INIM QXI Series Installation Instructions Manual

Wide Angle Outdoor Detector
Wide Angle Outdoor Detector
QXI series
QXI series
WIRED MODEL
Introduction
1
Manufacturer' s statement
2
! Warning
Installation
3
Base
Main unit
Cover
LED
[1] Warm-up
Lens
[2] Alarm
[3] Walk test end
[4] Blocking detection
How to open the cover
Lock screw
(Use as necessary)
* Remove before,
if used.
[1] Unlock the cover using a
screwdriver (-).
[2] Lift the cover up.
PDF download and additional information with multilanguage
available in:
https://inim.biz/it/antintrusione/protezione-da-esterno?
Prohibited Recommended
Mounting height
Multi Level
Pet Alley
Do not touch the
!
parts with this sign.
Microwave module
!
Tamper switch
Seconds
60
2
5
x 3
Terminal
-
+
SP TR AL TP TP
COM
Alarm
Power
Spare Trouble
! Caution
2.2 m (7 3 ) to 2.7 m (8 11 )
0.8 m (2 7 ) to 1.2 m (4 )
MW Sensitivity
!
L H
default
Mirror
Except levers
!
on side
DIP switch
PIR sensor
!
Cover lock screw
(Use as necessary)
Wiring
[1] [2]
Tamper
- 1 -
INSTALLATION INSTRUCTIONS
QXI-DT-X5: +Microwave detection (10.525 GHz)
Pet Alley
The anti-blocking function can not
be used with the pet alley setting.
Tilt
<Accessories>
Mounting screw
(4 × 20 mm) x 2
Area masking strips
a
b
b
c
c
d
d
e
e
ｆ
ｆ
<Options>
CA-1W(W)
Bracket for wall mount
2 cables
[1] Wiring knockout
EN
Fixing screw
for the Main unit
(3 × 12 mm) x 1
e
ｆ
d
c
b
a
b
c
d
ｆ
e
CA-2C(W)
Bracket for ceiling mount
Surface wiring
[2] Wire through
the knockout
