Operating Instructions and Parts Manual
Industrial Pump Models:
SP-PP, SP-PHT, SP-CPVC, SP-PVDF,
SP-6600/6700 & SP-7600/7700
Series
Pump Package Models:
9400, 9420, 9430, 9500, 9510,
9710, 9760, 9900 & 9920 Series
Industrial Pump Motors:
SP-280P, SP-ENC, SP-A1, SP-A2
& SP-400 Series
STANDARD PUMP INC.
1610 Satellite Blvd. Suite D, Duluth, Georgia 30097 USA
TOLL FREE 866–558–8611 • Phone 770–307–1003 • Fax 770–307–1009
e-mail: info@standardpump.com
www.standardpump.com
(OIPM-IND-1019)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Standard Pump SP-PP Series
Summary of Contents for Standard Pump SP-PP Series
- Page 1 9710, 9760, 9900 & 9920 Series Industrial Pump Motors: SP-280P, SP-ENC, SP-A1, SP-A2 & SP-400 Series STANDARD PUMP INC. 1610 Satellite Blvd. Suite D, Duluth, Georgia 30097 USA TOLL FREE 866–558–8611 • Phone 770–307–1003 • Fax 770–307–1009 e-mail: info@standardpump.com www.standardpump.com...
- Page 2 Pump Tube Spare Parts....................... Hazardous Duty / AtEx ......................Declarations of Conformity ....................Atex Declaration........................Warranty........................... STANDARD PUMP INC. 1610 Satellite Blvd. Suite D, Duluth, Georgia 30097 USA TOLL FREE 866–558–8611 • Phone 770–307–1003 • Fax 770–307–1009 e-mail: info@standardpump.com www.standardpump.com...
- Page 3 55 gallon corresponds to proper electrical supply. this manner causes excessive wear to drums and tanks. Standard Pump offers the potentiometer and may result in Before plugging motor into power several different pumps, each designed premature failure.
- Page 4 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-280P Series Spare Parts List Ref # Description 8130P Screw, Motor Cover/Lower Housing 8000 Motor Cover Wave Washer 8125 8331 Bearing, Upper 8508 Brush Holder 8509* Carbon Brushes, 110/220V Stator 8503 110V...
- Page 5 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-ENC Series Spare Parts List Ref # Description 3130 Screw, Motor Cover 3000 Motor Cover 3512 3511 Bearing Cover 8125 Wave Washer Bearing, Upper 8331 8508 Brush Holder 8509* Carbon Brushes, 110/220V...
- Page 6 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-A2 Series Spare Parts List Ref. Number Description Part Number Housing Assembly 317-A-A40 Inlet Bushing 317A-3B Trigger Assembly 317A-A93 Regulator Assembly 317-A249 Muffler Kit 317A-AMK1 Rear End Plate Assembly 317A-A12 Cylinder 317-A3...
- Page 7 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-A1 Spare Parts Lists Ref. # Description Repair Kit* (Includes items 2,4,6,7 & 11 SK285 Dead End Cap SAC228A Gasket SAC229 Dowel Pin SD324A Bearing SAG549 Dead End Plate SAC617 Gasket SAC527...
- Page 8 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) Pump Package Speci cations Electric Motor Pump Packages Immersion Nozzle Model Voltage Phase Meter Wetted Components Hose Length Length Material 9400 110V Polypropylene, Carbon, Hastelloy C, PVC, Viton , PTFE 39" (1000 mm) 6 ft.
- Page 9 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) Assembly 3. Remove the pump foot. (see Figure 3) 1. Remove the pump and motor from packaging. 2. Inspect all contents for damage. 3. Couple the motor to the pump tube by using the Hand Wheel.
- Page 10 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) 5. Remove the Pump Housing (see Figure 5). Figure 7 8. Remove pump coupling (P/N: 1004) from drive shaft by turning counterclockwise (see Figure 8). NOTE: Use grip-lock pliers to hold shaft while removing coupling.
- Page 11 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-PP, SP-PHT, SP-CPVC, SP-PVDF Series Spare Parts List Ref. P/N for P/N for P/N for P/N for Description Number SP-PP SP-PHT SP-CPVC SP-PVDF 1842 1842 1842 1842 Hand Wheel, Polypropylene Pump Coupling, Nylon...
- Page 12 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-6600 & 6700 Spare Parts List Ref. Description Number 1842 Handwheel, Polypropylene 1508 Snap Ring, Steel *1004 Pump Coupling, Nylon *1038-2 Bearing, Viton Shielded Bearing Spacer, SS316L *8838-4 V Seal, PTFE 4000...
- Page 13 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) SP-7600 & 7700 Spare Parts List Ref. P/N for Description Number SP-SS 1842 Hand Wheel, PP 1508 Snap Ring, Steel Pump Coupling, Nylon *1004 Bearing, Viton Shielded *1038-2 Bearing Spacer, SS316L *8838-4...
- Page 14 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) Hazardous Duty for both class I and II hazardous locations Drum Pump Installation can be made of “...iron, steel, copper, bronze, Operation SP-410EX & SP-430EX or aluminum..." (UL 674, Electric Motors and Generators –...
- Page 15 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) Grounding Procedures Bonding and grounding are required when before starting). Always check with a safety pumping flammable materials or in hazardous engineer when any question arises and Transferring of duty environments. Failure to bond and...
- Page 16 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) North America Declaration of Conformity We here with declare that the construction type Designation: SP-280P SP-280P-V SP-ENC SP-ENC-V Machine type: Electric Motors for drum pumps Item No: SP-280P SP-280P-V SP-ENC SP-ENC-V In the form as delivered by us complies with following applicable...
- Page 17 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) EC Declaration of Conformity We herewith declare that the construction type Designation: SP-280P-2 SP-280P-2-NL SP-280P-2-V SP-280P-2-V-NL SP-ENC-2 SP-ENC-2-NL SP-ENC-2-V SP-ENC-2-V-NL Machine type: Electric Motors for drum pumps Item No: SP-280P-2 SP-280P-2-NL SP-280P-2-V...
- Page 18 Standard Pump Operating Instructions and Parts Manual (OIPM-IND-1019) Rønnekrogen 2 < Phone: + 45 70 23 21 00 Fax: + 45 70 23 56 55 info@standard-europe.eu EU-Conformity Declaration ATEX 2014/34/EU We herewith declare that the products: SP-6600/6700, SP-7600/7700, SP-8600/8700 and SP-8850/8950...
- Page 19 Standard Pump, Inc, or its distributor . A returned goods authorization number (RGA #) issued by Standard Pump, Inc ., its subsidiary or authorized distributor, must be included with the returned equipment . The RGA # is required if the equipment has been used .
- Page 20 STA�DARD...
