- Page 1 TV Floor Stand TVDVD-6 65" 40kg (88lbs) CAUTION: DO NOT EXCEED RATED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! support@walielectric.com...
- Page 3 Supplied Parts List ① (x1) ② (x1) ③ (x1) ④ (x1) ⑤ (x1) ⑥ (x2) ⑦ (x1) ⑧ (x1) Plastic Washer Steel Washer M6x40 M8x50 M6x18x1.5 M6x16x1.5 A (x4) D (x2) B (x7) C (x13) Steel Washer Plastic Washer M6x25 M8x16 M8x16x1 M8x16x2...
- Page 4 Step 1 ③ ② ⑧ ①...
- Page 5 Step 2 ④ ⑦ ⑤...
- Page 6 Step 3 Measure the TV fixing holes Width and Height TV2-3 TV4-6 If width X is greater than 600mm or height Y You are provided with 4 diameters of TV fixing screws, M4,M6 and M8. Determine the screw greater than 400mm STOP installation now and contact the customer help line.
- Page 7 Step 4 TV10 TV2-3 TV7-9 TV4-6 ⑥ Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 8 Step 5 Display ① ②...
