Summary of Contents for ZEROXCLUB W01
- Page 1 *The packing contents may be different based on the kit you purchased. Please take the actual product as standard. Wireless Backup Camera System Model: W01/WX02 If you have any further questions regarding our products, please contact us at sales@uszeroxclub.com...
-
Page 2: System Test Guide
Note: Permanent installation should only proceed after successful testing. WARRANTY ZEROXCLUB offers a full 18 months warranty and 3 months replacement policy. We also provide lifetime technical support to ensure that you enjoy your modern backup camera for many years to come. -
Page 3: Table Of Contents
ZEROXCLUB INSTRUCTIONS MANUAL CONTENTS SYSTEM TEST GUIDE ................1 WARRANTY ....................1 1 WHAT’S IN THE BOX ................1 2 INSTALL GUIDE ..................2 2.1 Safety Precautions ................2 2.2 Installation Steps ................2 Step 1: Mount the Camera .............. 2 Step 2: Power the Camera ...............3 Step 3: Install the Monitor .............. - Page 4 ZEROXCLUB INSTRUCTIONS MANUAL 5 Troubleshooting ..................9 6 FAQ ..................... 11 7 General Information ................13 ✉ support@zeroxclub.com ..............13...
-
Page 5: Warranty
ZEROXCLUB INSTRUCTIONS MANUAL 1 WHAT’S IN THE BOX Thank you for choosing ZEROXCLUB! Your wireless backup camera system is built to last with high-quality monitors, cameras, and cables. To ensure everything arrives safely check the shipping box for signs of damage. -
Page 6: Install Guide
ZEROXCLUB INSTRUCTIONS MANUAL 2 INSTALL GUIDE The system components are designed to be assembled without difficulty and with simple tools. 2.1 Safety Precautions • Use the correct size cable and connector to power the rear camera • Ensure the power supply circuit has circuit protection •... -
Page 7: Step 2: Power The Camera
ZEROXCLUB INSTRUCTIONS MANUAL 1.Mark camera mounting 2. Tighten the screws on 3.Adjust the camera angle as position. Screw on both sides of the camera needed. according to the mark. Step 2: Power the Camera Connect the camera’s red wire to the vehicle’s reverse light wire (12V). -
Page 8: Step 4: Power The Monitor
ZEROXCLUB INSTRUCTIONS MANUAL Suction Cup Mount Installation: Step 4: Power the Monitor Power via: Cigarette lighter (plug-and-play) or hardwired to fuse box (for permanent power) Mount the antenna to ② Connect the power cord or Power the monitor ①... - Page 9 ZEROXCLUB INSTRUCTIONS MANUAL Channel number ① Sunshade Removable sunshade (optional) ② Factory-applied screen protector (recommended to keep installed) ③Protective Film Red Tag It is used to remove the protective film. Not recommended to ④ remove it Light Power Indicator Light: ON/OFF status ⑤...
-
Page 10: System Operation
ZEROXCLUB INSTRUCTIONS MANUAL 4 SYSTEM OPERATION Software Management System (SMS) Interface Overview The diagram below shows the organization of the SMS panels and their corresponding sub-panels. You can easily navigate and adjust these settings using your monitor's control buttons. 4.1 Menu Description There are 4 primary menu options available. -
Page 11: Pairing Settings
ZEROXCLUB INSTRUCTIONS MANUAL 4.2 Pairing Settings 4.2.1 Pairing Procedure The camera has been paired in the factory for QC testing. If you cannot find the image from the camera on the monitor ("NO SIGNAL" appears), when adding new cameras to the system, or when... -
Page 12: Picture Operation
ZEROXCLUB INSTRUCTIONS MANUAL 4.3 PICTURE Operation You can adjust the parameters of screen brightness, contrast and hue as needed. Press MENU → Select PICTURE with +☀/-☀ → Confirm with SEL → Adjust value with +☀/-☀ → Confirm with SEL or exit with MENU .4 MIR-FLIP Operation... -
Page 13: Troubleshooting
ZEROXCLUB INSTRUCTIONS MANUAL 5 Troubleshooting 1. Must complete pairing within 20 seconds: Keep camera and monitor Pairing failure within 3ft during pairing. 2. Camera powered before pairing countdown: Power the camera only after pairing countdown begins. 3. Intermittent signal from poor wiring: Check all cable connections. - Page 14 ZEROXCLUB INSTRUCTIONS MANUAL 4. Test Camera Power: Cover the camera’s sensor with your finger. IR lights should turn on (if not, the camera isn’t receiving power). 5. Test with a different 12V power source (if available). 1. Check if the camera unit is receiving power.
-
Page 15: Faq
ZEROXCLUB INSTRUCTIONS MANUAL screwed on to the monitor. 7. Check if the monitor power cord can stay connected to the cigarette lighter outlet. 8. Please contact us at sales@uszeroxclub.com with your Amazon Order ID. It would be better if you could attach the video of the issue. - Page 16 ZEROXCLUB INSTRUCTIONS MANUAL 6.5 Q: What should I do if the camera is foggy or if there is water inside the lens area? A: Please contact us at sales@uszeroxclub.com in time, and we will send the replacement to you. 6.6 Q: The monitor emits smoke after connection A: The positive and negative poles are connected in reverse and cause a short circuit.
-
Page 17: General Information
This vehicle monitoring system includes weatherproof cameras and a display, designed for 12-24V DC power (1-2A max). 7.2 Safety Instructions ⚠ Critical Warnings: Professional installation required - Contact ZEROXCLUB support for assistance Power off during installation/maintenance No user repairs - Contains no serviceable parts Keep away from children ⚠...
