Madison Park Monroe Chair Assembly Instructions

Important safety instructions:

Please read carefully all instructions before assembly.
For your safety and ease, assembly by two or more adults is recommended.
Keep instructions for future use.

Pre-assembly:

Do not discard any content until assembly is complete to avoid accidentally discarding small parts or hardware.
Take out all parts and hardware from box.
Chair Back
Front legs
Left Arm
Right Arm
Seat Frame
Seat Cushion
Big Long Bolts Ø5/16"*2-1/2"
H1
Big Short Bolts Ø5/16"*1-3/4"
H2
H3 Big Lock Washers 5/16"
Big Flat Washers 5/16"
H4
H5 Big Allen Wrench 5/16"
Small Short Bolts Ø1/4"*1-3/4"L
H6
Small Long Bolts Ø1/4"*1-1/2"L
H7
H8
Small Lock Washers 1/4"
Small Flat Washers 1/4"*5/8"
H9
H10
Small Allen Wrench 1/4 "
H11 Screw
Wooden Plugs
H12

Assembly Procedures:

Big Long Bolts Ø5/16"*2-1/2"L
(H1)x4
(H2)x3 Big Short Bolts Ø5/16"*1-3/4"
Big Lock Washers 5/16"
(H3)x7
(H4)x7 Big Flat Washers 5/16"
(H5)x1 Big Allen Wrench 5/16"
R
1
2
1
1
1
1
8
3
11
11
1
2
2
4
4
1
5
2
