Delta LYTE II DRL-240W Series Technical Data Sheet

TECHNICAL DATASHEET
LYTE II DIN Rail Power Supply
DRL-240W series / DRL-V240W1EN
General Description
Delta's LYTE II DIN rail power supply series is designed for cost sensitive users who need to fulfill essential features needed for many
general industrial applications, without compromising on quality and reliability. The convection-cooled LYTE II series will operate full
power from -30°C to +50°C, then de-rating up to +70°C at 230 Vac. It can operate in constant current mode, making it suitable for
inductive and capacitive loads. The product is certified according to safety standards IEC/EN/UL 62368-1. Electromagnetic radiated and
conducted emissions are compliant to heavy industrial EN 61000-6-4 Class B Emission standard and EN 61000-6-2 Immunity standard.
The product comply with environmental protection requirements as per RoHS Directive.
Model Information
LYTE II DIN Rail Power Supply
Model Number
DRL-12V240W1EN
DRL-15V240W1EN
DRL-24V240W1EN
DRL-48V240W1EN
Model Numbering
L –
DR
DIN Rail Product Type
L – LYTE Family
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
1
www.DeltaPSU.com (August 2024, Rev. 09)
Input Voltage Range
90-264 Vac
240W
□V
Output Voltage Output
12 – 12 V Power
15 – 15 V
24 – 24 V
48 – 48 V
Highlights & Features
Universal AC input voltage range
•
• Built-in constant current circuit for reactive loads
High power density
•
• Operate from -30°C to +70°C with -40°C Cold Start
Reduced no-load power consumption
•
• Compliance with DOE VI Energy Standard
Compliance to SEMI F47 @ 200 Vac
•
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (H x W x D):
Rated Output Voltage
12 Vdc
15 Vdc
24 Vdc
48 Vdc
1 E
Single Phase LYTE II Series
with Slim Design
DRL-V240W1EN
0.62 kg (1.37 lb)
123.6 x 40 x 116.8 mm
(4.87 x 1.57 x 4.60 inch)
Rated Output Current
20.0 A
16.0 A
10.0 A
5.0 A
N

N – No DC OK Blank – No coating
Relay Contact
A – With coating
