TECHINCAL DATASHEET
LYTE DIN Rail Power Supply
48V 120W 1 Phase / DRL-48V120W1A
*This picture is for reference to DRL-48V120W series only.
General Description
Delta's Lyte DIN Rail Power Supply series is designed for cost sensitive users who need to fulfill essential features needed for many
general industrial applications, without compromising on quality and reliability. The convection-cooled Lyte series will operate
between -20°C to +70°C, with full rated power available from -10°C to +50°C at 230Vac. The overcurrent protection is designed to
operate in constant current mode, which makes the Lyte series suitable for inductive and capacitive load applications. The product is
certified according to safety standards IEC/EN/UL 60950-1 for Information Technology Equipment (ITE) and UL 508 for Industrial
Control Equipment (ICE). Electromagnetic radiated and conducted emissions are compliant to EN 55032, Class B; and, the product is
fully compliant for environmental protection requirements per RoHS Directive (EU) 2015/863.
Model Information
LYTE DIN Rail Power Supply
Model Number
DRL-48V120W1A☐
Model Numbering
DR
L –
DIN Rail
Product Type
L – LYTE Series
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
1
www.DeltaPSU.com (October 2019, Rev. 03)
Input Voltage Range
85-264Vac (120-375Vdc)
48V
120W
Output Voltage
Output Power
□
Highlights & Features
•
Universal AC input voltage
Built-in constant current circuit for reactive loads
•
•
Up to 90.0% efficiency
Full power from -10°C to +50°C operation at 230Vac
•
@ 5,000 meters or 16,400 feet altitude
Built-in DC OK relay contact option available
•
•
Compliance to SEMI F47 @ 200Vac
Conformal coating on PCBAs to protect against common
•
dust and chemical pollutants
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (L x W x D):
Rated Output Voltage
48Vdc
1
A
Single Phase
Delta
Standard
DRL-48V120W1A☐
0.54 kg (1.19 lb)
123.6 x 40 x 117.6 mm
(4.86 x 1.57 x 4.62 inch)
Rated Output Current
2.50A
□
A – Without DC OK Contact
S – With DC OK Relay Contact
