215-1322 Rev. Y; ECN 17-08-010
© 2017 Bradley
Page 1 of 14
4/24/2017
Installation
MG-3 Infrared
Express
Lavatory System - MG Series
®
with Adaptive Infrared
Table of Contents
Pre-Installation Information ................................................2
Supplies Required .............................................................2
Dimensions ........................................................................3
Supplies Required .............................................................3
Rough-Ins ..........................................................................4
Mount the Frame ...............................................................5
Install the Bowl ..................................................................5
Connect the Supply ...........................................................6
Install the Drains ................................................................7
Connect the Electrical and Tubing .....................................7
Adjust the Temperature......................................................8
Components ......................................................................9
Sensor Assembly and Valve Access ...............................10
Cleaning and Maintenance ..............................................11
Troubleshooting ..........................................................12-14
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
P.O. Box 309
bradleycorp.com
Advertisement
Table of Contents
Related Manuals for Bradley Express MG Series
Summary of Contents for Bradley Express MG Series
-
Page 1: Table Of Contents
Sensor Assembly and Valve Access .......10 Cleaning and Maintenance ..........11 Troubleshooting ............12-14 P.O. Box 309 215-1322 Rev. Y; ECN 17-08-010 Menomonee Falls, WI 53052 USA © 2017 Bradley 800 BRADLEY (800 272 3539) +1 262 251 6000 Page 1 of 14 4/24/2017 bradleycorp.com... -
Page 2: Pre-Installation Information
• (8) 3/8" wall anchors, bolts and 1" min. O.D. washers to mount main frame and bowl to wall (minimum pull-out rating of 1,000 lbs.) • 1/2" nominal copper tubing for hot and cold supplies and 1-1/2" NPT drain piping • 120V/220V 50/60 Hz power source using Bradley supplied 120VAC/12V DC plug-in adapter Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 3: Dimensions
Subtract 3.5" from all vertical dimensions for TAS Juvenile Height Mounting (grades Pre-K through 5 or 6). Subtract 1.5" from all vertical dimensions for TAS Juvenile Height Mounting (grades 6 through 8 or 9). Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 4: Rough-Ins
34" above finished floor to be compliant with Americans with Disabilities Act (ADA). When mounted at 33½" rim height, the MG-3 Infrared Express® meets ADA, ANSI and UFAS requirements for barrier-free clearances, reaches and controls. Always check local codes and ordinances for compliance. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 5: Mount The Frame
Tighten the screws to secure the bowl assembly to the frame. Do not overtighten. If necessary, adjust sprayhead body to fit closely to the wall by adjusting the sprayhead mounting bolts. Refer to the components illustration for bolt locations. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 6: Connect The Supply
Slide the valve bracket up and lift it from the frame. Connect one end of flexible hose to the tempered line adapter. Connect the other swivel end to the stop. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 7: Install The Drains
Loosen the compression nuts. Push the sprayhead supply tubes firmly into the tube connectors until they are fully seated. Tighten the compression nuts by hand. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 8: Adjust The Temperature
Wait two full minutes after making the power connection before using the lav. The sensors will take up to eight full minutes (while not in use) to adapt to the bowl if another object is detected during the two-minute start-up period. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 9: Components
(MG-3-PANEL-CAPS) Contact your local Bradley rep for part number. BOWL MOUNTING HARDWARE 1/4"-20 x 1/2" 1/4"-20 PAN HEAD WASHER SCREW (qty. 4) (qty. 4) (160-389) (142-002DB) Extension Cable (251-024) Power Adapter (261-147A) Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 10: Sensor Assembly And Valve Access
TO BOWL (2) PLACES SENSOR EYES INFRARED WINDOW 269-1241 SPRAYHEAD BODY 110-115 SENSOR 269-1608HP-DC CONNECTOR ¼" TUBE 145-089 ACCESS PLATE 150-201 HOOK AND LOOP FASTENER P10-569 .5 GPM AERATOR SCREW ALLEN SOCKET #10-24 S05-142A 160-138 Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... -
Page 11: Cleaning And Maintenance
For complete instructions on this additional maintenance, visit bradleycorp.com. Repair Kits: Terreon repair kits are available. Contact your Bradley representative or distributor for part numbers and pricing. Repair kits are made to order and have a shelf life of 30 days. - Page 12 2. Inspect the stop valves for proper installation. 3. Inspect mixing valve for proper hot and cold installation. A red marking indicates the hot inlet. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017...
-
Page 13: Troubleshooting
• reconnect to the adjacent valve and turn on the water supplies to the unit; • pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor. Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017... - Page 14 198-014 Check Valve* 132-051 Retaining Ring* 118-319 Valve Body 146-079 U-Clip * Included with Prepack S65-326 Tempered Line Adapter Option Part no. S39-804 (replaces S59-4000 if tempered line is used) Strainer (173-028) Bradley • 215-1322 Rev. Y; ECN 17-08-010 4/24/2017...
