- Page 1 Extra Large Tabletop TV Stand 85" TVS004 MIN 75mm x 75mm 2-50kg MAX 1000mm x 800mm (4.4-110lbs) RATED support@walielectric.com...
- Page 3 Supplied Parts List A1(x1) A2 (x1) A3 (x1) A4 (x1) A5 (x1) A6 (x1) Base Plate Junction Plate Plastic Cover TV Bracket1 TV Bracket2 TV Bracket3 B1(X1) B2 (x1) B3 (x1) B4 (x1) B5 (x1) B6 (x1) Base Plate Junction Plate Plastic Cover TV Bracket1 TV Bracket2...
- Page 4 Step 1 Connecting the Base Plates and Junction Plates Step 2 Connecting the vertical TV Brackets...
- Page 5 Connecting the TV brackets and Junction Plates, Step 3 then install the Plastic Covers Step 5 Step 4 Step 4.1 Select TV Screws...
- Page 6 Step 4 Step 4.2 Attaching the TV Brackets to the back of TV Once you have determined the correct diameter and length, you will thread the Bolts into the TV using the correct Washers( ). Use the Spacers( ) only if the bolts are too long.
- Page 7 We support the technology that brings your home to life. We offer high quality products, professional customer service, and extensive technical support. If you have any questions,please contact us. support@walielectric.com 1-844-SATTLER (18447288537)
