- Page 1 Installation manual Washer extractor S7–75, S7–85, S7–105, S7–130, S7–180, S7–250, S7–330 Type W3... 438905543/GB, IE Original instructions 2025.05.19...
-
Page 3: Table Of Contents
Contents Contents 1 Safety Precautions ..........................5 General safety information......................6 Commercial use only........................6 Copyright ..........................6 Symbols............................6 2 Technical data.............................7 Drawing ............................7 2.1.1 S7–75, S7–85, S7–105 ....................7 2.1.2 S7–130...........................8 2.1.3 S7–180...........................9 2.1.4 S7–250, S7–330......................10 Technical data ......................... 11 Connections ..........................12 3 Setup ...............................13 Unpacking ..........................13 Recycling instruction for packaging ...................14 Siting ............................15... - Page 4 Contents The manufacturer reserves the right to make changes to design and component specifications.
-
Page 5: Safety Precautions
Installation manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. •... -
Page 6: General Safety Information
The machine/machines covered by this manual is/are made for commercial and industrial use only. 1.3 Copyright This manual is intended solely for consultation by the operator and can only be given to third parties with the permis- sion of Wascomat company. 1.4 Symbols Caution... -
Page 7: Technical Data
Installation manual 2 Technical data 2.1 Drawing 2.1.1 S7–75, S7–85, S7–105 fig.X01719 Operating panel Door opening, S7–75, S7–85: ⌀ 310 mm, S7–105: ⌀ 365 mm Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection S7–75 1135... -
Page 8: S7-130
Installation manual 2.1.2 S7–130 fig.X01720 Operating panel Door opening, S7–130: ⌀ 365 mm Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection S7–130 1220 1335 S7–130 1120 1100 1000... -
Page 9: S7-180
Installation manual 2.1.3 S7–180 fig.X01721 Operating panel Door opening, S7–180: ⌀ 395 mm Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection Cold water (for detergent container) / Hot water S7–180 1345 1435 1050 S7–180... -
Page 10: S7-250, S7-330
Installation manual 2.1.4 S7–250, S7–330 fig.X01722 Operating panel Door opening, S7–250, S7–330: ⌀ 435 mm Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection S7–250 1030 1430 1590 1135 S7–330 1115 1465 1675 1170 S7–250... -
Page 11: Technical Data
Installation manual 2.2 Technical data S7–75 S7–85 S7–105 S7–130 S7–180 S7–250 S7–330 Weight, net Drum volume litres Drum diameter Drum speed during wash Drum speed during extraction G-factor, max. Heating: Electricity Heating: Steam Heating: Hot water Frequency of the dynamic 13.8 13.8 12.9... -
Page 12: Connections
Installation manual 2.3 Connections S7–75 S7–85 S7–105 S7–130 S7–180 S7–250 S7–330 Water valves 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” Recommended water pressure 200–600 200–600 200–600 200–600 200–600 200–600 200–600 Continuous operating pressure 50–800 50–800 50–800 50–800 50–800 50–800 50–800 Capacity at 300 kPa l/min Drain valve... -
Page 13: Setup
Installation manual 3 Setup 3.1 Unpacking Note! For S7–130, S7–180, S7–250, S7–330 two persons are recommended for the unpacking. Remove the front and rear panel. Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another diagonally opposed to it, at the back of the machine. -
Page 14: Recycling Instruction For Packaging
Installation manual 3.2 Recycling instruction for packaging fig.X02395 Fig. Description Code Type Wrapping film LDPE 4 Plastics Corner protection PS 6 Plastics Cardboard packaging PAP 20 Paper Pallet FOR 50 Wood Screw FE 40 Steel FE 40 Steel Plastic bag PET 1 Plastics... -
Page 15: Siting
Installation manual 3.3 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will prevent easy access for maintenance and service operations. -
Page 16: Mechanical Installation
Installation manual 3.4 Mechanical installation Foundation requirement In this type of machine, the drum is attached directly to the frame. As a result the floor under the machine must be stable enough to absorb the dynamic forces generated during spin cycles. For that reason, the mounting bolts must be cast into the floor material itself. - Page 17 Installation manual After the machine has been placed over the other four M16 bolts, at the expansion M10 bolts (1), place the two square spacers (t = 4 mm) over the two holes. They shall be placed between the machine and foundation. Insert the expansion bolts (1) into the holes drilled in the floor.
-
Page 18: Casting A Plinth
Installation manual 3.4.1 Casting a plinth A plinth should be used where the existing floor is less than 150 mm thick or in order to ensure that the machine is above the level of any water leakages. The plinth should be approximately 150 - 200 mm in height. 4-M16 (5/8") 150-200 mm / 5 7/8-7 7/8 inch... -
Page 19: Chemical Bolts / Chemical Anchors
Installation manual 3.4.2 Chemical bolts / chemical anchors An alternative to breaking up the existing floor or foundation is to use chemical bolts M16. 1. Mark and drill four holes (⌀ 18 mm) 125 mm deep for the chemical bolts. Check the previous table for the correct position of the holes. - Page 20 Installation manual fig.7644C...
-
Page 21: Marine Installation
Installation manual 4 Marine installation 4.1 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. fig.X00959 25 mm 500 mm... -
Page 22: Mechanical Installation
Installation manual 4.2 Mechanical installation To ensure steadiness of the machine it is important to fasten the machine to the foundation. Level the machine by using stainless or galvanized steel washers between the machine and the floor. The washers must be of a size to cover the support surface. Fit the washers and self-locking nuts supplied with the machine and tighten well. -
Page 23: Casting A Plinth
Installation manual 4.2.1 Casting a plinth A plinth should be used where the existing floor is less than 150 mm thick or in order to ensure that the machine is above the level of any water leakages. The plinth should be approximately 150 - 200 mm in height. 4-M16 (5/8") 150-200 mm / 5 7/8-7 7/8 inch... -
Page 24: Welding A Foundation
Installation manual 4.2.2 Welding a foundation A welded foundation shall be made where a concrete foundation can not be made. The welded foundation must be able to withstand the loads indicated in the table in the Technical data section. (Equivalent the concrete floor, with a minimum strength of 20.7 MPa). The following figure shows such an example of welded foundation, where the machine fixing points are located and must be mounted to the welded foundation. -
Page 25: Water Connection
Installation manual 5 Water connection All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal- lation and servicing. Water pipes and hoses should be flushed clean before installation. The machine shall be connected with new water hoses. Re-used water hoses must not be used. Hoses are to be of an approved type and grade and comply with IEC 61770 and any applicable local regulations. - Page 26 Installation manual Water pressure: Continuous operating pressure: 50–800 kPa (0.5-80 kp/cm Maximum: 1000 kPa (10 kp/cm Recommended: 200–600 kPa (2–6 kp/cm Note! If the water pressure is below the minimum value, the wash result can not be guaranteed for certain program. For WRAS-approved machines;...
-
Page 27: Connection Of External Dosing Systems
Installation manual 6 Connection of external dosing systems 6.1 Connection of the hoses The machine is prepared for connection of external dosing systems or water re-use systems etc. The connections are closed at delivery. Open any of the connections that shall be used by drilling a hole where the hoses shall be connected. -
Page 28: Electrical Connection Of External Dosing System
Installation manual 6.2 Electrical connection of external dosing system The power supply to the external dosing system must never be connected to the machine’s incoming terminal block or to the edge connectors on the I/O-board. 6.2.1 Machine with connectors Connect the external dosing system to connections A and B on the machine. Connect the signal cable to B and the power supply to A. -
Page 29: Machine Without Connectors
Installation manual 6.2.2 Machine without connectors Connect the external dosing system to the I/O board, which is located to the right of the incoming power supply. The I/O board has edge connectors for connecting external dosing systems. Edge connectors on the I/O board can be loosened for connecting cables. fig.6572 11 = N 18 = Program run... -
Page 30: Outputs
Installation manual 6.2.3 Outputs Connect the power supply (e.g. 24V DC) for the external liquid supplies to 9 and 10. If an internal power supply (from the machine) is being used, it can be taken from 1 (N) and connected to 9 and from 2 (L) and connected to 10. Max load on the outputs 0.5 A. -
Page 31: Inputs
Installation manual 6.2.4 Inputs The signal level can be 5-24V DC/AC or 100- 240V AC. For 5-24V, the signal reference is connected to 3 and for 100-240V to 4. Potentials on the inputs cannot be mixed. Note! The I/O board will be damaged if the voltage on connection 3 is too high > 24V. Connection 8 may be connected if the program is to pause, e.g. -
Page 32: Drain Connection
Installation manual 7 Drain connection Connect a 75 mm pipe or rubber hose to the machine’s drain pipe, ensuring a downward flow from the machine. Avoid sharp bends which may prevent proper draining. fig.5330 Drain pump (for models S7–75, S7–85, S7–105) The drainage pipe should be located over a floor drain, drainage channel or the like. -
Page 33: Electrical Connection
Installation manual 8 Electrical connection 8.1 Electrical installation The electrical installation may only be carried out by qualified personnel. Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break- er. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. -
Page 34: Electrical Connections
Installation manual 8.2 Electrical connections S7–75 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse Electric heated 220-240V 1/1N~ 50/60 3.0/5.4/7.5 3.3/5.7/7.8 16/25/32 220-240V 3~ 50/60 3.0/5.4/7.5 3.4/5.7/7.8 10/16/25 380-415V 3N/3~ 50/60 3.0/5.4/7.5 3.4/5.7/7.8 10/10/16 440V 3~ 50/60 5.4/7.5 5.7/7.9... - Page 35 Installation manual S7–180 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse Electric heated 220-240V 1/1N~ 50/60 4.8/13.0 5.3/13.5 25/63 220-240V 3~ 50/60 4.8/13.0 5.3/13.5 16/35 380-415V 3N/3~ 50/60 4.8/13.0 5.3/13.5 10/25 440V 3~ 50/60 13.0 13.5 480V 3~ 13.0 13.7...
-
Page 36: Machine Connection
Installation manual 8.3 Machine connection Connect the earth and other wires as shown. Single-phase connection Three-phase connection 1NAC L2 L3 3N AC L2 L3 1N/1 3N AC L2/N Single phase machines may be powered either by connection between a phase and neutral or by connecting be- tween two phases. -
Page 37: Machine Connection With Ferrite
Installation manual 8.4 Machine connection with ferrite 8.4.1 S7–250, S7–330 To obtain approved level of EMC, it is mandatory to use the ferrite which is enclosed with above listed models. (Note that this is only valid for those models). Before connecting to the machine, the protective earth (PE) wire shall be wrapped around the ferrite. Prepare the power cord by making sure the protective earth (PE) wire is longer than the other wires according to the table. -
Page 38: Functions For I/O-Cards
Installation manual 8.5 Functions for I/O-cards The electrical schematic can be one of the following: 8.5.1 External coin meter/Central payment (2A) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.6606A... -
Page 39: Central Payment (2B)
Installation manual 8.5.2 Central payment (2B) To start the machine from a central payment system, the payment system must transmit a start pulse to the machine. The start pulse can be either 230V or 24V. In order to receive a feedback signal once the machine has started, 230V or 24V must be connected to connection 19. -
Page 40: Central Payment (2C)
Installation manual 8.5.3 Central payment (2C) The central payment or booking system shall transmit an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the machine door is closed but the program has not started. -
Page 41: Outputs For Detergent Signals And Inputs For Pause Signals, "Empty" Signal And Price Reduction (2D)
Installation manual 8.5.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price reduction (2D) The figure shows standard function addressing for machines with the coin program package. By maintaining an active (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. -
Page 42: Central Booking/Payment (2F)
Installation manual 8.5.5 Central booking/payment (2F) The central payment or booking system shall provide an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the program is running. -
Page 43: Machines With I/O Module Type 3
Installation manual 8.5.6 Machines with I/O module type 3 By maintaining an active (high) signal on connection 3 "Price reduction”, the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. Whilst the sig- nal remains active (high), the price of the program is reduced by the percentage entered in the price programming menu. -
Page 44: Converting Heating Elements
Installation manual 8.6 Converting heating elements WS6–20 S7–180 can be converted from 380-415V 3N AC to 220-240V 1N AC with reduced power Disconnect the power to the machine. Demount the cover panel to the electrical connections. Remove the cables that are connected to K21:2 and K22:6. Move the remaining cables from L2 and L3 to L1 or N ac- cording to the figure. -
Page 45: Steam Connection
Installation manual 9 Steam connection Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). Demount the top panel (A). - Page 46 Installation manual Mount the hose with wires between steam valve and machine. Connect the wires to the steam valve. Connect ground cable to the terminal ground connection. Connect the ”HEAT” cable connector to the ”HEAT” terminal on the I/O board. ”HEAT”...
-
Page 47: At First Power Up
Installation manual 10 At first power up When the installation is complete and the power is connected for the first time you will be forced to make the following settings. When one setting is ready you will automatically enter the next one. •... -
Page 48: Function Check
Installation manual 11 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •... -
Page 49: Disposal Information
Installation manual 12 Disposal information 12.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 52 Electrolux Professional AB 341 80 Ljungby, Sweden Share more of our thinking at www.wascomat.com...
