Assembly Instruction--Accent Bench
PARTS #
PARTS NAME
P1
Left Front Legs
P2
Right Front Legs
P3
Left Back Legs
P4
Right Back Legs
P5
Accent Bench
Hardware#
PARTS NAME
H1
φ5/16*2-3/8"
Lock Washers
H2
Flat Washers
H3
Allen Wrench
H4
1. Turn the bench upside down and lay on protective carpet, take out the legs and
hardwares from the bottom.
2. Using bolts (H1), lock washers (H2), flat washers (H3), connect legs(P1,P2,P3,P4) to
bench (P5). Tighten bolts (H1) with Allen Wrench (H4).
3. Place bench upright on a level surface. Assembly is complete.
DRAWING
DRAWING
Bolts
φ5/16"
φ5/16"
φ5/16"
QTY
1
1
1
1
1
QTY
8
8
8
1
