Page 1 Service Manual DOC. NO. 438.9228-96/03 EDITION 2010.08.27 SU620cl – SU677cl Clarus Control Wascomat provides efficient washers, dryers, flatwork ironers and wetcleaning systems in a size and model for every laundry and wetcleaning need! 516-371-4400...
Page 2: Warranty Claims
Wascomat machine(s), the model and serial number(s). additional warranty proof may also be required.
Page 3: Installation
NOTICE TO SERVICE PERSONNEL INSTALLATION Improper installation of Wascomat laundry and wet cleaning equipment can result in personal injury and severe damage to the machine. REFER INSTALLATION TO QUALIFIED PERSONNEL! RISK OF ELECTRIC SHOCK The equipment utilizes high Voltages. Disconnect electric power before servicing.
Page 4: Intentionally Blank
Intentionally blank...
Page 5 Clarus Control WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR WASCOMAT MACHINE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
Page 6 Intentionally blank...
Page 7 Be certain to relock after remoun- ting the top panel. MANUFACTURED BY WASCATOR DISTRIBUTED BY WASCOMAT, INWOOD, NEW YORK, USA 471 766202-04 LOCATED ON THE DOOR: If you need to order more safety or warning signs, call Wascomat's parts department at 516-371-2000, or call your local dealer.
Page 8 Be sure to keep the machine(s) in proper working order: Follow all maintenance and safety procedures. Further information regarding machine safety, service and parts can be obtained from your dealer or from Wascomat through its Technical Support Department - 516/371-0700.
Page 9: Table Of Contents
Contents Contents Safety Precautions ..................11 Technical data .................... 13 Machine presentation ................17 General ....................17 Function ....................18 Programme unit ..................19 Motor and motor control ............... 20 Door lock ....................21 Heating ....................22 Water connections ................22 Rear control unit ..................
Page 10 Contents Door and door lock .................. 157 General ....................157 The door lock locks the door............... 159 The door lock unlocks the door............159 Error codes ..................160 Reset button ..................161 Door lock control inputs/outputs ............161 Repairs ....................164 Emergency opening of door lock ............
Page 11: Safety Precautions
Safety Precautions Safety Precautions • The machine is only intended for washing with water. • Do not allow minors to operate the machine. • Installation and maintenance work should only be done by authorized persons • Do not bypass the door lock of the machine. • Any leaks, e.g. a worn-out door seal, should be repaired immediately. • Prior to repairs or maintenance, be sure to read the corresponding handbooks and service manuals. • Do not flush the machine with water. Warnings The service manual includes the following warnings that warn of possible injuries. Next to each warning text, a page reference refers to the page where the warning can be found in the manual.
Page 13: Technical Data
Technical data Technical data SU620 SU630 SU645 SU660 SU677 Innerdrum volume litres/ft 85/3.0 130/4.6 180/6.4 250/8.8 330/11.7 diameter mm/inch 520/20 1/2 595/23 7/16 650/25 9/16 725/28 9/16 795/31 5/16 Drum speed wash extraction Heating electricity 5.4/7.5 7.5/10 steam hot water G-factor Weight, net kg/lbs...
Page 14 Technical data Electrical connection Cold water Hot water Steam connection Drain Liquid detergent supply Control panel Soap box Water reuse Door opening, SU620: ø310, SU630: ø365, SU645: ø395, SU660, SU677: ø435 SU620 730 1115 355 45 1030 215 1010 130 SU630 790 1200 365 45 1115 215 1095 130...
Page 15 Technical data in inch SU620 28 3/4 43 7/8 30 1/8 32 1/2 1 3/4 40 9/16 8 7/16 39 3/4 SU630 28 3/8 31 1/8 47 1/4 14 3/8 32 1/2 35 13/16 1 3/4 40 7/8 8 7/16 43 1/8 SU645 29 1/2...
Page 16 Technical data Frequency of the dynamic force 11.6 10.8 10.3 Max floor load at extraction lbs force 375±741 518±1050 611±1320 842±1663 948±1974 1.7±3.3 2.3±4.7 2.7±5.9 3.7±7.4 4.2±8.8...
Page 17: Machine Presentation
Machine presentation Machine presentation General The machines covered in this manual include: Drum volume Model type (gallon) 22.5 SU620 34.4 SU630 47.6 SU645 SU660 87.2 SU677 The programme unit contains a microprocessor with a number of standard programmes for nor- mal wash cycles.
Page 18: Function
Machine presentation Function This section presents an overview of the functions of the machine. Most functions are then presented in detail in separate chapters in the service manual. Water inlet valves Rear control unit I/O card Detergent compartment Front control unit Motor control Programme unit Control panel...
Page 19: Programme Unit
Machine presentation Programme unit The programme unit is made up of the CPU card, the display card, card reader and one Programme unit I/O card or two I/O cards. The programme unit holds a number of standard programmes, but it is also possible to programme user-specific washing programmes, either using the control panel on the machine or a computer.
Page 20: Motor And Motor Control
Machine presentation Motor and motor control A frequency-regulated motor using a drive belt Motor control drives the drum. The motor is situated on a mo- tor shelf, under the outer drum with a tensioner device for the drive belt. The motor control relies on microcomputer con- trol and controls acceleration, rpm and retarda- tion of the drum with high precision.
Page 21: Door Lock
Machine presentation Door lock The door lock is an electro-mechanical type with Door lock control A31 double safety switches. The lock is bi-stable, i.e., it needs to receive an active pulse from the control in order to both lock and unlock the door. A separate printed circuit board, called door lock control, can be fitted onto the programme unit. This board controls locking and unlocking.
Page 22: Heating
Machine presentation Heating When using electric heating, the water for wash- Rear control unit ing is heated by three heating elements acces- sible from the front of the machine. Contactor K21 Main power switch (heating) The machine can also be fitted with steam hea- ting using a steam valve fitted on the rear of the machine.
Page 23: Detergent Compartment
Machine presentation Detergent compartment The compartment is divided into four for pre- wash, main wash, rinse and bleaching-agent/ Detergent compartment liquid detergent. The detergent compartment of the machines is described in detail in section Detergent compartment. Drain valve This valve is a diaphragm valve that opens and closes by way of the water pressure. The control valve is situated next to the water valves.
Page 25: Troubleshooting
Troubleshooting Troubleshooting The troubleshooting section is used to pinpoint a fault on the machine to a specific defective component or unit. If the power supply is interrupted, the programme memory will keep the select programme in its memory for approx 3-5 minutes. Within this time period, the machine automatically restarts after the power interruption.
Page 26: Errors With No Error Codes
Troubleshooting Errors with no error codes This section includes troubleshooting charts for errors for which no error code is generated. Errors with error codes Error indication Programme or machine errors are indicated by an alarm text in the display window. Alarm text 4221 Resetting an error indication...
Page 27 Troubleshooting List of errors, functions monitored and relevant error messages displayed Error/Function Error message displayed 01 ERROR. NO WATER Water level has not reached set level within time set. NO WATER After this error message appears and the machine is reset, the machine will try again.
Page 28 Troubleshooting List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed 15 ERROR. EMERGENCY STOP The emergency stop button has been pressed. EMERGENCY STOP 16 ERROR. WEIGHT FROM SCALE Over-/Under-load of scale or weight above limit for maximum allowed WEIGHT FROM SCALE weight at wash module start. 17 ERROR.
Page 29 Troubleshooting List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed ERROR CODES FROM MOTOR This function includes a number of error warnings from the motor control system for frequency-controlled motors (EWD) 31 Temperature of MCU control circuits too high HEAT SINK TOO HOT 32 Motor thermal protection has tripped MOTOR TOO HOT...
Page 30: Service Programme
Troubleshooting Service programme Opening the service programme The service program The service program makes fault-finding on the machine easier, as it allows you to control the If this menu is not currently various machine functions individually: displayed: • water filling RUN A WASH PROGRAM Press repeatedly. GO TO THE MENU • detergent flushing MAKE YOUR CHOICE WITH • motor rotation, clockwise and counterclockwise...
Page 31 Troubleshooting To prevent unauthorised or accidental use Unauthorised or accidental use of the service program is prevented by requiring the user to locate PRESS BUTTON ON Press the button on the and press the button on CPU board. CPU BOARD CPU circuit board.
Page 32: To Control The Machine Functions
Troubleshooting To control the machine functions SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED 01 COLD WATER 02 HOT WATER 03 COLD HARD WATER 04 TANK 1 WATER 05 TANK 2 WATER 06 TANK 3 WATER To activate the various 01 COLD WATER machine functions: 02 HOT WATER...
Page 33: I/O Card Inputs
Troubleshooting I/O card inputs Press 1. SERVICE PROGRAM Now you can check the LEVEL TEMP 22°C various input signals from I/O SPEED DRAIN CLOSED board 1. EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED A black square in front of the REMOTE START UNBALANCE SERVICE...
Page 34: No Indication In The Display Window (Machine Not Responding Or Operates Apart From This)
Troubleshooting Errors with no error codes Programme unit card No indication in the display window (machine not responding or operates apart from this). If the power is on, be very careful when working on the the machine. 3972 Verify that: Green LED Red LED • the machine receives power.
Page 35: Errors With Error Codes
Troubleshooting Errors with error codes NO WATER The water level has not reached the selected level within the given time. Following an alarm and subsequent, the machine will make a new attempt. First verify that: • the programme unit was not incorrectly pro- grammed 3973 • the inlet filter is not blocked Valve Switch Relay cold/warm compartment 1 X9:7...
Page 36: Level Indication
Troubleshooting Continued from previous page 5. Activate (close) the drain valve in the service programme. Activate another of the water valves and verify the drain valve function. Drain valve OK Drain valve defective Troubleshoot the drain valve according to the instructions under error code WATER IN DRUM later in this troubleshooting section.
Page 37 Troubleshooting DOOR OPEN No signal from the ”Door closed” during pro- gramme operation. If the input signal for ”Door closed” is lost during programme operation, the OPEN DOOR error code is immediately generated. If the power is on, be very careful when working on the the machine.
Page 38 Troubleshooting Continued from previous page 4. Disassemble the door lock and verify the function of S3 using an ohm meter. Correct function Incorrect function Replace Door lock. Cables 6112...
Page 39: Door Unlocked
Troubleshooting DOOR UNLOCKED No signal from the ”Door locked” during pro- gramme operation. If the input signal for the "Door locked" is lost during programme operation, the "DOOR UN- LOCKED" error code is immediately genrera- ted. At programme start, this error code is sup- pressed for a few seconds.
Page 40: Ntc Low Temp
Troubleshooting NTC LOW TEMP The programme unit indicates an interruption with the temperature sensor or the tempera- ture is below -5 °C. Try to restart the machine (i.e. reset the error code) by pressing START. 1. Undo the temperature sensor connections and measure the resistance of the sensor.
Page 41: Ntc High Temp
Troubleshooting NTC HIGH TEMP The programme unit indicates a short-circuit with the temperature sensor or the tempera- ture exceeds 98°C. Try to restart the machine (i.e. reset the error code) by pressing START. 1. Undo the temperature sensor connections and measure the resistance of the sensor.
Page 42: Water In Drum
Troubleshooting WATER IN DRUM Level indication The water level is higher than EMPTY at programme start. SERVICE PROGRAM First verify whether: LEVEL TEMP 22°C SPEED DRAIN CLOSED • the same error appears again following reset- EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED ting of the error code REMOTE START IMBALANCE SERVICE...
Page 43: Machine Overfilled
Troubleshooting MACHINE OVERFILLED Level indication The water level is above the level for OVER- FILLED MACHINE. If this function is switched SERVICE PROGRAM off (=N) the drain valve will open instead for a LEVEL TEMP 22°C short while to drain some of the water. SPEED DRAIN CLOSED EMERGENCY STOP...
Page 44 Troubleshooting NO HEATING The temperature has not increased the number of degrees specified in the function MIN ALLO- WABLE TEMPERATURE INCREASE (see set- tings 2) during the time that is programmed in the function MAXIMUM HEATING TIME (Confi- guration 1). If the power is on, be very careful when working on the the machine.
Page 45 Troubleshooting NOT DRAINED The water level exceeds EMPTY at wash program start. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, first verify these items: • Is the drain is blocked by fluff or foam? • Are the the level hose and air box blocked (blow into the level hose)? • For machines with a drain pump, verify correction operation. • Does water run out when the power switch on the machine is switched off? • Verify the operation of the drain using the service programme.
Page 46: Unbalance Sensor Fault
Troubleshooting UNBALANCE SENSOR FAULT The imbalance switch is closed during program start. If the power is on, be very careful when working on the the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: Verify: • the mechanical function of the imbalance switch • the resistance between the imbalance switch and the cabling.
Page 47: No Motor Comm
Troubleshooting NO MOTOR COMM. Communication between the programme unit and the motor controller has been interrupted or interfered. If the power is on, be very careful when working on the the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: 1.
Page 48: Level Calibration
Troubleshooting LEVEL CALIBRATION The water level system has not been correctly calibrated. Each machine has been individually level adjusted at the factory. If the calibration values are missing or outside the limits, an error is generator at programme start. The programme can, however, be started by pressing START once more.
Page 49: Weight From Scale
Troubleshooting WEIGHT FROM SCALE The scale is all the time sending the actual weight to the timer. If the scale is over- or under-loaded all the time the error will be indicated. The same error will also be indicated if the weight transfered from the scale to the timer at the beginning of a water filling periode, is above a certain li- mit set in the configuration system of the machine.
Page 50: Emergency Stop
Troubleshooting EMERGENCY STOP The emergency stop button was pressed. If the power is on, be very careful when working on the the machine. Find out the reason for the emergency stop button having been pressed. Take the necessary measures. Reset the emergency stop button by turning it counter-clockwise. Restart the machine by pressing START or a.
Page 51 Troubleshooting DOOR LOCK The signal from the ”Door locked ” switch is present although there is no signal from the ”Door closed” switch. This error code can only be generated prior to programme start. If the power is on, be very careful when working on the the machine.
Page 52: Start Not Allowed
Troubleshooting START NOT ALLOWED The network does not allow start of the washing programme. Try to reset the error code. If the error remains, contact the responsible person for the network and have the error fixed.
Page 53: Mis Communication
Troubleshooting MIS COMMUNICATION Communication between the programme unit card A1 and the network has been interrupted. If the power is on, be very careful when working on the the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: 3972 Verify that the cable between the network and...
Page 54: Interlock Status
Troubleshooting INTERLOCK STATUS X302 The motor controller does not receiving an interlock signal during programme operation. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been comple- tely reset.
Page 55 Troubleshooting IO COMMUNICATION Communication between programme unit A1 and one of the I/O cards has been interfered with or interrupted, or incorrect configuration of the I/O cards. If the power is on, be very careful when working on the the machine. Try to restart the machine (i.e.
Page 56: Low Oil Level
Troubleshooting LOW OIL LEVEL Low oil level in the oil container. Applies only to machines with oil lubrication. Fill up with oil and restart the machine. Verify for any leaks.
Page 57 Troubleshooting PHASE Alarm from the mains monitoring equipment. An input on I/O card 1 (X16:7-8) can be connected to external equipment that monitors received mains signals in terms of voltage levels, loss of phase, etc. If this input goes high, the error message is displayed. Find out the reason for the error indication by inspecting the mains monito- ring equipment.
Page 58: Aut. Level Calib
Troubleshooting AUT. LEVEL CALIB. The pressure sensor for the water level signals Level indication a value that is so incorrect when the machine is empty that automatic level calibration of the SERVICE PROGRAM level system is not possible. LEVEL TEMP 22°C SPEED DRAIN CLOSED...
Page 59: Level Not Calibrated
Troubleshooting LEVEL NOT CALIBRATED Before the machine is used filling water controlled by the pressure sensor system, the pressure sensor system must be calibrated. The pressure sen- sor system for water filling can be calibrated in the service mode. It is possible to use the machine in weight mode, filling water on weight, without calibrating the water pressure sensor system.
Page 60: No Scale Connected
Troubleshooting NO SCALE CONNECTED Communication between the timer and the scale is not working. Check the wire between the timer and the scale. If still not working, please contact service.
Page 61: Heat Sink Too Hot
Troubleshooting HEAT SINK TOO HOT The motor controller indicates too high a temperature at the heat dissipator. This error code appears if the external temperature has been very high. It his has been the case, lower the temperature by e.g., ventila- tion the room.
Page 62: Motor Too Hot
Troubleshooting MOTOR TOO HOT The motor controller indicates the thermal Measure the resistance between pins 7 and 9 protector of the motor has triggered. If the power is on, be very careful when working on the the machine. First verify that: Contactor X3, female towards motor • the machine is not overloaded 5420...
Page 63 Troubleshooting Continued from previous 4. Replace X3. Remove the contactor X312 and measure the resistance of the contactor with the motor cabling between X312:4 - 5. Contact Interruption Defective cabling between motor controller and motor. Inspect the cabling and replace if necessary. Internal error in the thermal sensor of the motor controller detector.
Page 64 Troubleshooting NO INTERLOCK X302 The motor controller received the rotation command from the programme unit but recei- ves no interlock ACK (”Door locked” signal). If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been comple- tely reset.
Page 65: Motor Shortning
Troubleshooting MOTOR SHORTNING Contactor X3, female towards motor The motor controller indicates a short-circuit in the motor windings, cabling or internally in the motor controller. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to Measure resistance between ensure the motor controller has been completely pins 1, 2 and 3...
Page 66: Interlock Hardware
Troubleshooting INTERLOCK HARDWARE The motor controller indicates an error in the interlock receiving circuit. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor con- troller has been completely reset.
Page 67: Low Dc Voltage
Troubleshooting LOW DC VOLTAGE X311 The motor controller indicates the DC level is too low. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been comple- tely reset.
Page 68: High Dc Voltage
Troubleshooting HIGH DC VOLTAGE X311 The motor controller indicates the DC level is too high. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been completely reset.
Page 69: Rippel On Dc Bus
Troubleshooting RIPPEL ON DC BUS X311 The DC voltage level fluctuates too much. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been completely reset.
Page 70: Line Interrupt
Troubleshooting LINE INTERRUPT X311 The motor controller is missing a phase. If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor controller has been completely reset.
Page 71: Klixon Circuit
Troubleshooting KLIXON CIRCUIT The motor controller indicates an error inn the thermal protection circuits of the motor. If the power is on, be very careful when working on the the machine. Switch off the machine and for about 30 seconds. Then switch on the machine again and start a programme.
Page 72 Troubleshooting NO PARAM. SET IN MCU The motor controller indicates no parameter set value in motor controller (MCU). If the power is on, be very careful when working on the the machine. Switch off the machine for at least 30 seconds to ensure the motor control- ler (MCU) has been completely reset.
Page 73: Troubleshooting The Keypad In The Display Unit
Troubleshooting Troubleshooting the keypad in the display unit When a key is pressed on the keypad of the programme unit, two of the outputs on the keypad close. By disconnected the flat cable from the display card, pressing a key and the measuring the resistance between the outputs that should close, it is possible to determine correct operation of any one key.
Page 75: Control Unit
Control unit Control unit Description The control unit of the machine consists of the following parts: • Front control unit This unit contains two microcomputer controlled electronic pro- gramme units consisting of a CPU card A1, display card A2, card reader A3 and one or two I/O cards A11 and A12.
Page 76: Front Control Unit
Control unit Front control unit Programme unit The programme unit consists of the following I/O card 2 parts: • CPU card A1 The CPU card uses the various control pro- I/O card 1 grammes in the card programme memory to check the various functions of the washing machine.
Page 77 Control unit • I/O cards A11 and A12 Most smaller machines have only one card: A11. The I/O cards are controlled by the CPU card via a serial interface. The I/O cards fea- ture outputs, which, via the communication card in the rear control unit, control various machine functions, such as the water valves, heating connection and drain valve.
Page 78 Control unit Door lock control A31 This card serves to perform a safety check of the door lock function. The card checks the water level using level gu- ard B2 and the drum speed by way of a rotation sensor B3. The card receives a signal from the CPU card when the door should be locked or opened.
Page 79: Rear Control Unit
Control unit Rear control unit Main power switch Q1 Model with main power switch The main power switch interrupts all received Main power switch Q 1 Heating contactor K21 power phases and is situated on the outside of the connection box cover. The cover cannot be removed unless the main power switch is turned to the 0 position.
Page 80 Control unit Communication card A21 This card is used to send and receive signals from I/O card 1. It contains: • Fuses F11 and F12 (T 1.25 A) Protects the received voltage supply in the Communication card A21 timer and door lock controller. • Service button S40 Used to engage service mode of the pro- gramme unit.
Page 81 Control unit Communication card A22 This card is used to send and receive signals from I/0 card 2. It contains: • Input/output connection blocks Communication card A22 Card No. Function Output (200 - 240 V AC) Liquid detergent 5 Liquid detergent 6 Liquid detergent 7 Liquid detergent 8 Drain block Drain A...
Page 83: Programme Unit
Programme unit Programme unit Description I/O card 2 A12 The programme unit of the machine consists of the following parts: • CPU card A1 I/O card 1 A11 The CPU card uses the various control pro- grammes in the card programme memory to check all the functions of the washing CPU card A1 machine.
Page 84 Programme unit • I/O cards A11 and A12 Most smaller machines have only one card: A11. On some machines, there is a greater need for outputs, in which case two I/O cards are used. The I/O cards are controlled by the CPU card via a serial interface. The I/O cards feature outputs, which, via the communication cards in the rear electric box, control various machine functions, such as the wa- ter valves, heater connection and drain valve.
Page 85: Cpu Card A1
Programme unit CPU card A1 The CPU card controls all functions of the washing machine using various control programmes in the CPU card memory. The CPU card communi- cates with the I/O card, display card and motor controller using a serial interface.
Page 86 Programme unit Press button 2 to confirm changes made in Configuration 1 and 2. The two pins in switch X7 are shorted to confirm changes made in Configuration 1 and 2. (Not for FOM71 CLS). Pushbutton SW1 / SW2: used as an acknowledge- ment button when in the Service programme mode P1, P2 Used for (the same function is also available on the...
Page 87: Display Card A2
Programme unit Display card A2 The display card communicates with the CPU card through a serial interface. The CPU card informs what should be displayed in the display window and the display card converts these messages to information that controls the alphanumeric display window. The display card also detects which buttons are pressed on the con- trol panel and sends these signals to the CPU card.
Page 88: I/O Cards
Programme unit I/O cards The I/O cards are controlled by the CPU card and communicate via a serial interface. Depending on the need for inputs and outputs, one programme unit may have one or two I/O cards. All inputs and outputs are switched from the I/O card to the various functions via the communication cards in the rear electric module.
Page 89: Input And Outputs On I/O Cards 1 And 2
Programme unit Input and outputs on I/O cards 1 and 2 Card switch I/O-card 1 A11 I/O-card 2 A12 Serial interface and voltage supply X1: 1-3 Serial interface to card 2 16 V+ supply to card 2 0 V– supply to card 2 X2: 1 0 V– supply to CPU 12 V- from card 1 16 V+ supply to CPU 12 V+ supply from card 1 3-5 Serial interface to CPU Serial interface to card 1 X3: 1...
Page 90 Programme unit Inputs and outputs on I/O cards 1 and 2 I/O-card D.card A21 I/O-card 1 A11 Connection block No. Switch No. Relay No. Function Outputs X4: 1 Neutral Door lock relay, phase (normally open) Neutral Door lock relay, phase (normally open) X7: 1 Drain 1 (Y1), phase (normally open) Common neutral Drain 1 (D1), phase (normally closed)
Page 91 Programme unit Inputs and Outputs on I/O card 1 and 2 I/O-card D.card A22 I/O-card 2 A12 Connection block No. Switch No. Relay No. Function Outputs X4: 1 X77:1 Flashlight, phase X7: 1 Cold, hard water (Y35) N (neutral) X8: 1 Heater relay (K22) Neutral X9: 1 X76:8...
Page 92 Programme unit I/O-card D.card A21 I/O-card 1 A11 Connection block No. Opto-coupler Relay No. Function Inputs X5: 1 Door lock micro-switch S4/N, Com Door lock micro-switch S4/N, No 3-4 Door lock position micro-switch S3/N 5-6 Door lock micro-switch S4/Phase X15:1 X70:4 External start/stop signal, phase External start/stop signal, neutral External pause signal, phase External pause signal, neutral X16:1-2 ACK, emergency stop (S2) 3-4 External service switch 5-6 7-8...
Page 93 Programme unit I/O-card D.card A22 I/O-card 2 A12 Connection block No. Opto-coupler Relay No. Function Inputs X5: 1 3-4 5-6 X15:1 X74:2 Switch heat 1/heat 2, phase Switch heat 1/heat 2, neutral X16:1-2 3-4 5-6 7-8...
Page 94: The Service Program
Programme unit The service program The service programme facilitates troubleshooting on the machine by enabling control of all machine functions. Input signals to the various I/O cards that are active are also indicated. The following functions can be controlled: COLD WATER LOW EXTRACT HOT WATER MEDIUM EXTRACT...
Page 95: To Select The "Service Program" Function
Programme unit To select the ”Service Program” function The service program The service program makes fault-finding on the machine easier, as it allows you to control the If this menu is not currently various machine functions individually: displayed: • water filling RUN A WASH PROGRAM Press repeatedly. GO TO THE MENU • detergent flushing MAKE YOUR CHOICE WITH...
Page 96 Programme unit To prevent unauthorised or accidental use Unauthorised or accidental use of the service program is prevented by requiring the user to locate PRESS BUTTON ON Press the button on the and press the button on CPU board. CPU BOARD CPU circuit board.
Page 97: To Control The Machine Functions
Programme unit To control the machine functions SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED 01 COLD WATER 02 HOT WATER 03 COLD HARD WATER 04 TANK 1 WATER 05 TANK 2 WATER 06 TANK 3 WATER To activate the various 01 COLD WATER machine functions: 02 HOT WATER...
Page 98: I/O Card Inputs
Programme unit I/O card inputs Press 1. Now you can check the SERVICE PROGRAM various input signals from I/O LEVEL TEMP 22°C SPEED board 1. DRAIN CLOSED EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED REMOTE START UNBALANCE A black square in front of the SERVICE PHASE CHECK name indicates that the input...
Page 99: Settings 1
Programme unit Settings 1 In the Configuration 1 mode, the variables can be changed without requesting a special password from the supplier: ADJUST TIME ALLOWED LEVEL HIGH MIDDEL TEMPERATURE COOL-DOWN ADJUST TEMPERATURE ALLOWED RAPID ADVANCE ALLOWED DEFAULT MOTOR ON TIME DEFAULT MOTOR OFF TIME SHOW WEIGHT ALLOWED WATER REDUCTION NOT ALLOWED FLUSH DELAY TIME...
Page 100: To Select The "Settings 1" Function
Programme unit To select the ”SETTINGS 1” function If this menu is not currently RUN A WASH PROGRAM displayed: GO TO THE MENU Press repeatedly. MAKE YOUR CHOICE WITH AND PRESS SELECT WEIGHT, KG 000,0 SELECT Press to highlight ”GO TO THE MENU”.
Page 101: Password
Programme unit Password Password protection or not? It is for you to decide whether or not the functions To open the function without a password SETTINGS 1 and PROGRAMMING will be pass- word-protected. Please note that if you do decide to implement password protection for either of SETTINGS 1 them, then access to both these functions will be by means of the same password.
Page 102 Programme unit To change the password SETTINGS 1 PLEASE ENTER YOUR PASSWORD: ENTER NEW PASSWORD: Enter your four-digit pass- word. Once the correct password has been entered, the display and SELECT. will show Press Enter the new four-digit password. SELECT Press SELECT.
Page 103: Variables Under "Settings 1
Programme unit Variables under ”SETTINGS 1” When the top line of a menu SETTINGS 1 is highlighted you have the option of scrolling down ADJUST TIME ALLOWED ADJUST TEMPERATURE ALLOWED through the menu faster by RAPID ADVANCE ALLOWED MANUAL FUNCTIONS ALLOWED pressing .
Page 104 Programme unit Altering ”step time” allowed ADJUST TIME ALLOWED Here you determine if manual adjustment of the ADJUST TEMPERATURE ALLOWED remaining ”step time” (by using to move to RAPID ADVANCE ALLOWED the line for ”STEP TIME” then entering a new time) SHOW WEIGHT ALLOWED will be allowed.
Page 105 Programme unit Rapid advance allowed ADJUST TIME ALLOWED Here you determine whether it is allowed to use ADJUST TEMPERATURE ALLOWED rapid advance forwards or backwards through the RAPID ADVANCE ALLOWED wash program during program operation. SHOW WEIGHT ALLOWED WATER REDUCTION NOT ALLOWED 991 NORMAL 95°C STD MANUAL FUNCTIONS ALLOWED PROGRAM STEP: MAIN WASH...
Page 106 Programme unit For machines with weight measurement installed only! Water reduction not allowed ADJUST TIME ALLOWED If the weight measurement function is installed, ADJUST TEMPERATURE ALLOWED the water level will be reduced automatically if the RAPID ADVANCE ALLOWED machine does not have a full load. SHOW WEIGHT ALLOWED Here you determine whether it will be possible to WATER REDUCTION NOT ALLOWED...
Page 107 Programme unit ADJUST TIME ALLOWED ADJUST TEMPERATURE ALLOWED Pause allowed RAPID ADVANCE ALLOWED Here you determine whether it is allowed to use SHOW WEIGHT ALLOWED the pause function during the wash program. This WATER REDUCTION NOT ALLOWED function will not work until the second time the MANUAL FUNCTIONS ALLOWED program is run.
Page 108 Programme unit ADJUST TIME ALLOWED Changing wash program allowed ADJUST TEMPERATURE ALLOWED Here you determine whether it is allowed to chan- RAPID ADVANCE ALLOWED ge to a different wash program during program SHOW WEIGHT ALLOWED operation. WATER REDUCTION NOT ALLOWED MANUAL FUNCTIONS ALLOWED 991 NORMAL 95°C STD PAUSE ALLOWED...
Page 109 Programme unit RAPID ADVANCE ALLOWED Altering extraction speed allowed SHOW WEIGHT ALLOWED Here you determine whether it is allowed to alter WATER REDUCTION NOT ALLOWED the extraction speed during the current extraction MANUAL FUNCTIONS ALLOWED sequence by using to move to the DRUM PAUSE ALLOWED SPEED line and entering a new value.
Page 110 Programme unit MANUAL FUNCTIONS ALLOWED Display actual temperature FREE TEXT ALLOWED Here you determine whether the actual water tem- CHANGE WASH PROGRAM ALLOWED perature will be displayed during the program. AUTO RESTART ALLOWED ADJUST SPIN SPEED ALLOWED. DISPLAY REMAINING TIME 991 NORMAL 95°C STD DISPLAY ACTUAL TEMPERATURE PROGRAM STEP: MAIN WASH...
Page 111 Programme unit Machine not heated Here you determine if the machine is to heat the water to the required temperature before the time CHANGE WASH PROGRAM ALLOWED the wash sequence starts, or if the wash time of AUTO RESTART ALLOWED the sequence is to begin directly after water filling.
Page 112 Programme unit ADJUST SPIN SPEED ALLOWED. DISPLAY REMAINING TIME DISPLAY ACTUAL TEMPERATURE Temperature in °C DISPLAY ACTUAL SPEED Here you determine if all temperatures are to be MACHINE NOT HEATED shown in °C or °F. TEMPERATURE CONTROL OF WATER If you answer Yes (Y): TEMPERATURE IN °C REPEAT PROGR.
Page 113 Programme unit DISPLAY ACTUAL TEMPERATURE DISPLAY ACTUAL SPEED MACHINE NOT HEATED No access to standard programs TEMPERATURE CONTROL OF WATER Here you determine whether the user will have ac- TEMPERATURE IN °C cess to the machine’s standard programs (numbe- REPEAT PROGR. MODE QUESTION red 991-999) or not.
Page 114 Programme unit MACHINE NOT HEATED TEMPERATURE CONTROL OF WATER TEMPERATURE IN °C Water level after unbalance halt REPEAT PROGR. MODE QUESTION Here you determine the water level to which LOCKED STANDARD WASH PROGRAMS N the machine fills after a halt in extraction due to LEVEL QUICK COOL-DOWN unbalance.
Page 115 Programme unit Middle temperature cool-down LEVEL QUICK COOL-DOWN Here you determine the middle temperature for cool-down. LEVEL UNBALANCE LEVEL LOW When creating a new wash program you can, to LEVEL MEDIUM prevent creasing of the load, use the COOL-DOWN LEVEL HIGH module to achieve controlled cool-down of the wa- MIDDLE TEMPERATURE COOL-DOWN 70 ° ter in the drum. The cool-down sequence is divided into two stages: DEFAULT MOTOR ON TIME 0:12 DEFAULT MOTOR OFF TIME...
Page 116 Programme unit LEVEL UNBALANCE LEVEL LOW LEVEL MEDIUM LEVEL HIGH MIDDLE TEMPERATURE COOL-DOWN 7 0 °C DEFAULT MOTOR ON TIME 0:12 Flush times DEFAULT MOTOR OFF TIME 0:03 Here you determine times relating to flushing clean FLUSH DELAY TIME 0:06 the supply lines of an external system for liquid de- FLUSH ON TIME 0:10 tergent: the delay time and the length of time ”on”.
Page 117 Programme unit Maximum filling time BUZZER ON BUTTON MAX FILLING TIME 10:00 Here you determine the maximum time to be al- MAX HEATING TIME 10:00 lowed for filling the machine with water to the level set. SHOW WEIGHT TIMEOUT 0:20 PC5 BLOCKING OF HEATING If the correct level has not been reached within PC5 BLOCKING OF SPINNING...
Page 118 Programme unit Show weight timeout BUZZER ON BUTTON Here you determine the length of time the weight MAX FILLING TIME 10:00 will be displayed, before the normal display is MAX HEATING TIME 10:00 restored. SHOW WEIGHT TIMEOUT 0:20 PC5 BLOCKING OF HEATING CLARUS CONTROL PC5 BLOCKING OF SPINNING WEIGHT, KG:...
Page 119 Programme unit BUZZER ON BUTTON MAX FILLING TIME 10:00 MAX HEATING TIME 10:00 SHOW WEIGHT TIMEOUT 0:20 Relay for steam as standard PC5 BLOCKING OF HEATING PC5 BLOCKING OF SPINNING Here you decide if the machine should heat with HEAT 2 AS STANDARD steam or el.
Page 120 Programme unit Buzzer length at programme end Here you determine for how long the buzzer should sound at the end of the programme unless BUZZER TIMEOUT AT END 0:20 it is not turned off manually. When programming the main data for a washing programme, it is possible to select whether or not to sound the buzzer at the programme end. The buzzer is switched off by pressing a function but- ton on the control panel.
Page 121 Programme unit Password active Here you determine whether or not to set a pass- PASSWORD ACTIVE word according to the explanations. CMIS address Here you can give the machine a unique address CMIS ADDRESS when connected to the CMIS system. 0 = inactive Allowed values = 1-127. Level in mm active Y(es) = Pressure sensor system for water LEVEL IN MM ACTIVE filling active.
Page 122 Programme unit Start slow filling, hg START SLOW FILLING, HG When filling on weight, detergent valve 3 will be used to finalize the washer filling. Detergent valve 3 will be opened given value before the final level is reached. Offset level, hg Gives value will be subtracted from programing OFFSET LEVEL, HG water level before water filling starts.
Page 123 Programme unit To conclude making changes in variables To prevent inadvertent changes in variables under ”SETTINGS 1” If you have changed any variables under “Settings 1”, when you have finished keying in the changes, you need to insert a strap between two terminals on the CPU circuit board to register the changes in the SETTINGS 1 CPU.
Page 124: Settings 2
Programme unit Settings 2 In Configuration 2, there are variables that, in case of carelessness or lack of knowledge, may affect the safety systems or operating safety of the machine. Because of this, these variables are protected by a code system. Each time a variable needs to be changed, it is neces- sary to obtain a new code from the manufacturer.
Page 125: To Select The "Settings 2" Function
Programme unit To select the ”SETTINGS 2” function If this menu is not currently RUN A WASH PROGRAM displayed: GO TO THE MENU Press repeatedly. MAKE YOUR COICHE WITH AND PRESS SELECT WEIGHT, KG 000,0 SELECT Press to highlight ”GO TO THE MENU”.
Page 126: Variables Under "Settings 2
Programme unit Variables in Settings 2 SETTINGS 2 When the top line of a menu HEATING RELAY ON WHEN NOT HEATED is highlighted you have the TEMPERATURE INCREASE ALLOWED LEVEL EMPTY option of scrolling down LEVEL OVERFILL PAUSE TEST LEVEL through the menu faster by PAUSE TEST TEMPERATURE -18°C...
Page 127 Programme unit Heating relay on Here you determine whether the heating relay will HEATING RELAY ON IF NOT HEATED switch on when heating begins. TEMPERATURE INCREASE ALLOWED Note that the heating relay switches on even if the LEVEL EMPTY answer ”Yes” is in place for the function ”MACHI- LEVEL OVERFILL NE NOT HEATED”...
Page 128 Programme unit Level empty HEATING RELAY ON IF NOT HEATED Here you determine the water level at which the TEMPERATURE INCREASE ALLOWED drum will be regarded as empty. LEVEL EMPTY It is advisable to set this level so that the inner LEVEL OVERFILL drum will have emptied, but so that some water PAUSE TEST LEVEL...
Page 129 Programme unit Test values for pause HEATING RELAY ON IF NOT HEATED Here you determine whether, and if relevant, the TEMPERATURE INCREASE ALLOWED conditions under which it will be allowed for the LEVEL EMPTY user to open the door during a wash program, for LEVEL OVERFILL example to take samples of the water.
Page 130 Programme unit Temperature step in cool-down HEATING RELAY ON IF NOT HEATED Here you determine the maximum reduction in TEMPERATURE INCREASE ALLOWED temperature per minute during the first stage of LEVEL EMPTY cool-down. LEVEL OVERFILL PAUSE TEST LEVEL How does cool-down work? PAUSE TEST TEMPERATURE -18 °C When creating a new wash program you can,...
Page 131 Programme unit PAUSE TEST LEVEL PAUSE TEST TEMPERATURE -18 °C DEFAULT TEMPERATURE HYSTERIS 4 °C TEMPERATURE STEP IN COOL-DOWN 4 °C DEFAULT LOW EXTRACT TIME 00:00 DEFAULT MEDIUM EXTRACT TIME 00:00 Default values for re-start after unbalance DEFAULT HIGH EXTRACT TIME 00:00 Here you determine the drain time and distribu- DEFAULT DRAIN TIME 00:00 tion time the machine will use if it cannot find the...
Page 132: Drain Time
Programme unit Drain open delay Here you determine whether you want a delay be- fore the drain valve opens, for example if you want the drum to have time to gather speed first, before the valve opens. TEMPERATURE STEP IN COOL-DOWN 4 °C The drain module DEFAULT LOW EXTRACT TIME 00:10 may be structured according to point 1 (here)
Page 133 Programme unit Rollout time Here you determine whether you want a time delay after each extraction before the machine starts to fill with water, to give the motor time to slow down. This function is useful if the motor is not a frequen- cy-controlled one.
Page 134 Programme unit DEFAULT HIGH EXTRACT TIME 00:20 DEFAULT DRAIN TIME 00:40 DEFAULT DISTR. TIME 00:30 DO UNBALANCE MEASUREMENT DRAIN OPEN DELAY 0:13 START EXTRACT TIME 00:30 Pay per wash ROLLOUT TIME 00:01 This question is for special installations with pay PAY PER WASH ALARM systems.
Page 135 Programme unit DO UNBALANCE MEASUREMENT Lock test delay DRAIN OPEN DELAY 0:13 Here you determine the length of time between START EXTRACT TIME 00:30 when the door is locked and when the check ROLLOUT TIME 00:01 should be made of the lock’s microswitch. PAY PER WASH ALARM LOCK TEST DELAY 0:10...
Page 136 Programme unit Time drain to open after over-filling DRAIN OPEN DELAY 0:13 Here you determine how long the drain valve START EXTRACT TIME 00:30 should open for if the machine has over-filled, ROLLOUT TIME 00:01 provided you ensure that the parameter (response) PAY PER WASH ALARM stored for the function ERROR OVER-FILLED is LOCK TEST DELAY 0:10 N (No) (see below).
Page 137 Programme unit PAY PER WASH ALARM LOCK TEST DELAY 0:10 DRAIN TIME WHEN OVERFILL 0:05 Oil lubrication OIL LUBRICATION HOURS PULSE TIME OIL LUBR. SEC 0:01 Here you determine the lubrication interval and AMOUNT OF I/O MODULES (1-3) pulse time for the oil lubrication systems used on larger washer extractors.
Page 138 Programme unit DRAIN TIME WHEN OVERFILL 0:05 Delay clear door text OIL LUBRICATION HOURS Here you determine how long the text ”WAITING PULSE TIME OIL LUBR. SEC 0:01 FOR DOOR TO UNLOCK” will remain visible if, for AMOUNT OF I/O MODULES (1-3) some reason, the door is not unlocked at the right DELAY CLEAR DOOR TEXT 04:00 time.
Page 139 Programme unit Timeout during pause OIL LUBRICATION HOURS PULSE TIME OIL LUBR. SEC 0:01 Here you determine the maximum time for a AMOUNT OF I/O MODULES (1-3) pause in the program, if it is to be available for use DELAY CLEAR DOOR TEXT 04:00 in calculating the average length of the program.
Page 140 Programme unit AMOUNT OF I/O MODULES (1-3) Door open delay for ”motor lost” DELAY CLEAR DOOR TEXT 04:00 Here you determine the length of time during MAX DRAIN TIME 4:00 which the door will be prevented from opening TIMEOUT DURING PAUSE 1:00 if, (in machines with frequency control) the MCU MINIMUM TEMPERATURE INCREASE 5°C loses control of braking at the end of extraction.
Page 141 Programme unit List of errors, functions monitored and relevant error messages displayed Error/Function Error message displayed 01 ERROR. NO WATER Water level has not reached set level within time set. NO WATER After this error message appears and the machine is reset, the machine will try again.
Page 142 Programme unit List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed 15 ERROR. EMERGENCY STOP The emergency stop button has been pressed. EMERGENCY STOP 16 ERROR. WEIGHT FROM SCALE Over-/Under-load of scale or weight above limit for maximum allowed WEIGHT FROM SCALE weight at wash module start. 17 ERROR.
Page 143 Programme unit List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed ERROR CODES FROM MOTOR This function includes a number of error warnings from the motor control system for frequency-controlled motors (EWD) 31 Temperature of MCU control circuits too high HEAT SINK TOO HOT 32 Motor thermal protection has tripped MOTOR TOO HOT...
Page 144 Programme unit ERROR, EWD INTERLOCK ERROR, I/O COMMUNICATION ERROR, LOW OIL LEVEL ERROR, LOW OR HIGH VOLTAGE ERROR, ERROR CODES FROM MOTOR ERROR, PRESS SENSOR TILT Time delay before door opening ERROR, PRESSURE SENSOR TIMEOUT Here you determine the length of time during which ERROR, DOOR SWITCH TILT the door will be prevented from opening if the ERROR, LEVEL OFFSET...
Page 145 Programme unit Upper limit for manual temperature ERROR, I/O COMMUNICATION adjustment (”Max adjust temperature”) ERROR, LOW OIL LEVEL Here you determine the highest temperature the ERROR, LOW OR HIGH VOLTAGE user may alter the wash temperature to manually ERROR, ERROR CODES FROM MOTOR (by using to move to the line for ERROR, PRESS SENSOR TILT...
Page 146 Programme unit ERROR, PRESS SENSOR TILT ERROR, PRESSURE SENSOR TIMEOUT ERROR, DOOR SWITCH TILT ERROR, LEVEL OFFSET ERROR, LEVEL SYSTEM NOT CALIB. TIME DELAY BEFORE DOOR OPENING 0:30 UPPER TEMPERATURE FOR ERROR 98°C LOWER TEMPERATURE FOR ERROR -9°C Default wash speed MAX ADJUST TEMPERATURE 97°C Here you determine the wash speed the machine MAXIMUM EXTRACT SPEED...
Page 147 Programme unit TIME DELAY BEFORE DOOR OPENING 0:30 Default value, extraction time UPPER TEMPERATURE FOR ERROR 98°C Here you determine the various speeds (low, me- LOWER TEMPERATURE FOR ERROR -9°C dium and high) for extraction. The instructions for MAX ADJUST TEMPERATURE 97°C determining the length of extraction times are to MAXIMUM EXTRACT SPEED 1200 be found earlier in SETTINGS 2.
Page 148 Programme unit START EXTRACT SPEED 1000 Default wash acceleration DEFAULT WASH ACCELERATION Here you determine the acceleration rate (rpm/ DISTRIBUTION ACCELERATION second) which the machine can use to reach wash RETARDATION ACCELERATION speed when it cannot find this value elsewhere, EXTRACT ACCELERATION e.g.
Page 149 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION Extraction acceleration DISTRIBUTION ACCELERATION Here you determine the acceleration rate (rpm/ RETARDATION ACCELERATION second) the machine will use to reach extraction EXTRACT ACCELERATION speed. This value is not programmable when START EXTRACT ACCELERATION you create a wash program.
Page 150 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION DISTRIBUTION ACCELERATION Extract retardation (i.e. Deceleration rate RETARDATION ACCELERATION after extraction) EXTRACT ACCELERATION START EXTRACT ACCELERATION Here you determine the deceleration rate (rpm/ EXTRACT RETARDATION second) at which the drum will slow down after MAX SPEED DURING FILLING extraction speed.
Page 151 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION DISTRIBUTION ACCELERATION RETERDATION ACCELERATION EXTRACT ACCELERATION START EXTRACT ACCELERATION EXTRACT RETARDATION MAX SPEED DURING FILLING Max level offs. for aut. calib. MAX LEVEL OFFS. FOR AUT. CALIB. Maximum level in SKD for automatic calibration. TIME AT DISTRIBUTION SPEED 2 NUMBER OF REDIST LOW 1 UNB.
Page 152 Programme unit NUMBER OF REDIST LOW 1 UNB. NUMBER OF REDIST LOW 2 UNB. NUMBER OF REDIST MEDIUM UNB. NUMBER OF REDIST HIGH UNB. NUMBER OF REDIST EXTREME UNB. Drain time at progr. end DRAIN TIME AT PROGR. START Drain time at program end after that the level is DRAIN TIME AT PROGR.
Page 153 Programme unit To conclude making changes in variables To prevent inadvertent changes in variables under ”SETTINGS 2” If you have changed any variables under “Settings 2”, when you have finished keying in the changes, you need to insert a strap between two terminals on the CPU circuit board to register the changes in the SETTINGS 2 CPU.
Page 154: To Replace The Cpu Board
Programme unit To replace the CPU board If the CPU board is faulty and has to be replaced. The correct software for the particular washer extractor has to be downloaded into the new timer. For this you need: 1. A new CPU circuit board. 2.
Page 155: To Replace An I/O Board
Programme unit To replace an I/O board The procedure described here is for machi- nes with more than one I/O board. On machines with only one I/O board, that board can be replaced without any need for this procedure. If there is more than one I/O circuit board, the processor must know whether the new circuit CPU circuit board board is I/O board 1, I/O board 2 or I/O board 3:...
Page 157: Door And Door Lock
Door and door lock Door and door lock General The door lock part consists of the following: Emergency opening button • Door lock A41 that contains - an actuator that locks the door lock and which also has two built-in micro switches, S4a and S4b. The actuator is bi-stable, i.e., it has two stable positions: locked door and unlocked door.
Page 158: The Door Lock Locks The Door
Door and door lock The door lock locks the door When the door is closed (closed door lock switch S3), the programme unit may request door locking by applying a voltage of 200-240 V on the door lock controller A31 input X92. Door lock The following check is made by the A31 card Programme control prior to locking of the door:...
Page 159: The Door Lock Unlocks The Door
Door and door lock The door lock unlocks the door The programme unit requests door unlocking by applying 0 V on input X92 of the door lock con- troller. The following check is made prior to unlocking Door lock of the door: Programme control unit A1...
Page 160: Error Codes
Door and door lock Error codes The door lock control has three LEDs that show whether the door lock operates normally or Reset button whether an error has been detected. During normal operation, the LEDs blink when the drum is not turning and are off when the drum rotates. In case of an error, the three LEDs will show the error condition according to the table below.
Page 161: Reset Button
Door and door lock Reset button The door lock control features a reset button Door lock control A31 used to reset the programme routines stored in the computer. When pressed, any error codes 200- 240 V are erased. Voltage Door lock control inputs/outputs supply to A1 Level guard X90: AC 200-240 V feed...
Page 162 Door and door lock X93: Input from level guard If the input indicates “Water in drum” when the Door lock control A31 door is not locked, the door cannot be locked. 200- The LEDs then show the error code l l m. 240 V Input voltage Function...
Page 163 Door and door lock X95: Input from rotation sensor on motor shaft When the motor is operating, a pulse train is Door lock control A31 applied on the input. Tacho generator Input Function Pin 1: Pin 2: Tacho signal X96: Output to door lock Unlocks + Locks Locks the door lock when the following condi-...
Page 164: Repairs
Door and door lock Repairs Repair work on the machine should only be done by specially trained personnel. Emergency opening of door lock 1. Take down power from the machine by tur- ning the main power switch to the 0 position. 2.
Page 165: Replacing The Door Lock
Door and door lock Replacing the door lock 1. Take down power from the machine by turning the main power switch to the 0 position. 2. Remove the front cover alt. side pole. 3. Remove the door (two screws in each hinge). 4.
Page 167: Motor And Motor Control
Motor and motor control Motor and motor control DANGER Be careful when measuring the electric components in the motor control. All components have a potential difference of approx. 300 V in relation to protective earth and neutral. When the green LED on the motor control card is lit, the components carry dangerous vol- tages.
Page 168: Motor
Motor and motor control Motor The motor is fitted in a bridge carrier under the outer drum. It drives the washing drum using a drive belt. The motor is frequency-controlled and is con- trolled by microcomputer control. The vari- ous speeds for normal operation, distribution speeds and extraction as well as acceleration/ retardation can be controlled with a high de- gree of precision.
Page 169: Motor Control
Motor and motor control Motor control The motor control unit is microcomputer con- Motor control U1 trolled and is situated under the top cover of the machine, right above the outer drum. The unit consists of a PCB (mother board) fitted on a heat sink that does double-duty as part of the housing.
Page 170: Function
Motor and motor control Function DANGER Be careful when measuring the electric components in the motor control. All components have a potential difference of approx. 300 V in relation to protective earth and neutral. When the green LED on the motor control card is lit, the compo- nents carry dangerous voltages.
Page 171: Inputs And Outputs
Motor and motor control The motor control is also able to deliver various instantaneous and output values during con- stant speed, acceleration and retardation. These values are used to calculate the weight of the loaded laundry and to detect any load imbalan- ces.
Page 172 Motor and motor control X304: Door lock connector The collector output function is controlled from the programme unit (X301). The collector output X311 does not switch on if there is no communication with the programme unit. Tacho signal from the motor (via door lock con- trol A31) is needed to control the motor.
Page 173 Motor and motor control X312: AC supply to motor and input from the motor thermal protector The motor is fed with alternating current with va- rying frequency that is proportional to the motor speed. This connector also includes the input from the thermal protector of the motor.
Page 174: Led Indicatioins
Motor and motor control LED indications Two LEDs, one yellow and one green, indicate any errors on the motor controller and motor. The table below shows the blinking patterns of the various error codes. Green LED LED blinking pattern Cause OK blink (brief pause every 5 seconds) Microcomputor in motor control unit not working, voltage is on.
Page 175: Repairs
Motor and motor control Repairs Main power switch Repair work on the machine should only be done by specially trained personnel. Motor replacement Disassembly 1. Swith off power to the machine by turning the main power switch to the 0 position. 2.
Page 176 Motor and motor control Assembly 1. Fit the new motor without locking the mounting bolts. 2. Fit the drive belt and adjust the belt tension with the tensioner on one side of the motor. Se section Adjustments - Drive belt tension for de- tails. 3. Connect the new motor to the motor control and use straps to secure the cable.
Page 177: Adjustments
Motor and motor control Adjustments Drive belt tension The drive belt is pre-tensioned upon delivery from the factory. The drive belt tension should be as follows: Model Force A Post tensioning B New belt C inch (mm) inch (mm) SU620 3/8"...
Page 179: Drain Valve
Drain valve Drain valve Description The drain valve is situated on a flange at the bot- tom of the outer drum and can be accessed from the front after removing the front cover. The drain valve consists of the following principal parts: • Lower part with rubber diaphragm. • Piston and cylinder. • Pressure plate and recoil springs. • Rubber diaphragm with drain connection. • Upper part with connection for outer drum.
Page 180: Repairs
Drain valve Repairs Main power switch Repair work on the machine should only be done by specially trained personnel. Disassembly For repair works on the drain valve, there is a risk that water still left in the machine may flood onto the floor. Be sure to dry up any spilled water since it may cause people to 5468 slip and hurt themselves.
Page 181: Assembling
Drain valve Assembling 1. Connect the pressure hose to the lower part of the valve. Verify that the hose is not bent or pinched. 2. Fit the rubber bellows onto the sleeve coupling. 3. Hook the valve onto the bolts and turn the valve into position. Secure the 4 retaining bolts of the valve.
Page 183: Detergent Compartment
Detergent compartment Detergent compartment Description Detergent compartment The detergent compartment of the machine is designed for use with powder and liquid deter- gent. The compartment is divided into four sub- compartments as follows: • Compartment 1 - For pre wash with powder or liquid detergent. • Compartment 2 - For main wash with deter- gent powder. • Compartment 3 - Rinse. • Compartment 4 - Main wash with liquid de- tergent or, bleaching-agent. The connections for incoming water are situated on the rear side of the compartment.
Page 185: Heating
Heating Heating Electric heating Heating contactor The heating system of the machine consists of: • Three heating elements for heating the water in the drum. • A temperature sensor to detect the water temperature in the drum. 5365 • One or two heating contactors for switch-on/ switch-off of the heating elements. The heating elements and the temperature sen- sor are situated at the bottom of the outer drum close to the edge. They can be accessed front the front after the front plate is removed. The contactor(s) is(are) placed in the rear control unit. Depending on the size of the machine, the fol- lowing heating elements are available: Machine Heating element size model (kW) SU620 3 x 1, 3 x 1.8, 3 x 2.5 SU630 3 x 3.3 SU645 3 x 4.33 SU660 3 x 6...
Page 186: Repairs
Heating Repairs Main power switch Repair work on the machine should only be done by specially trained personnel. Replacing the heating elements When replacing the heating elements, there is a risk that water still left in the machine may flood onto the floor. Be sure to dry up any spilled water since it may cause people to slip and hurt themselves.
Page 187: Regular Maintenance
Regular maintenance Regular maintenance To maintain correct and proper functioning and to prevent interruption of service, the following maintenance scheme should be adhered to. The maintenance interval should be adapted to how frequently the machi- ne is used. Daily • Check the door and door lock: - Let the door remain open and try starting the machine. The machine should not start.
Page 188 Regular maintenance - Verify that all internal hoses do not leak. - Inspect the drive belt. Adjust the tension or replace if necessary. - Check that water does not leak onto the floor. - If the heating time is unusually long, check the heating elements. If the water is very hard, check whether there are lime deposits on the heating elements. Decalcify the elements if necessary. Adapt the amount of deliming agent to the manufacturer’s guidelines. - Never switch on the heating elements when there is no water in the machine. This will cause the slow-blow fuse to trigger.
Page 189 BuiLd a neW Laundry WiTh LoW-cosT financinG or LeasinG from WascomaT* With Wascomat/viking financing or leasing you can obtain and install durable, efficient, state-of-the-art Wascomat washers, dryers and non-polluting, environmentally-friendly wetcleaning equipment to meet all anti-pollution regulations.
Page 190 Coin operated and commercial wetcleaning need. energy and gas efficient, user With the push of a button, the unique Wascomat friendly TD dryer models with optional unique “Dual-Use” Wetcleaner converts to an ideal laundry Wascomat washer for washing shirts, comforters, drapes, all Residual Moisture Control (RMC).

This manual is also suitable for:

Clarus control su630 Clarus control su645 Clarus control su662 Clarus control su677 Clarus control su620cl Clarus control su677cl

Wascomat Clarus Control SU620 Service Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Wascomat Clarus Control SU620

Summary of Contents for Wascomat Clarus Control SU620

This manual is also suitable for:

Table of Contents
