- Page 1 Extra Large Table Top TV Stand TVS004 85" MIN 75mm x 75mm 2-50kg TVS004-W MAX 1000mm x 800mm (4.4-110lbs) RATED support@walielectric.com...
- Page 3 Supplied Parts List Base Plate Junction Plate Plastic Cover TV Bracket1 TV Bracket2 TV Bracket3 A1(x1) A2(x1) A3(x1) A4(x1) A5(x1) A6(x1) Base Plate Junction Plate Plastic Cover TV Bracket1 TV Bracket2 TV Bracket3 B1(x1) B2(x1) B3(x1) B4(x1) B5(x1) B6(x1) M6x10 Bolt M6x12 Cap Nut M6 Nut Allen Key...
- Page 4 Step 1 Connecting the Base Plates and Junction Plates Step 2 Connecting the vertical TV Brackets...
- Page 5 Connecting the TV brackets and Junction Plates, Step 3 then install the Plastic Covers Step 5 Step 4 Step 4.1 Select TV Screws...
- Page 6 Step 4 Step 4.2 Attaching the TV Brackets to the back of TV Once you have determined the correct diameter and length, you will thread the Bolts into the TV using the correct Washers ( M-F , M-G ). Use the Spacers ( M-H , M-I ) only if the bolts are too longer. M-F M-G H to M-E M-F / M-G...
- Page 7 We support the technology that brings your home to life. We offer high quality products, professional customer service, and extensive technical support. If you have any questions,please contact us. support@walielectric.com 1-844-SATTLER (18447288537)
