- Page 1 SPSN15 1 1/2" Sanitary with Metallic Center Section SPSN15 Models • SPSN15NPT • SPSN15NPS • SPSN15NPP STANDARD PUMP, INC ® 1610 Satellite Blvd Suite D. Duluth, Ga. 30097 • Phone: (770) 307-1003 • www.standardpump.com...
-
Page 2: Safety Information
Safety Information IMPORTANT WARNING Read the safety warnings and instructions in this manual before pump installation and start-up. Failure to comply with the recommendations stated in this manual could damage the pump and void factory warranty. Before maintenance or repair, shut off the compressed air line, When the pump is used for materials that tend to settle out bleed the pressure, and disconnect the air line from the pump. - Page 3 Table of Contents SECTION 1: PUMP SPECIFICATIONS ....1 • Performance • Materials • Dimensional Drawings SECTION 2: INSTALLATION & OPERATION ..4 • Principle of Pump Operation • Typical Installation Guide • Troubleshooting SECTION 3: EXPLODED VIEW ......7 • Composite Drawings •...
- Page 4 Stainless Steel ... . 75 lbs (34 kg) Meters Feet Capacity in U.S. Gallons Per Minute Capacity in Liters Per Minute conditions. The use of other materials and varying hydraulic conditions may result in deviations in excess of 5%. • Model SPSN15 STANDARDPUMP spsn15sm-rev-0516...
- Page 5 Maximum life should not be expected at the extreme limits of the temperature ranges. Metals: Stainless Steel: resistant iron chromium, iron chromium nickel and nickel based alloy castings for general applicaitons. Commonly referred to as 316 Stainless Steel in the pump industry. Model SPSN15 • STANDARDPUMP spsn15sm-rev-0516...
-
Page 6: Dimensional Drawings
Dimensional Drawings Model SPSN15 Sanitary Dimensions in inches (metric dimensions in brackets) 13.95 1.98 O.D. 15.72 DISCHARGE TRI- CLAMP FLANGE 2.50 2.00 1/2" NPT 3/4" NPT AIR INLET AIR EXHAUST 31.56 25.72 26.07 29.82 9.78 1.98 O.D. SUCTION TRI-CLAMP FLANGE 15.57... -
Page 7: Principle Of Pump Operation
The air exhaust must be piped above the liquid level. When the pumped product MUFFLER condition), pipe the exhaust higher than the product source to prevent siphoning spills. 1" DIAMETER AIR EXHAUST PIPING LIQUID LEVEL SUCTION LINE Model SPSN15 • STANDARDPUMP spsn15sm-rev-0516... - Page 8 Water in the compressed air supply may cause icing or freezing of the exhaust air, causing the pump to cycle erratically or stop operating. Water in the air supply can be reduced by using a point-of-use air dryer. Air Inlet And Priming • Model SPSN15 STANDARDPUMP spsn15sm-rev-0516...
-
Page 9: Troubleshooting Guide
Check valve and/or seat is worn or needs adjusting. Inspect check valves and seats for wear and proper setting. Replace if necessary. Entrained air or vapor lock in chamber(s). Purge chambers through tapped chamber vent plugs. Model SPSN15 • STANDARDPUMP spsn15sm-rev-0516... -
Page 10: Composite Repair Parts Drawing
WITHOUT THE EXPRESS WRITTEN PERMISSION OF WARREN RUPP INC. E4 Sanitary Pump DESCRIPTION DRAWING NUMBER E4SJxxxx0-SP UPDATED TO NEW MANUAL FORMAT 6/5/12 REVISION DATE SEE NOTE 4 METALLIC SEAT OPTION UPDATED TO NEW MANUAL FORMAT REVISION • Model SPSN15 STANDARDPUMP spsn15sm-rev-0516... -
Page 11: Composite Repair Parts List
Wet End Assembly Item # Qty. Description Part Number Water Chamber Manifold Elbow Ball Cage Manifold Tee Stand Attachment Pump Stand Locking Pin Large Clamp Large Clamp Bolt Large Clamp Wing Nut Small Tri-Clamp Large Tri-Clamp Model SPSN15 • STANDARDPUMP spsn15sm-rev-0516... - Page 12 Dir produkt voldoet aan de volgende EG-richtlijnen: Denna produkt överensstämmer med följande EU direktiv: Standard Pump, Inc., erklærer herved som fabrikant, at ovennævnte produkt er i overensstemmelse med bestemmelserne i Direkktive: Tämä tuote täyttää seuraavien EC Direktiivien vaatimukstet: Dette produkt oppfyller kravene til følgende EC Direktiver: Este produto está...
- Page 13 Potentially Explosive Atmospheres-Part 5 Protection by Constructional Safety Equipment: SPFP20, SPFP30, SPSN20, SPFP15, SPSN15 We hereby certify that the above apparatuses described above conforms with the protection requirements of Council Directive 94/9/EC of 23 March 1994 Annex VIII on the approximation of...
-
Page 14: Declaration Of Conformity
Declaration of Conformity Manufacturer: Standard Pump, Inc. 1610 Satellite Blvd., Suite D, Duluth, GA 30097, USA certifies that Air-Operated Double Diaphragm Food Processing and Sanitary Pump Models comply with the European Community Regulation 1935/2004/EC for Food Contact Materials. Food Processing Pump Models:...
