- Page 1 Operating Instructions and Parts Manual Industrial- & Sanitary Pump Air Motor Model: SPE-A1LF STANDARD PUMP EUROPE Ronnekrogen 2, DK-3400 Hillerod, Denmark Phone +45 70 23 21 00 info@standard-europe.eu www.standard-europe.eu (OIPM-SPE-A1LF-0125)
-
Page 2: Table Of Contents
Description..........................General Safety Information....................Motor Description........................Operation & Maintenance ..................... Hazardous Duty Operation/ AtEx..................Equipotential Bonding......................Declarations of Conformity ....................Warranty..........................14 STANDARD PUMP EUROPE Ronnekrogen 2, DK-3400 Hillerod, Denmark Phone +45 70 23 21 00 info@standard-europe.eu www.standard-europe.eu (OIPM-SPE-A1LF-0125) -
Page 3: This Manual
Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 1.This Manual This manual is concerning this product SPE-A1LF • This manual describes the safe and proper use of this product SPE-A1LF in connection with Standard Pump Europe supplied • drum pumps 2. Description Drum Pumps are designed to transfer a variety of materials from drums and tanks. -
Page 4: Motor Description
4. Motor Description SPE-A1LF, Lubrication free motors have a special hard, friction free and corrosion resistant coating. These motors can operate without any lubricant and therefore do not release any oily mist in the exhaust. Apart from the overall saving, this makes them very suitable to use in super clean environments. - Page 5 Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 4.3 Motor Spare Parts Ref. # Description Qty. Repair Kit SPE-8119704 Includes items 6, 7, 8, 9, 10, 11 & 12 Housing SPE-8110508 Front Flange SPE-8110510 Rear Flange SPE-8110507 Rotor Shaft...
-
Page 6: Operation & Maintenance
Air motors must be lubricated daily to ensure proper functionality. Standard Pump Europe recommend the use a Filter Lubricator Regulator (FLR), to ensure a moisture free supply of air to the motor. Maximum Operating Pressure 6 Bar. Equivalent motor speed is 8.500 RPM (measured by pumping clean water at 20 °C) 5.2.2 Lubrication Free Condition... -
Page 7: Operation
Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 5.3 Operation 1. Once the pump is fully assembled and all connections are securely fastened, insert the pump into the drum or tank. 2. Open air inlet valve. 3. After use, clean the pump and store vertically. - Page 8 Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 5. Remove the Pump Housing (see Figure 5). Figure 7 8. Remove pump coupling from drive shaft by turning counterclockwise (see Figure 8). NOTE: Use grip-lock pliers to hold shaft while removing coupling.
-
Page 9: Motor Inspection
Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 5.5 Motor Inspection 1. Inspection periods - Standard Condition; bearings and rotor blades to be inspected at the latest by 1000 operating hours for wear and tear and replacement. 2. Inspection period - Lubrication Free Condition; bearings and rotor blades to be inspected at the latest by 800 operating hours for wear and tear and replacement. -
Page 10: Hazardous Duty Operation/ Atex
Please contact the factory or an authorized distributor with any questions regarding this matter. Pump Conditions When operating in Hazardous Duty applications, the SPE-A1LF must be used in conjunction with a Standard Pump Europe supplied ATEX approved drum pump and properly bonded and grounded. - Page 11 • The compressed air motor correspond to the ATEX Directive/UKEx Regulation (group II, category 2 for gases and dust). • The motor are therefore suitable for driving Standard Pump Europe drum pumps of category 1/2. • Motor Operation Condition (See 5.2.3 ATEX Operation / Hazardous Area) •...
-
Page 12: Equipotential Bonding
Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) 7. Equipotential Bonding and Earthing Transferring of flammables or use in hazardous duty. Equipotential bonding is an electrical connection between a primary metal vessel and a metal receiving vessel. See schematic. - Page 13 Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) EU Declaration of Conformity Contact Standard Pump Europe or visit www.standard-europe.eu...
- Page 14 Standard Pump Europe Operating Instructions and Parts Manual (OIPM-SPE-A1LF-0125) This page is intentionally Left blank.
-
Page 15: Warranty
Warranties purporting to be on behalf of Standard Pump Europe made by any person, including representatives of Standard Pump Europe its subsidiaries, or its distributors, which do not fall within the terms of this warranty shall not be binding upon Standard Pump Europe unless expressly approved in writing by a Director or Manager of Standard Pump Europe.
