- Page 1 EN 50131-1 EN 50131-2-6 EN 50131-5-3 EN 50130-4 EN 50130-5 CEB T031 Air2-MC200 Magnetic contact with shock and tilt sensor Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Description of the Air2 system 2. Description of Air2-MC200 2.1 Description of parts 2.2 Technical specifications of Air2-MC200 3. Installation of Air2-MC200 3.1 Enrolling a wireless device 3.2 Battery replacement 4. Programming wireless terminal 4.1 Wireless terminal parameters 4.2 Real-time 5. General information 5.1 About this manual 5.2 Manufacturer's details 5.3 Notes from the Manufacturer 5.4 Simplified EU Declaration of Conformity 5.5 Warranty 5.6 Limited warranty 5.7 Documents for the users 5.8 Disposal of the product Installation and programming manual- 102... -
Page 3: Description Of The Air2 System
Air2-KF100/S 4 button remote-control key Air2-Ergo/S 4 button remote-control key Air2-Pebble/S 4 button remote-control key Air2-MC200 magnetic contact with shock and tilt sensor Air2-MC300 magnetic contact with two I/O terminals Air2-FD100 smoke detector Air2-Aria/W keypad with graphic display ... -
Page 4: Description Of Air2-Mc200
2. Description of Air2-MC200 2. Description of Air2-MC200 The Air2-MC200 is supplied with a magnet which is to be secured (by means of two screws) to the side of the contact, in the position indicated by the two notches. Air2-MC200 also integrates a shock and a tilt sensor that allow its use without the need of the magnet. The Air2-MC200 is equipped with open and dislodgement tamper protection. The device uses separate channels for the different types of signalling, thus allowing precise identification of the alarm source. Magnet detection range The following table indicates the distance in millimeters of the operating capacity of the magnet depending on the side in use and the axes illustrated in the figure (values starting from a nominal distance of 10mm, except for axis y-): Distance between magnet and contact (mm) Axis Near Withdrawn x +/- z +/- Shock detection Signalling of shock waves is achieved through a tri-axial vibration detector. The vibration sensibility can be set either from a keypad or via the programming software application. Tilt detection Signalling of tilting (angle change) is achieved through tri-axial tilt sensing. The tilt-variation value (angle) ... -
Page 5: Description Of Parts
4 years estimated life ‘Low battery’ fault voltage Less than 2.4V Current draw 10µA during standby 30mA maximum Operating environmental conditions from -10 to +40 °C Temperature ≤ 93 % without condensation Relative humidity Security rating Environmental class Dimensions (W x H x D) 35 x 58 x 23mm Air2-MC200 | © 2021 Inim Electronics S.r.l. - Page 6 2. Description of Air2-MC200 Weight 30 g Magnet dimensions 13 x 40 x 14mm Colours White, Brown and Black (EN IEC 62368-1) Terminal type BATTERY ES1, PS1 Installation and programming manual- 102...
-
Page 7: Installation Of Air2-Mc200
2. Using a flat-bladed screwdriver in the enclosure screw location, push open the enclosure and sepa- rate the two parts. 3. Hold the base to the chosen mounting placement and mark the screw holes and tamper protection position. 4. Using the screws, secure the base and the tamper protection in position. 5. Insert the battery, ensure you respect the proper polarity. 6. Enroll the device. 7. If you wish to fit the magnet by means of the screws (included), remove the magnet base by means of a flat-bladed screwdriver. 8. Position the base of the magnet at a distance of about 2 mm from the detector, centering the notches on the side of the detector base. 9. Using the screws or the adhesive tape, attach the magnet. 10. Re-attach the cover to the base of the contact and replace the enclosure screw. Air2-MC200 | © 2021 Inim Electronics S.r.l. -
Page 8: Enrolling A Wireless Device
3. Installation of Air2-MC200 3.1 Enrolling a wireless device The enrolling process allows you to associate an INIM wireless device with the Air2-BS200 transceiver that connects to the anti-intrusion control panel. This procedure varies depending on the control panel in use and the programming software or application: 1. Access the control-panel programming section. 2. Select the device to be enrolled in accordance with its type: an input terminal, for a detector (motion detector, magnetic contact, etc.) an output terminal, for an output device connected to a terminal of the Air2-MC300 magnetic contact a keypad a sounder/flasher a key, for a remote control device, selecting as the associated reader the one simulated by the transceiver 3. Set the device as ‘Wireless’. 4. Start the learning phase from the control panel. 5. Press the ENROLL button on the wireless device. ... -
Page 9: Battery Replacement
3.2 Battery replacement Once the solution of the system to be designed [A] has been opened, in the right ‘Design’ tab [B], it is pos- sible to select an icon of the type of peripheral to be configured and drag it to the relevant part of the tree structure on the left [C]. Alternatively, you can double-click on the device icon to add it to the configuration. In the tree structure on the left, the number corresponding to the selected device type increases. To remove a component from the tree structure, select it and press CANC on the computer keyboard. Via keypad Enrolling of wireless devices is possible by enabling the menu options in the installer menu section: In this section it is possible to add the device to the configuration or delete it, by means of keys ‘ ’ and ‘ ’. As soon as the device is enabled it must be configured as ‘Wireless’: Once the OK button has been pressed, it is necessary to work through the menu options in order to enroll it. 3.2 Battery replacement When replacing the power supply batteries of the equipment, the installer must use only non-rechargeable lithium batteries compliant with IEC 60086-4 standard. In the case of battery replacement, it is advisable to press the ENROLL in order to ensure that the device is synchronized with the wireless transceiver. Air2-MC200 | © 2021 Inim Electronics S.r.l. -
Page 10: Programming Wireless Terminal
4. Programming wireless terminal 4. Programming wireless terminal The programming of a wireless terminal can only be done through the control panel programming software. On accessing the software, it is necessary to open a solution, configuration of the real system to be desi- gned. Successively a terminal previously configured or to be configured as ‘wireless’ must be selected. After which it will be possible to access the device programming in order to select or change the device type and its parameters. 4.1 Wireless terminal parameters Parameters and sensitivity Installer menu Software section Parameter section Wireless Terminals, "ter- The red LED on the device provides visual signalling of alarm or expansion, minal",Options, Use detector tamper conditions on the device itself. Selected ter- Use sensor LED minal, Wire- Bypass tamper This option disables open/dislodgement tamper signalling. -
Page 11: Real-Time
4.2 Real-time 4.2 Real-time For each configured device the software provides a direct software-to-device connection which allows visua- lization of the real-time values of the following features: The value read by each detector of the device is displayed on a bar which indicates the alarm threshold by means of a colour Reading level change from green to red. Signal reception This series of notches represents the reception level of the wireless signal of the device as received by the Air2-BS200 trans- level ceiver. Battery charge Percentage of the device battery charge. level RF analysis Function to monitor the variation of the signal transmitted by the device and the background noise detected through time. Air2-MC200 | © 2021 Inim Electronics S.r.l. -
Page 12: General Information
5.3 Notes from the Manufacturer The Air2 devices are certified by IMQ-Sistemi di sicurezza (Italian certification body). The information relating to the power-supply batteries required by Air2 devices is shown in the Technical Specification table that follows. The manufacturer cannot guarantee the declared battery life. Attention! Do not use batteries other than those indicated by the manufacturer as they may explode. 5.4 Simplified EU Declaration of Conformity Hereby, Inim Electronics S.r.l. declares that the radio equipment type Air2-MC200 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.inim.biz. Installation and programming manual- 102... -
Page 13: Warranty
Manuals may be downloaded free of charge from the web address www.inim.biz, getting access to the reser- ved area, after the login, and then to the section of each product. 5.8 Disposal of the product Informative notice regarding the disposal of electrical and electronic equipment (applicable in countries with differentiated waste collection systems) The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be disposed of correctly at the end of its working life and should never be disposed of together with gene- ral household waste. The user, therefore, must take the equipment that has reached the end of its working life to the appropriate civic amenities site designated to the differentiated collection of electrical and elec- tronic waste. As an alternative to the autonomous-management of electrical and electronic waste, you can hand over the equipment you wish to dispose of to a dealer when purchasing new equipment of the same type. You are also entitled to convey for disposal small electronic-waste products with dimensions of less than 25cm to the premises of electronic retail outlets with sales areas of at least 400m2, free of charge and without any obligation to buy. Appropriate differentiated waste collection for the subsequent recycling of the Air2-MC200 | © 2021 Inim Electronics S.r.l. - Page 14 5. General information discarded equipment, its treatment and its environmentally compatible disposal helps to avoid possible negative effects on the environment and on health and favours the re-use and/or recycling of the materials it is made of. Information about disposal of batteries and accumulators (applicable in Countries with sepa- rate collection systems) This marking on batteries and/or their manual and/or their packaging, indicates that batteries of this products, at the end of their working life, should not be disposed of as unsorted municipal waste, but must be object of a separate collection. Where marked, the chemical symbols Hg, Cd o Pb indicate that the bat- tery contains mercury, cadmium or lead above the reference levels of the directive 2006/66/EC. If batteries are not properly disposed of, these substances, together with other ones contained, can cause harm to human health and to the environment. To protect human health and the environment, to facilitate treatment and recycling of materials, separate batteries from other kind of waste and use the collection scheme stated in your area, in accordance to current laws. Before disposing of the above, it's appropriate to remove them from their holders avoiding to damage them or causing short circuits. Installation and programming manual- 102...
- Page 15 5.8 Disposal of the product Air2-MC200 | © 2021 Inim Electronics S.r.l.
- Page 16 Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz DCMIINE0A2MC2008E-102-20210526...
