Bradley Express MG Series Manual

Hide thumbs Also See for Express MG Series:

Installation manual (28 pages)

Installation instructions manual (21 pages)

Installation instruction (14 pages)

Table Of Contents

Quick Links

Download this manual

• ADA and TAS compliant

• Serves one or two users at a time

• Standard lavatory spacing on 30" centers

• Continuous bowl, sprayhead, and end caps are constructed of

Terreon

or Terreon

RE solid surface material

• Available in a variety of colors

• Available in infrared, air valve metering, or TouchTime

Specifications

The flowing "wave" design accommodates one to two users. Units handle washroom

traffic quickly and economically, while providing each user with personal space.

Lavatories for the system are positioned on 30" centers. Bradley' s continuous bowl

features a contemporary flowing "wave" design. This unique "wave" pattern is repeated

in the sprayhead, integrating the components. The pre-assembled sprayhead module

is equipped with independent aerators, each served by separate infrared sensing

module and solenoid valve (Model MG-2/IRP), pushbutton air metering valve

(Model MG-2/AST4), TouchTime

mechanical pushbutton (Model MG-2/TTPA) or

TouchTime piezo switch (MG-2/TTPB), or independent battery IR sensor and batteries

(Model MG-2/BIR3). Operating range is 20–80 psi. Flow restrictor keeps flow rate

constant at all pressures.

Product Compliance

Listed by IAPMO R&T to

• Uniform Plumbing Code (UPC)

• National Plumbing Code of Canada

• International Plumbing Code (IPC)

• IGC 156 and the requirements of

CSA B45.5/IAPMO Z124 and

ASME A112.18.1/CSA B125.1

Listed by UL Environment to

• GreenGuard Gold

Serves the American Disabilities Act and ICC/ANSI 117.1 guidelines, citations 306, 308,

309.4, 606.4, 606.5 when installed according to these requirements.

Consult local codes and standards.

This plumbing fixture is designed for hand washing only. It is not intended to dispense

water for human consumption through drinking or for preparation of food or beverages.

Verify all rough-in dimensions prior to installation.

Consult local and national codes. Conformity and compliance to local and national codes

is the responsibility of the installer.

Page 1 of 5

This information is subject to change without notice.

Bradley_Sink_Express_MG-2

mechanical metering

Listed by NSF International to

• NSF/ANSI 372

Certified to

NSF/ANSI 372

Complies with

• ADA

• ICC/ANSI 117.1

• TAS

1/20/2021

Express

Lavatory System – MG-Series

Construction

Bowl, Sprayhead, and Pedestal End Caps

Constructed of Terreon, a densified solid surface material composed of a bio-based

resin, or TerreonRE, a densified solid surface material composed of a bio-based resin

and preconsumer recycled granules. Terreon and TerreonRE are resistant to chemicals,

stains, burns, and impact. Surface damage can be easily repaired with everyday

cleansers or fine grit abrasives. Terreon and TerreonRE are GREENGUARD

as low-emitting materials.

Support Frame and Access Panel

Bowl assembly and pedestal end caps are secured to a heavy gauge stainless steel

support frame mounted to the wall. The contoured front access panel is constructed of

300 series stainless steel.

Vandal Resistance

The molded solid surface sprayhead is an integral part of the bowl module. A

free-spinning collar protects the aerator from vandalism. The infrared sensor will

automatically shut off water flow after 30–45 seconds if a vandal attempts to trigger

constant operation by covering the sensor, or by placing a stationary object in the

sensor' s detection area. Pushbuttons are secured to the unit from inside the sprayhead.

Air valves, water supplies, and waste are concealed within the pedestal/support frame

assembly.

Standard Equipment

Continuous bowl with two lavatories, sprayhead, pedestal, stainless steel mounting

frame (as described above), 120VAC/12VDC plug-in adapter (Model MG-2/IRP, Model

MG-2/TTPA and Model MG-2/TTPB). Batteries are included (Model MG-3/BIR3). The

following fittings are provided: P-trap, tailpiece, two flexible stainless steel supply

connections, and Navigator

View Latest Version

thermostatic mixing valve with stops.

P.O. Box 309, Menomonee Falls, WI 53052-0309

800 BRADLEY (800 272 3539)

MG-2

certified

+1 262 251 6000

bradleycorp.com
