Freestanding gas cooker
Dear Customer!
Congratulations on your purchase. See for yourself: our
products read reliability.
These ample instructions have been compiled in order to help
you learn how to handle the appliance. They will show you step
by step what your appliance is capable of, so please read them
carefully before you attempt to use your cooker for the first
time.
Contents
Freestanding gas cooker............................................... 41
Dear Customer!
Contents
Instructions for use....................................................... 41
Safety precautions
If you notice any malfunction in the gas installation, or if you
smell gas in the room:
Description of the appliance ........................................ 42
Prior first use ................................................................ 43
Oven............................................................................... 44
Use of oven for baking.................................................. 45
Roasting of meat
Oven............................................................................... 46
Ignition and operation of oven gas burner
Instructions for use
Safety precautions
• To avoid any possible hazard, the appliance may be installed
by qualified personnel only, authorized by the gas distributing
company and by the authorized service. Installation should be
carried out in accordance with the legal regulations and
technical requirements of the local gas supplier. Important
instructions in this regard may be found in the Section
"Instructions for installation".
• Any repairs by unqualified persons may result in explosion, electric
shock or short circuit. In order to avoid possible injuries to your body
or to the appliance, do not attempt any repairs by yourself. Such
work should be carried out by qualified service personnel.
• Before installing and connecting the appliance check whether the
specifications of the local gas supplier (type of gas and pressure)
correspond to the specifications of the appliance.
• Technical specifications of the appliance are indicated on the rating
plate.
Safety warnings are listed on page 41.
The first thing to do is to check if your appliance has arrived
undamaged. In case you find any transport damages, please
report it immediately to your local dealer, or to the regional
warehouse which supplied the appliance. You will find their
phone numbers on the invoice or on the delivery note.
We hope your cooker will successfully serve its purpose for
many years.
Grilling with infrared electric heater
Cleaning and maintenance ...........................................51
Troubleshooting guide ..................................................52
Note!
Replacement of parts ....................................................53
Instructions for installation and connection ...............53
Electrical connections ...................................................54
Gas connections .............................................................54
Technical specifications ................................................57
Technical specifications ................................................57
• This appliance is not connected to a chimney or vent opening. The
appliance must be installed and connected in accordance with the
standing regulations. Special attention should be taken in regard to
adequate ventilation.
• The use of a gas cooking appliance results in the production of
heat, moisture and products of combustion in the room in which it
is installed. Ensure that the kitchen is well ventilated especially
when the appliance is in use: keep natural ventilation holes open
or install a mechanical ventilation device (mechanical extractor
hood).".
• Hot grease is highly inflammable, so pay extra attention when
preparing food with grease or oil. Frying may be carried out only
under constant surveillance.
• Never clean the oven or the cooktop with hot steam devices or
high-pressure jet cleaning device, as they may provoke short circuit.
• Before opening the control panel and before any attempted repairs
disconnect the appliance from the mains.
Instructions for use and installation
167220
GB IE MT
41
Advertisement
Table of Contents
Related Manuals for Gorenje P51A1-V1VTD
Summary of Contents for Gorenje P51A1-V1VTD
-
Page 1: Table Of Contents
167220 Freestanding gas cooker GB IE MT Safety warnings are listed on page 41. Dear Customer! The first thing to do is to check if your appliance has arrived Congratulations on your purchase. See for yourself: our undamaged. In case you find any transport damages, please products read reliability. -
Page 2: Intended Use
167220 • Do not keep any flammable material in the drawer under the oven mental capacity, or persons with inadequate experience or knowledge, do not use the appliance unless attended by a (paper, wiping cloth, plastic bags, cleaning agents or sprays, etc.), qualified person. -
Page 3: Electric Ignition
167220 1 Gas ignition device button (certain models only) 5 Cooking zone, front left, normal burner 2 Oven illumination switch (certain models only) 6 Cooking zone, front right, large burner 3 Oven signal lamp. Lit when electric grill is in 7 Cooking zone, rear right, auxiliary burner operation (certain models only) 4 Cooking zone, rear left, normal burner... -
Page 4: Ignition And Operation Of Burners
167220 crown cap Ignition with both hands (certain models only) To ignite the burner, press the selected burner button and turn it to thermal coupling (certain the maximum power position . Now press the ignition device models only) button. Electric spark from the ignition device ignites the gas. If the ignition device is out of order, either due to power failure or humid ignition device, use a match or a lighter to ignite the gas. -
Page 5: Use Of Oven For Baking
167220 Use of oven for baking • Aluminum or clay dishes reduce the possibility of burning from Baking of pastry below. Baking pans made of such materials are suitable for Always use middle level for baking pastry. baking soft, wet pastry. •... -
Page 6: Oven
167220 Oven • Oven temperature is regulated by the thermostat. Important warnings! Immediately after ignition it operates at maximum power until • Never put aluminum foil to the bottom of the oven, and do the preset temperature is reached. Then the thermostat not place any crockery upon it, since the foil may impede the reduces the burner power to the value required for circulation of air, and the oven enamel may be damaged by... - Page 7 167220 • In case you may not find any particular type of cake in the Pastry is too light below tables, use the information available for the next most similar Use dark baking pan next time, or place the pan one level type of cake.
-
Page 8: Roasting
167220 type of meat, its size and quality, so you may expect some Roasting variations. • Roasting of red meat, poultry and fish is rational if the roast The table below indicates the recommended temperatures, times, and baking levels. exceeds one kilogram in size. •... -
Page 9: Heating With Infrared Gas Burner (Position - Symbol)
167220 • Place the meat chunk in the middle of the grid rack, below Heating with infrared gas burner (position – symbol) the burner. • Heat comes directly from the infrared burner located at the • Turn the meat round after half of the roasting time has oven ceiling. -
Page 10: Broaching With Infrared Electric Heater
167220 Grill table for infrared gas burner Type of meat for grill Weight Guide level Grill time (in grams) (from bottom up) (in min.) Meat and sausages 2 beefsteaks 25-30 2 pork scrag fillets 25-30 2 pork chops 25-30 4 lamb cutlets 18-22 4 grill sausages 18-23... -
Page 11: Cleaning And Maintenance
167220 Cleaning and maintenance • When purchasing cleaning agents remember the Never clean the appliance with hot steam device or pressurized steam cleaner! environment, and strictly follow the manufacturer's Before cleaning switch the cooker off and let it cool down instructions. -
Page 12: Troubleshooting Guide
167220 pushing them forward and downwards, so the hinges lock into their slots (fig. 3). Check if the hinges are locked into their respective slots. Now open the door completely and turn the removable locks into their original position. Close the door slowly and check if they close properly (fig. -
Page 13: Replacement Of Parts
167220 Replacement of parts In case of damage you are allowed to replace only such Oven light bulb parts which do not require any tools for their replacement. • All other exchange parts requiring tools for replacement, (certain models only) The bulb for replacement should meet the following may be replaced by qualified personnel only. -
Page 14: Electrical Connections
167220 Electrical connections • Before attempting the connection, check whether the voltage Electric connection may be carried out by qualified service personnel only! indicated on the rating plate corresponds to the actual mains Wrong connection may permanently damage parts of voltage. -
Page 15: Nozzle Specifications
167220 Nozzle specifications Type of gas, Auxiliary burner Normal burner Large burner Mini Wok Oven burner Infrared pressure Standard Fast burner Wobe number 0,36 0,36 1,90 0,46 0,76 1,56 0,81 Natural gas H Nennwärme- Wo=45,7÷54,7 belastung(kW) MJ/ m 95,21 34,4 95,21 34,4 180,9... - Page 16 167220 Oven burner regulation elements (fig. 4) Elements for setting infra-red burner (Figure 4a) 12 Nozzle For approach to the parts for the modification of infra-read heater it is necessary to disassemble the infra-red burner 14 Screen (unscrew the screw on the bottom part of the burner and draw 15 Oven burner it slightly downwards).
-
Page 17: Technical Specifications
Total mains power (g/h) AC 230 V, 50 Hz Nominal voltage Group GB,IE,GR = II2H3+ Empty oven reaches 200°C in 9 minutes with the oven burner in operation. Technical specifications Type P51A1-V1VTD P52A1-V2VTD P53A1-V2VTD P53A1-N3VTD P53B2-V2NTD P53B1-N3VTD P51A1-V3NTD P52A2-V2VTD P53A1-N3NTD P51A2-V2VTD...
