Wascomat WLD720 Installation Manual

Wascomat WLD720 Installation Manual

Washer - light dry
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation manual
Washer — Light Dry
WLD720, WLD725, WLD730,
WLD745, WLD762, WLD777
Type W3...
438905536/US
2022.11.18
Wascomat Commercial Laundry Equipment
516-371-4400 www.wascomat.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the WLD720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wascomat WLD720

Summary of Contents for Wascomat WLD720

  • Page 1 Installation manual Washer — Light Dry WLD720, WLD725, WLD730, WLD745, WLD762, WLD777 Type W3... 438905536/US 2022.11.18 Wascomat Commercial Laundry Equipment 516-371-4400 www.wascomat.com...
  • Page 2 WARRANTY CLAIMS Wascomat’s Technical Support Staff will honor valid manufacturer’s parts warranty claims providing your Wascomat machines are registered for warranty coverage upon installation. If they are not registered, you can validate your warranty claim by providing information about when and where you purchased the Wascomat machine(s), the model and serial number(s).
  • Page 3 Safety WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR MACHINE. MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE REFERENCE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
  • Page 4 Safety IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, including the following: 1. Read all instructions before using the appliance. 2. This machine must be securely bolted to an uncovered concrete floor. 3.
  • Page 5 Safety NOTICE TO: OWNERS, OPERATORS AND DEALERS IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY. TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS. Prior to operation of the machine, check to make certain that all operating instructions and warning signs are affixed to the machine and legible.
  • Page 6 Safety AVERTISSEMENT : TOUTES LES PROCÉDURES DE FONCTIONNEMENT ET DE MAINTENANCE INDIQUÉES À LA PAGE SUIVANTE DE CE MANUEL DOIVENT ÊTRE SUIVIES QUOTIDIENNEMENT POUR GARANTIR LE BON FONCTIONNEMENT DE VOTRE MACHINE. GARDEZ CE MANUEL DANS UN ENDROIT SÉCURISÉ POUR RÉFÉRENCE ULTÉRIEURE. VEUILLEZ ÉCRIRE LES INFORMATIONS SUIVANTES QUI FIGURENT SUR LA OU LES PLAQUES SIGNALÉTIQUES DE LA OU DES MACHINES.
  • Page 7 Safety INSTRUCTIONS DE SÉCURITÉ IMPORTANTES AVERTISSEMENT - Pour réduire le risque d'incendie, de choc électrique ou de blessures aux personnes lors de l'utilisation de votre appareil, y compris les points suivants : 1. Lisez toutes les instructions avant d'utiliser l'appareil. 2.
  • Page 8 Safety NOTICE POUR : LES PROPRIÉTAIRES, OPÉRATEURS ET REVENDEURS UNE INSTALLATION INCORRECTE, UNE MAINTENANCE INADÉQUATE, UN MAUVAIS ENTRETIEN MÉNAGER ET LA NÉGLIGENCE VOLONTAIRE OU LE CONTOURNEMENT DES DISPOSITIFS DE SÉCURITÉ PEUVENT ENTRAÎNER DES ACCIDENTS OU DES BLESSURES GRAVES. POUR ASSURER LA SÉCURITÉ DES CLIENTS ET/OU DES OPÉRATEURS DE VOTRE MACHINE, LES CONTRÔLES DE MAINTENANCE SUIVANTS DOIVENT ÊTRE EFFECTUÉS SUR UNE BASE QUOTIDIENNE.
  • Page 9 Safety ADVERTENCIA: TODOS LOS PROCEDIMIENTOS DE MANEJO Y MANTENIMIENTO QUE APARECEN EN LA SIGUIENTE PÁGINA DE ESTE MANUAL DEBERÁN SEGUIRSE DIARIAMENTE PARA EL CORRECTO FUNCIONAMIENTO DE LA MÁQUINA. ASEGÚRESE DE CONSERVAR ESTE MANUAL EN UN LUGAR SEGURO PARA CONSULTARLO EN EL FUTURO.
  • Page 10 Safety INSTRUCCIONES IMPORTANTES SOBRE SEGURIDAD ADVERTENCIA: Para reducir el riesgo de incendio, descarga eléctrica o lesiones personales al utilizar el dispositivo, incluyendo lo siguiente: 1. Lea las instrucciones antes de utilizar el dispositivo. 2. Esta máquina debe fijarse de forma segura a un suelo de hormigón visto. 3.
  • Page 11 Safety AVISO PARA: PROPIETARIOS, OPERADORES Y DISTRIBUIDORES UNA INSTALACIÓN INCORRECTA Y UN MANTENIMIENTO INADECUADO, UNA MALA CONSERVACIÓN Y LA OMISIÓN DELIBERADA O PUENTEO DE LOS DISPOSITIVOS DE SEGURIDAD PODRÍA RESULTAR EN ACCIDENTES O LESIONES GRAVES. PARA GARANTIZAR LA SEGURIDAD DE LOS CLIENTES Y/O LOS OPERADORES DE SU MÁQUINA, DEBERÁN REALIZARSE LAS COMPROBACIONES DE MANTENIMIENTO SIGUIENTES A DIARIO.
  • Page 12 Improper fastening of this machine to its foundation, inferior foundation materials, an undersized foundation, the use of fabricated steel bases not provided by Wascomat or its approved supplier(s), the use of an improper type, number, or size of mounting bolts, or failure to use proper hardware on mounting bolts may result in damage to the machine that will not be covered by the manufacturer's warranty.
  • Page 13 Contents 1 Safety Precautions ..........................15 General safety information......................15 Commercial use only........................15 Symbols..........................16 2 Technical data...........................17 Drawing ..........................17 2.1.1 WLD720, WLD725 ......................17 2.1.2 WLD730 ........................18 2.1.3 WLD745 ........................19 2.1.4 WLD762, WLD777 ......................20 Technical data .........................21 Connections ..........................22 3 Setup ...............................23 Unpacking ..........................23 Recycling instruction for packaging ...................24...
  • Page 15 • The openings in the base, shall not be obstructed by a carpet. • Maximum mass of dry cloth: WLD720: 9 kg / 20 lbs, WLD725: 11 kg / 25 lbs, WLD730: 14 kg / 30 lbs, WLD745: 20 kg / 45 lbs, WLD762: 28 kg / 62 lbs, WLD777: 35 kg / 77 lbs.
  • Page 16 Installation manual 1.3 Symbols Caution Caution, high voltage Read the instructions before using the machine...
  • Page 17 2 Technical data 2.1 Drawing 2.1.1 WLD720, WLD725 fig.X01719 Operating panel Door opening, WLD720: ⌀ 310 mm / 12 3/16 inch, WLD725: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply...
  • Page 18 Installation manual 2.1.2 WLD730 fig.X01720 Operating panel Door opening, WLD730: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection inch WLD730 1220 1335 28 3/8 31 1/8 48 1/16 14 9/16...
  • Page 19 Installation manual 2.1.3 WLD745 fig.X01721 Operating panel Door opening, WLD745: ⌀ 395 mm / 15 9/16 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection inch WLD745 1345 1435 1050 29 1/2 52 15/ 17 5/16 20 1/4...
  • Page 20 Installation manual 2.1.4 WLD762, WLD777 fig.X01722 Operating panel Door opening, WLD762, WLD777: ⌀ 435 mm / 17 1/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection inch WLD762 1030 1430 1590 1135 32 11/...
  • Page 21 Installation manual 2.2 Technical data WLD720 WLD725 WLD730 WLD745 WLD762 WLD777 Weight, net Drum volume litres 11.7 Drum diameter inch 20 1/2 23 7/16 23 7/16 25 9/16 28 9/16 31 5/16 Drum speed during wash Drum speed during extraction G-factor, max.
  • Page 22 Installation manual 2.3 Connections WLD720 WLD725 WLD730 WLD745 WLD762 WLD777 Water valves 3/4” 3/4” 3/4” 3/4” * 3/4” 3/4” Recommended water pressure 200–600 200–600 200–600 200–600 200–600 200–600 30–90 30–90 30–90 30–90 30–90 30–90 Continuous operating pressure 50–800 50–800 50–800 50–800...
  • Page 23 Installation manual 3 Setup 3.1 Unpacking Note! For WLD730–WLD777 two persons are recommended for the unpacking. Remove the front and rear panel. Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another diagonally opposed to it, at the back of the machine.
  • Page 24 Installation manual 3.2 Recycling instruction for packaging fig.X02395 Fig. Description Code Type Wrapping film LDPE 4 Plastics Corner protection PS 6 Plastics Cardboard packaging PAP 20 Paper Pallet FOR 50 Wood Screw FE 40 Steel FE 40 Steel Plastic bag PET 1 Plastics...
  • Page 25 Installation manual 3.3 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will prevent easy access for maintenance and service operations.
  • Page 26 The following table shows the drilling points. 4-M16 (5/8") Ø 18 (11/16") 125 (5") Ø 10 (3/8") 50 (1 15/16") 2-M10 (3/8") fig.5989E inch WLD720 28 9/16 19 17/32 17 7/16 4 1/2 26 3/16 WLD725 693.1 27 7/8 28 3/8...
  • Page 27 Installation manual After the machine has been placed over the other four M16 bolts, at the expansion M10 bolts (1) (only valid for WLD777), place the two square spacers (t = 4 mm / 3/16 inch) over the two holes. They shall be placed between the machine and foundation.
  • Page 28 Installation manual 3.4.1 Casting a plinth A plinth should be used where the existing floor is less than 200 mm / 7 7/8 inch thick or in order to ensure that the machine is above the level of any water leakages. The plinth should be approximately 150 - 200 mm / 5 7/8 —...
  • Page 29 Installation manual 3.4.2 Chemical bolts / chemical anchors An alternative to breaking up the existing floor or foundation is to use chemical bolts M16. 1. Mark and drill four holes (⌀ 18 mm / 11/16 inch) 125 mm / 5 inch deep for the chemical bolts. Check the previous table for the correct position of the holes.
  • Page 30 Installation manual fig.7644C...
  • Page 31 The table shows the possible connection options, which will depend on the water types to be con- nected to the machine. Information is also available on the panel above the connections. Water type Water connection WLD720, WLD725, WLD730 WLD720, WLD725, WLD730 N7–75, N7–85, N7–105, N7–130 N7–75, N7–85, N7–105, N7–130 •...
  • Page 32 Installation manual Water-inlet fittings have either 3/4” NH (garden hose) or DN20 (3/4” BSP) threads. All models except WLD745 have 3/4" NH threaded on all inlet valves. On WLD745 there are DN20 (3/4” BSP) threaded at position (1), (2) and another one at position 3 which is 3/4” NH threaded.
  • Page 33 B = ⌀ 6 mm / 1/4 inch (used for external dosing systems only). C = Only used for external liquid manifold. (Separate instructions enclosed when ordering). WLD720, WLD725 WLD730, WLD745, WLD762, WLD777 Always connect hoses on connections (A) with a hose clamp.
  • Page 34 Installation manual 5.2 Electrical connection of external dosing system The power supply to the external dosing system must never be connected to the machine’s incoming terminal block or to the edge connectors on the I/O-board. 5.2.1 Machine with connectors Connect the external dosing system to connections A and B on the machine. Connect the signal cable to B and the power supply to A.
  • Page 35 Installation manual 5.2.2 Machine without connectors Connect the external dosing system to the I/O board, which is located to the right of the incoming power supply. The I/O board has edge connectors for connecting external dosing systems. Edge connectors on the I/O board can be loosened for connecting cables. fig.6572 11 = N 18 = Program run...
  • Page 36 Installation manual 5.2.3 Outputs Connect the power supply (e.g. 24V DC) for the external liquid supplies to 9 and 10. If an internal power supply (from the machine) is being used, it can be taken from 1 (N) and connected to 9 and from 2 (L) and connected to 10. Max load on the outputs 0.5 A.
  • Page 37 Installation manual 5.2.4 Inputs The signal level can be 5-24V DC/AC or 100- 240V AC. For 5-24V, the signal reference is connected to 3 and for 100-240V to 4. Potentials on the inputs cannot be mixed. Note! The I/O board will be damaged if the voltage on connection 3 is too high > 24V. Connection 8 may be connected if the program is to pause, e.g.
  • Page 38 Avoid sharp bends which may prevent proper draining. fig.5330 Drain pump (for models WLD720, WLD725) The drainage pipe should be located over a floor drain, drainage channel or the like. The highest part of the drain hose shall be positioned according to the figure.
  • Page 39 Installation manual 7 Electrical connection 7.1 Electrical installation The electrical installation may only be carried out by qualified personnel. Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break- er. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary but is recommended.
  • Page 40 Installation manual 7.2 Electrical connections WLD720 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 1~ 3.0/5.4/7.5 3.4/5.7/7.8 20/30/40 208-240V 3~ 3.0/5.4/7.5 3.4/5.7/7.8 15/20/25 440V 3~ 5.4/7.5 5.7/7.9 15/15 480V 3~ 5.4/7.5 5.7/7.9...
  • Page 41 Installation manual WLD762 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 3~ 18.0 18.8 440V 3~ 18.0 18.8 480V 3~ 18.0 18.8 Non heated/Steam heated 120/440/480V 1~ 208-240V 1~ Total power and recommended fuse does not depend on the heating power in those cases. WLD777 Electrical connections Heating alternative...
  • Page 42 Installation manual 7.3 Machine connection Connect the earth and other two wires as shown. Single-phase connection Three-phase connection 1N/1 L2/N L2 L3...
  • Page 43 Installation manual 7.4 Machine connection with ferrite 7.4.1 WLD762, WLD777 To obtain approved level of EMC, it is mandatory to use the ferrite which is enclosed with above listed models. (Note that this is only valid for those models). Before connecting to the machine, the protective earth (PE) wire shall be wrapped around the ferrite. Prepare the power cord by making sure the protective earth (PE) wire is longer than the other wires according to the table.
  • Page 44 Installation manual 7.5 Functions for I/O-cards The electrical schematic can be one of the following: 7.5.1 External coin meter/Central payment (2A) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.6606A...
  • Page 45 Installation manual 7.5.2 Central payment (2B) To start the machine from a central payment system, the payment system must transmit a start pulse to the machine. The start pulse can be either 230V or 24V. In order to receive a feedback signal once the machine has started, 230V or 24V must be connected to connection 19.
  • Page 46 Installation manual 7.5.3 Central payment (2C) The central payment or booking system shall transmit an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the machine door is closed but the program has not started.
  • Page 47 Installation manual 7.5.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price reduction (2D) The figure shows standard function addressing for machines with the coin program package. By maintaining an active (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day.
  • Page 48 Installation manual 7.5.5 Central booking/payment (2F) The central payment or booking system shall provide an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the program is running.
  • Page 49 Installation manual 7.5.6 Machines with I/O module type 3 By maintaining an active (high) signal on connection 3 "Price reduction”, the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. Whilst the sig- nal remains active (high), the price of the program is reduced by the percentage entered in the price programming menu.
  • Page 50 Installation manual 8 Steam connection Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). Demount the top panel (A).
  • Page 51 Installation manual 9 At first power up When the installation is complete and the power is connected for the first time you will be forced to make the following settings. When one setting is ready you will automatically enter the next one. •...
  • Page 52 Installation manual 10 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •...
  • Page 53 Installation manual 11 Disposal information 11.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g.
  • Page 56 www.wascomat.com...
