- Page 1 EN 50131-1 EN 50131-2-4 EN 50131-5-3 EN 50130-4 EN 50130-5 CEB T031 Air2-QIR200W Indoor wireless passive infrared detector for intrusion alarm systems Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Qtech detectors 1.1 Functioning of the Air2-QIR200W detector 1.2 Main features 1.3 Description of parts 1.4 Technical specifications 2. Installation 2.1 Warnings 2.2 Coverage 3. Programming wireless terminal 3.1 Wireless terminal parameters 3.2 Real-time 4. General information 4.1 About this manual 4.2 Manufacturer's details 4.3 Warranty 4.4 Limited warranty 4.5 Documents for the users 4.6 Disposal of the product Installation and programming manual- 100... -
Page 3: Qtech Detectors
Tamper protection The detector is protected by anti-tamper systems: through the contact on the PCB for anti-opening through a sensor that detects changes in position of the detector and tilting 1.2 Main features Digital signal analysis Coverage 13m Detection angle 90° Pulse counter Temperature compensation White light immunity Signalling LED Signals from bypassable LEDs Anti-opening protection Movement and tilt protection Adjustable sensor sensitivity Wireless interface Air2 Air2-QIR200W | © 2022 Inim Electronics S.r.l. -
Page 4: Description Of Parts
1. Qtech detectors 1.3 Description of parts [A] Cover [H] Positive battery contact [B] Signalling LED [I] Negative battery contact [C] Lens [J] Anti-opening tamper [D] [K] Base ENROLL button [E] [L] Cover retainer locations PIR sensor (infrared) [F] Mounting screw locations [G] Cover securing screws 1.4 Technical specifications Power supply voltage Battery type Lithium CR17450 3V Estimated life 3 years <Low battery= fault voltage... - Page 5 Communication type Two-way Modulation GFSK Device monitoring from 12 to 250 minutes Note In order to comply with the EN 50131-1 standards the alarm system supervision time must be below 120 minutes. (EN IEC 62368-1) Tipo terminali BATTERY ES1, PS1 Air2-QIR200W | © 2022 Inim Electronics S.r.l.
-
Page 6: Installation
2. Pull the cover away from the base. 3. Push apart the card retainers. 4. Open the anchor-screw holes. 5. Hold the base to the chosen mounting placement and mark the screw holes position. 6. Using the screws, secure the base in position. 7. Insert the battery, ensure you respect the proper polarity. Air2-QIR200W | © 2022 Inim Electronics S.r.l. -
Page 7: Warnings
2. Installation 8. Enroll the device. For details of the enrolling phase, refer to the manual of the Air2-BS200 trans- ceiver. Configure the detector on the control panel as i nput terminal, . 9. Fit the PCB back. 10. Re-attach the front cover and replace the securing screw. 11. Complete the programming process and adjust the operating sensitivity. Note When using of the optional XBK100 swivel, the function that detects removal from the mounting surface (anti-dis- lodgement) is void and the degree of safety is reduced to 1. 2.1 Warnings ... - Page 8 2.2 Coverage Top view 90° IR level 1 IR level 2 IR level 3 Air2-QIR200W | © 2022 Inim Electronics S.r.l.
- Page 9 2. Installation Side view Installation and programming manual- 100...
-
Page 10: Programming Wireless Terminal
parameters If this value is more than 1, you must also program the 8Multi- 8generic9 Alarm pulses pulse time9 parameter. Multi-pulse For future use time Alarm pulse For future use duration 3.2 Real-time For each configured device the software provides a direct software-to-device connection which allows visua- lization of the real-time values of the following features: Signal reception This series of notches represents the reception level of the wireless signal of the device as received by the Air2-BS200 level transceiver. Battery charge level Percentage of the device battery charge. RF analysis Function to monitor the variation of the signal transmitted by the device and the background noise detected through time. Air2-QIR200W | © 2022 Inim Electronics S.r.l. - Page 11 3. Programming wireless terminal Such data can be reached through the 8Real time9 section relating to the programming of each wireless device or through the 8Monitoring9 section which provides an overview of all the devices connected to the control panel. Installation and programming manual- 100...
-
Page 12: General Information
4.2 Manufacturer's details Manufacturer: Inim Electronics S.r.l. Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.biz Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work only on devices marketed under the brand Inim Electronics. 4.3 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation of performance of this product or actual damage that results from the use of products, parts or other repla- ceable items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental, including without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defec- tive products or otherwise arising from the incorrect or otherwise improper installation or use of this product. This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover damage arising from improper maintenance or negligence, damage caused by fire, flood, wind or lightning, vandalism, fair wear and tear. Inim Electronics S.r.l. shall, at its option, repair or replace any defective products. Improper use, that is, use for purposes other than those mentioned in this manual will void the warranty. Contact Our authorized dea- ler, or visit our website for further information regarding this warranty. Air2-QIR200W | © 2022 Inim Electronics S.r.l. -
Page 13: Limited Warranty
4. General information 4.4 Limited warranty Inim Electronics S.r.l. shall not be liable to the purchaser or any other person for damage arising from impro- per storage, handling or use of this product. Installation of this Product must be carried out by qualified persons appointed by Inim Electronics. Instal- lation of this Product must be carried out in accordance with Our instructions in the product manual. 4.5 Documents for the users Declarations of Performance, Declarations of Conformity and Certificates concerning to Inim Electronics S.r.l. products may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and then selecting "Certifications" or requested to the e-mail address info@inim.biz or requested by ordinary mail to the address shown in this document. Manuals may be downloaded free of charge from the web address www.inim.biz, getting access to the reser- ved area, after the login, and then to the section of each product. 4.6 Disposal of the product Informative notice regarding the disposal of electrical and electronic equipment (applicable in countries with differentiated waste collection systems) The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be ... - Page 14 4.6 Disposal of the product Air2-QIR200W | © 2022 Inim Electronics S.r.l.
- Page 15 4. General information Installation and programming manual- 100...
- Page 16 Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz DCMIINE0A2QIR200W8E-100-20220511...
