  • Page 1 EN 50131-1 EN 50131-2-4 EN 50130-4 EN 50130-5 CEB T031   QDT500H Indoor combined passive infrared and microwave curtain detec- tor with anti-masking protection for intrusion alarm systems Installation and programming manual...
  • Page 2: Table Of Contents

    Table of contents 1.  Qtech detectors 1.1  Functioning of the QDT500H detector 1.2  Main features 1.3  Description of parts 1.3.1  Terminal board 1.3.2  LED signallings 1.4  Technical specifications 2.  Installation 2.1  Warnings 2.2  Coverage 2.3  Balancing 2.3.1  N.C./N.O. 2.3.2  Single balancing 2.3.3  Double balancing 2.3.4  Double zone balancing 2.3.5  Double zone balancing with EOL 2.3.6  Triple balancing 2.3.7  Triple balancing with EOL 2.3.8  Restrictions or requirements in: 3.  Programming 3.1  Programming from QDT500H 3.2  Programming menu 4.  General information 4.1  About this manual 4.2  Manufacturer's details 4.3  Warranty 4.4  Limited warranty 4.5  Simplified EU Declaration of Conformity 4.6  Documents for the users 4.7  Disposal of the product Installation and programming manual- 100...
  • Page 3: Qtech Detectors

    1.1 Functioning of the QDT500H detector On supplying power, the red LED starts blinking then, after closing the detector cover, the 4 LEDs light up in  sequence and the detector goes into the self-calibration phase. Within 150 seconds the detector enters oper- ational status and the LEDs turn off. During the self-calibration phase, the partition monitored by the  detector must be in stand-by status, free from obstacles and people moving about. If someone is moving in the space covered by the detector, the alarm signal will activate and the LEDs cor- responding to the detectors that have sensed the movement will light up. In this case the red LED lights up and the alarm contact opens for a minimum time of 1 to 3 seconds. AND mode Function that, if enabled, permits the detector to activate an alarm when the PIR and MW sensors detect  movement at the same time. Smart-OR mode Function that, if enabled, activates the alarm signal even when only one of the two sensors detects con- tinuous movement for at least 10 seconds. The alarm output (8ALARM9 terminals) activates when both sensors detect motion and also when the  detector is masked.  The tamper output (8TAMPER9 terminals) activates when the lid is opened or when the tilt sensor detects a  change in its position. Ambient temperature can affect infrared sensing ability and the possible presence of moving or vibrating  objects can affect the MW sensor. The installer can adjust the sensitivity of the detectors through pro- gramming. Changing the sensitivity of the sensors does not always reduce the range, but it does reduce the ability to  detect small changes in heat/temperature. Tamper protection The detector is protected by anti-tamper systems:   through the contact on the PCB for anti-opening   through a sensor that detects changes in position of the detector and tilting Anti-masking The anti-masking protection is achieved via the microwave module and IR sensors and is programmable. QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 4: Main Features

    1.  Qtech detectors If someone is covering the detector frontally with reflective or ferrous materials, the detector will generate a  8masking9 signal which will be restored only after the removal of the covering material in question. In order to generate a masking alarm, the distance between the detector of the covering material depends  on the material itself and can be between 0 and 30cm. Ferrous materials are detected at shorter distances  than reflective materials. The signalling occurs by activating the 8FAULT9 and 8ALARM9 outputs; these will be deactivated only when  stand-by (at rest) conditions are restored. 1.2 Main features   Digital signal analysis   Coverage 3m   Detection angle 70°   Pulse counter   Temperature compensation   White light immunity   Signalling LED   Signals from bypassable LEDs   Anti-opening protection   Movement and tilt protection   Anti-masking protection   Bypassable sensors   Adjustable sensor sensitivity   8AND9 and 8Smart-OR9 functions for alarm trigger 1.3 Description of parts Installation and programming manual- 100...
  • Page 5: Terminal Board

    MW sensor (microwave) [H]  [P]  Cable entry Antimasking sensor 1.3.1 Terminal board   +12V Positive power supply -12V Negative power supply ALARM Alarm signal (N.C. during stand-by) TAMPER Tamper signal output terminals (N.C. during stand-by) FAULT Fault signal output terminals The 8ALARM9 terminal activates in the event of alarm detection and in the event of masking. The 8FAULT9 terminal activates in the event of power supply voltage lower than 10V and in the event of  masking. 1.3.2 LED signallings Green LED MW detection Blue LED Anti-masking detection Tamper detection Red LED Alarm signal Yellow LED PIR detection QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 6: Technical Specifications

    1.  Qtech detectors 1.4 Technical specifications Power supply voltage range: from 10 to 16 V  Input voltage nominal: 12.6 V  Stand-by current draw 20mA Maximum current draw 25mA Detectors type digital dual PIR, microwave module Detection mode Infrared emission + doppler effect Type of microwave antenna Plane antenna with FET-GaAs oscillator Alarm pulses from 1 to 2 Intrusion alarm output N.C., 16V  , 100 mA max Tamper output N.C., 16V ...
  • Page 7: Installation

    2. Installation     1.  Choose a suitable mounting placement.   2.  Loosen the front cover securing screw and open the cover by spreading the two surfaces apart from  the side of the securing screw.   3.  Open the holes for the securing screws, open the cable glands and insert the cables.   4.  Hold the base to the chosen mounting placement and mark the screw holes position.   5.  Attach the adhesive sponge (provided) to the rear side of the base.   6.  Using the screws, secure the base in position.   7.  Complete the connections on the terminal board.   8.  If necessary, carry out the programming using the buttons on the PCB.   9.  Re-attach the cover to the base and replace the securing screw. QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 8: Warnings

    2.  Installation 2.1 Warnings     The securing screws are component parts of the anti-dislodgement device and therefore their use is  essential for the correct functioning of the device.   During the installation phases, pay the utmost attention in order to avoid drilling into water pipes, gas  pipes, electrical ducts, etc.   Avoid installing the detector in the vicinity of the following sources of interference:   s ources of steam,  oil fumes, infrared sources, power lines, neon lamps and objects that can cause temperature  changes such as stoves, refrigerators and ovens.   Do not install the detector   i n locations where there is risk of rapid temperature changes.   Ensure that the detector is placed in a location well protected against rain and bad weather.   Do not install more than one detector in each room or two detectors in different rooms at a distance  of less than 2 m from each other.   Do not blind the field of detection of the sensor, even partially.   Do not touch the electronic components as this may damage the circuits and reduce the reliability of  the detector. If necessary, clean the detector with a soft cloth only.   This detector must be installed in compliance with the laws and standards in force.   The device should be tested on a regular basis. 2.2 Coverage This paragraph shows the projections on a horizontal plane and on a vertical one of the range of the device  sensors. The measurements shown are in metres. Installation and programming manual- 100...
  • Page 9 2.2  Coverage Top view     Side view 70°   QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 10: Balancing

    2.  Installation Front view 10° 2.3 Balancing The alarm signals, masking, fault and tamper (on the line, forced opening or removal of the device) must be  signaled to the control panel through the connections with the available terminals.  In addition to this, the alarm and line tamper signals can be communicated with the use of appropriate bal- ancing, in order to be able to use a single control panel input (in the graphs below, indicated by 8Tx9). The wiring and respective balancing method depend on the type of detector you are installing, and the level  of protection you wish to achieve. The detectors can be powered through:   terminals [+AUX/12V] and [-/GND] on the control panel   terminals [+AUX/12V] and [-/GND] on expansions   terminal [+/12V] and terminals [-/GND] on keypads   from any 12V ancillary source on condition that its GND reference is in common with that of the con- trol panel. 2.3.1 N.C./N.O. In the case of N.C. (normally closed) balancing, it is possible to detect 2 distinct conditions on the zone:   stand-by (0 Ohm)   alarm (open circuit) Installation and programming manual- 100...
  • Page 11: Single Balancing

    2.3  Balancing If you want the detector to signal tamper events, it is necessary to connect the 8Tamper9 terminal to a 824h9  zone on the control panel. 2.3.2 Single balancing Single zones can discriminate 3 conditions on the entire terminal:   stand-by   alarm   tamper (short-circuit) 6K8Ω If you want the detector to signal tamper events, it is necessary to connect the 8Tamper9 terminal to a 824h9  zone on the control panel. 2.3.3 Double balancing Double balancing discriminates 4 distinct conditions on the zone terminal:   stand-by   alarm   tamper (short-circuit)   tamper (wire cutting) QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 12: Double Zone Balancing

    2.  Installation 6K8Ω 6K8Ω FAULT 2.3.4 Double zone balancing Double zones without EOL resistor can discriminate 5 conditions on the entire terminal:   stand-by on both zones   alarm on zone 1 and standby on zone 2   alarm on zone 2 and stand-by on zone 1   alarm on both zones   tamper (wire cutting) 6K8Ω 3K9Ω 2.3.5 Double zone balancing with EOL Double zones with EOL resistors can discriminate 6 conditions on the entire terminal:   stand-by on both zones   alarm on zone 1 and standby on zone 2   alarm on zone 2 and stand-by on zone 1   alarm on both zones   tamper (wire cutting)   tamper (short-circuit) Installation and programming manual- 100...
  • Page 13: Triple Balancing

    In the case of Triple balancing without an EOL resistor, it is possible to detect 5 distinct conditions for the  entire terminal:   stand-by on 8ALARM9 and 8FAULT9 zones   alarm on 8ALARM9 zone and stand-by on 8FAULT9 zone   alarm on 8FAULT9 zone and stand-by on 8ALARM9 zone   alarm on both zones   tamper (wire cutting) 3K9Ω 6K8Ω FAULT 2.3.7 Triple balancing with EOL In the case of Triple balancing with an EOL resistor, 6 distinct conditions can be detected for the entire ter- minal:   stand-by on 8ALARM9 and 8FAULT9 zones   alarm on 8ALARM9 zone and stand-by on 8FAULT9 zone   alarm on 8FAULT9 zone and stand-by on 8ALARM9 zone   alarm on both zones   tamper (wire cutting)   tamper (short-circuit) QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 14: Restrictions Or Requirements In

    2.  Installation 3K9Ω 3K9Ω 6K8Ω FAULT 2.3.8 Restrictions or requirements in: Band fre- Country Implementation Reason / remarks quency 24.05 - 24.25  Restricted imple- Band limited to 24.150 - 24.250 GHz to prevent speedometer inter- mentation ferences. Installation and programming manual- 100...
  • Page 15: Programming

    Remove the cover.   2.  Power up the detector.   3.  Press and hold the P1 button for 5 seconds until all the LEDs start blinking. When the button is  released, the menu will have the first option active.   4.  Use the P1 button to move to the different options on the menu (see). The LED combination (the  LEDs which blink) identifies the option concerned.   5.  By pressing the P2 button it is possible to view the current setting of the parameter and with sub- sequent presses the parameter can be changed until the desired setting is obtained.   6.  It is possible to change the menu option by pressing the P1 button again until the desired parameter  is reached.   7.  To exit programming without saving changes, wait 30 seconds without pressing any button or dis- connect the power supply. To exit programming and confirm all changes, press and hold the P1 button for 5 seconds, until the  LEDs blink quickly.   8.  Close the casing and complete the installation procedure. Default Reset of programming is achieved with the device powered up and by holding down buttons P1 and P2 sim- ultaneously for 10 seconds. This leads to the sequential lighting (one every 2 seconds) of all 4 LEDs. When all the LEDs are on, the but- tons can be released and in this way reset all programming menus to factory data settings. QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 16: Programming Menu

    3.  Programming 3.2 Programming menu In the table below, the 8Menu9 column indicates the combination of LEDs that identify the parameter and the  8Parameter9 column indicates the function/parameter on the menu. The 8Options9 column shows the value of the programmable settings for each parameter The boxes with a grey background indicate the values + + o f the factory parameters/functions. Menu (P1 button) Options (P2 button) Option Green Yellow Red Blue         Microwave sensitivity Level 1 Level 2 Level 3                 Infrared Sensitivity Level 1...
  • Page 17: General Information

    4.2 Manufacturer's details Manufacturer: Inim Electronics S.r.l. Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.biz Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system have authorization  to work only on devices marketed under the brand Inim Electronics. 4.3 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from  defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with  other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation  of performance of this product or actual damage that results from the use of products, parts or other repla- ceable items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller  obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any  product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any  other person for any loss or damage whether direct of indirect or consequential or incidental, including  without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defec- tive products or otherwise arising from the incorrect or otherwise improper installation or use of this product. This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover  damage arising from improper maintenance or negligence, damage caused by fire, flood, wind or lightning,  vandalism, fair wear and tear. Inim Electronics S.r.l. shall, at its option, repair or replace any defective products. Improper use, that is, use  for purposes other than those mentioned in this manual will void the warranty. Contact Our authorized dea- ler, or visit our website for further information regarding this warranty. QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 18: Limited Warranty

    4.  General information 4.4 Limited warranty Inim Electronics S.r.l. shall not be liable to the purchaser or any other person for damage arising from impro- per storage, handling or use of this product. Installation of this Product must be carried out by qualified persons appointed by Inim Electronics. Instal- lation of this Product must be carried out in accordance with Our instructions in the product manual. 4.5 Simplified EU Declaration of Conformity Hereby, Inim Electronics S.r.l. declares that the radio equipment type QDT500H is in compliance with Direc- tive  2014/53/EU.  The  full  text  of  the  EU  declaration  of  conformity  is  available  at  the  following  internet   address: www.inim.biz. 4.6 Documents for the users Declarations of Performance, Declarations of Conformity and Certificates concerning to Inim Electronics ...
  • Page 19 4.7  Disposal of the product   QDT500H | © 2022 Inim Electronics S.r.l.
  • Page 20   Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz DCMIINE0QDT500H-100-20220510...
