal AC Voltages 50/60 Hz No loss of function or performance 0 to ½ AC cycle Mid-point of nominal 50/60 Hz No loss of function AC Voltages or performance...
  • Page 6 Table 6: Voltage Regulation Limits Parameter Units Tolerance Vrms +3.3 V +3.135 +3.30 +3.46 +5/-5% Vrms +5 V +4.75 +5.00 +5.25 +5/-5% Vrms +12V +11.40 +12.00 +12.60 +5/-5% Vrms -12 V -10.80 -12.00 -13.20 +10/-10% Vrms +5 VSB +4.75 +5.00 +5.25 +5/-5% 3.3 Dynamic Loading...
  • Page 7 3.5 Ripple and Noise Table 11: Ripple and Noise +3.3 V +5 V +12 V -12 V +5 VSB 50 mVp-p 50 mVp-p 120 mVp-p 200 mVp-p 50 mVp-p 3.6 Load sharing The +12 V output shall have active load sharing. When operating at 50% of full load, the output current of any 1+1 power supplies shall be within (+/-10%).
  • Page 8 3.8 Timing Requirements These are the timing requirements for the power supply operation. The output voltages must rise from 10% to within regulation limits (Tvout_rise) within 1 to 70ms. The +3.3V, +5V and +12V output voltages should start to rise approximately at the same time. All outputs must rise monotonically.
  • Page 9 Table 13: Turn On/Turn Off Timing ITEM DESCRIPTION UNIS Delay from AC being applied to 5VSB 3000 msec sb_on_delay being within regulation. Delay from AC being applied to all 4500 msec ac_on_delay output voltages being within regulation. Time all output voltages stay within msec vout_holdup regulation after loss of AC.

  • Page 10: Protection Circuits

    4. Protection Circuits Protection circuits inside the power supply shall cause only the power supply’s main outputs to shutdown. If the power supply latches off due to a protection circuit tripping, an AC cycle OFF for 15 s and a PSON# cycle HIGH for 1 s must be able to reset the power supply.
  • Page 11 Table 16: Over Voltage Limits Output Voltage MIN (V) MAX (V) +3.3 V +5 V 6.82 +12V 13.4 15.6 4.3 Leakage current The leakage current from AC to safety ground will not exceed 3.5 mA-rms at 264Vac, 50 Hz. 4.4 Over Temperature Protection The power supply shall have minimum of two thermal sensors to measure the environmental (Tenv) and critical component (Tcomp) temperature.

  • Page 12: Control And Indicator Functions

    Table 18: Fan Failure Protection Condition FAN RPM Timing for LED Warning 1500 20sec Critical 1500 30sec 4.6 Over Power Protection The power supply must protect itself by Over Power Protection, no any components damaged. 4.7 Under Voltage Protection The power supply shall shutdown and latch off after an under voltage condition occurs.
  • Page 13 Table 19: PSON# Signal Characteristic Signal Type Accepts an open collector/drain input from the system. Pull-up to VSB located in power supply. PSON = Low, PSKILL = Low PSON = Open, PSKILL = Low or Open PSON = Low, PSKILL = Open 0.8V Logic level low (power supply ON) 2.0V...
  • Page 14 5.3 Power Supply LED Indicators There will be a single bi-color LED to indicate power supply status. Refer to Table 21 LED Indicators for conditions of the LED. CONDITION STATUS MODULE1(M1) MODULE2(M2) BUZZER LIGHT LIGHT CONDITION CONDITION CAGE) AC-OK Failure Warning Green Green...
  • Page 15 6.MTBF MTBF＞100,000 Hrs at 25°C, nominal input. 7. ENVIRONMENTAL REQUIREMENTS 7.1 Temperature Requirements The operation ambient temperature shall be 0°C to 50°C. The non-operation ambient temperature shall be -20°C to 80°C. 7.2 Relative Humidity Operating: 5% to 90 % relative humidity (non-condensing) Non-operating: 5% to 90 % relative humidity(non-condensing) 8.
  • Page 16 Software install guideline STEP1. You will see the below three folders when you used compression software to make the unzip all files. STEP 2 Please choose the Driver folder and you will see the two software as below. Please follow your original operation system to install the right version of monitor software.

  • Page 17: Gui Software

    STEP 4 Pleasae double clink the setup.exe file and follow the install step the install the Silverstone Gemini ATX redundant PSU monitor. It will create the shortcut on the desktop when you finish all install step. GUI Software 1. Display Integrated Module Power status •...
  • Page 18 * When the progrram is minimized, it will be displayed in the toolbar * When the program is minimized, the temperature warning will be displayed as a notification, as shown in the figure below.
  • Page 19 A single PCIe 8pin cable and connector’s maximum current rating is Anschlusses beträgt 12,5 A, was 150 W (+12 V x 12,5 A) entspricht. 12.5A, which is 150W (+12V x 12.5A). So SilverStone’s warranty will not Daher deckt die SilverStone-Garantie keine Schäden oder...
  • Page 20 électrique asegúrese de que los dispositivos conectados funcionan dentro de estos límites. La garantía de SilverStone no cubrirá daños o fallos a Le courant nominal maximum d'un câble et d'un connecteur PCIe 8 resultas de un uso excesivo de estos conectores y sus cables broches unique est de 12,5 A, ce qui correspond à...
  • Page 21 (+12V x 5A x 2) โปรดตรวจสอบให้ ม ั ่ น ใจว่ า อุ ป กรณ์ ต ั ว ดึ ง พลั ง งาน +12V ที ่ เ ชื ่ อ ม ต่ อ กั บ เมนบอร์ ด สามารถทำงานภายใต้ ข ี ด จำกั ด เหล่ า นี ้ ไ ด้ การรั บ ประกั น ของ SilverStone 仅适用于海拔2000m及以下地区安全使用。...
  • Page 22 Openings that do not exceed 5mm in any dimension Openings that do not exceed 1mm in width regardless of length...
  • Page 23 Model (safety certification):SST-AR0900FCGD-A The equipment a Class | Switching Power Supply intended to use for information technology equipment or Audio and Video equipment. ※付属の電源コードは当該製品専用です。他の機器に使用しないでください。 Please refer to SilverStone website for latest specifications updates.
  • Page 24 NO.G11247190...
