- Page 1 EN 50131-1 EN 50131-2-6 EN 50131-5-3 EN 50130-4 EN 50130-5 Air2-MC400 Micro-magnetic contact Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Description of Air2-MC400 1.1 Description of parts 1.2 Magnet detection 1.3 Technical specifications of Air2-MC400 2. Installation of Air2-MC400 2.1 Configuring interference magnet sensitivity 2.2 Enrolling a wireless device 2.2.1 Enrolling wireless terminals 2.3 Battery replacement 3. Programming wireless terminal 3.1 Wireless terminal parameters 3.2 Real-time 4. General information 4.1 About this manual 4.2 Manufacturer's details 4.3 Simplified EU Declaration of Conformity 4.4 Warranty 4.5 Limited warranty 4.6 Documents for the users 4.7 Disposal of the product Installation and programming manual- 100... -
Page 3: Description Of Air2-Mc400
Level 3, high sensitivity (in compliance with the requirements of European standard EN50131-2-6 concerning the magnetic interference test). Warning It is recommended to set level “3” only in cases where high security is required. Package contents Air2-MC400 magnetic contact magnet 2 replacement magnet bases 5 wall plugs for mounting the backplate and tamper bracket double-sided adhesive tape battery (already in place) installation guide Air2-MC400 | © 2024 Inim Electronics S.r.l. -
Page 4: Description Of Parts
1. Description of Air2-MC400 1.1 Description of parts [A] [I] Box base Red LED [B] [J] Mounting screw hole Battery [C] [K] Tamper-screw location ENROLL button [D] [L] Closure tab Magnet alignment point [E] [M] Retainer locations Magnet - short side [F] [N] Box cover Magnet - long side [G] Closure hooks [H] Retaining screw location Installation and programming manual- 100... -
Page 5: Magnet Detection
Tamper protection/ENROLL button The microswitch functions both as a tamper signal and as an “Enroll” but- ton for enrolling the device. When the box is opened a tamper signal will be sent and the button will change its function to “Enroll” mode. During the enrolling phase you can then press the button or alternatively lightly shake the Air2-MC400 device. 5 seconds after closing the box the button will return to the anti-tamper function. 1.2 Magnet detection The magnetic sensor the device is equipped with detects the magnetic field in the surrounding space and its variations. The following tables show the operating distances in millimetres of the magnet based on the level of sens- itivity to the interference magnet, the side used and the axes shown in the figures (values o btained starting from a nominal distance of 1 mm, except for the x-axis for the short side and the y-axis for the long side): Short side Level 1 Level 2 or 3 Axis Withdrawn Near Withdrawn Near Air2-MC400 | © 2024 Inim Electronics S.r.l. -
Page 6: Technical Specifications Of Air2-Mc400
Level 2 or 3 Axis Withdrawn Near Withdrawn Near Note All the distances indicated above have a tolerance of +/- 2 mm. 1.3 Technical specifications of Air2-MC400 Battery Lithium CR2 3V type 4 years estimated life “Low battery” fault voltage Less than 2.4V Current draw 12µA... - Page 7 RF output power 25mW e.r.p. Communication type Two-way Modulation GFSK Device monitoring from 12 to 250 minutes Note In order to comply with the EN 50131-1 standards the alarm system supervision time must be below 120 minutes. Air2-MC400 | © 2024 Inim Electronics S.r.l.
-
Page 8: Installation Of Air2-Mc400
2. Installation of Air2-MC400 2. Installation of Air2-MC400 1. Choose a suitable mounting placement. Attention! Ferromagnetic materials which are located in the vicinity of the mounting position can influ- ence the magnetic field and can result in the reduced operating capacity of the device. - Page 9 Wireless signal reception level Immediately after enrolling and for the next 3 minutes or so, each time an alarm is generated, the device LED provides information on the level of the wireless signal: 2 flashes = low RF signal level 3 flashes = medium RF signal level 4 flashes = high RF signal level Note However, such indications are shown on the LED only if for programming the “Use sensor LED” option has been activated. Air2-MC400 | © 2024 Inim Electronics S.r.l.
-
Page 10: Configuring Interference Magnet Sensitivity
2. Installation of Air2-MC400 2.1 Configuring interference magnet sensitivity The following procedure can be carried out in order to set the interference magnet sensitivity level after installation. 1. Open the Air2-MC400 box. If previously enrolled, the device will signal opening to the control panel. 2. If necessary, carry out the device enrolling process by pressing the ENROLL button. Or alternatively lightly shake the Air2-MC400 device. 3. Close the box with the base placed in its final position. 4. Position the magnet in the required stand-by (at rest) position, in other words the position in which the device must not generate any alarm or tamper signal. The position can be considered suitable for detection if it has a distance from the magnetic contact that is less than the minimum operating distance (in accordance with the table “Operating distances of the magnet”). 5. The device LED will blink rapidly for 20 seconds, indicating access to the interference magnet sens- itivity setting phase. Carry out one of the following actions to set the desired sensitivity level at which a visual signal will occur. Sensitivity level Actions to be carried out Visual signalling Double or quadruple touch, without magnet... -
Page 11: Enrolling A Wireless Device
Add device on BUS button. A window opens where you can select the devices to be configured and add them to the configuration. In the section on the left you can increase the number using the button corresponding to the selected device type. To remove a device from the structure, work through the Add device procedure, but instead deselect the device you want to remove Alternatively, you can access the programming section by clicking on the relevant button on the menu on the left, and from the list that appears click on the Delete button that corresponds to the line of the device to be removed. Via keypad Enrolling of wireless devices is possible by enabling the menu options in the installer menu section: Type-in Code (Installer), PROGRAMMING Expansions, Enable/Disable In this section it is possible to add/remove readers from the configuration, by means of keys ‘ ’ and ‘ ’. Following this you need to declare the expansion as “Wireless” by declaring one of its terminals as “Wire- less”. 2.2.1 Enrolling wireless terminals 1. Go to the expansion board field and then to the terminal concerned. 2. Configure the terminal as “Wireless”: Air2-MC400 | © 2024 Inim Electronics S.r.l. -
Page 12: Battery Replacement
2. Installation of Air2-MC400 Via keypad Type in Code (Installer), PROGRAMMING Terminals, select the terminal concerned Press the number button “6”; the word “Wireless” will appear on the last line of the display (pressing the but- ton again will disable the wireless attribute on the terminal). Via software Right click on the expansion that was previously added to the configuration and select “Wireless” to configure it as such. The “Wireless” symbol will appear on the expansion image. Note If a terminal on the expansion board is configured as “wireless”, all the remaining terminals must be configured as “wireless”... -
Page 13: Programming Wireless Terminal
Zones, generic zone Zones, selec- ted zone, Alarm If this value is more than 1, you must also program the ‘Multi-pulse Device para- pulses time’ parameter. meters ‘gen- This parameter applies only when the ‘Alarm pulse num.’ is higher eric’ than 1. This is the window during which a number of alarm pulses must be detected (each lasting as long as the programmed ‘Alarm pulse dur- ation’) equal to the value programmed for ‘Alarm pulses’ in order for the system to generate an alarm. Multi-pulse time This time window can be expressed in seconds or minutes. This is the length of time (after detection of alarm conditions) the zone will allow before generating an alarm. Alarm pulse duration Expressed in multiples of 15 milliseconds or minutes. 3.2 Real-time For each configured device the software provides a direct software-to-device connection which allows visu- alization of the real-time values of the following features: Air2-MC400 | © 2024 Inim Electronics S.r.l. - Page 14 3. Programming wireless terminal Signal reception This series of notches represents the reception level of the wireless signal of the device as received by the Air2-BS200 level transceiver. Battery charge level Percentage of the device battery charge. RF analysis Function to monitor the variation of the signal transmitted by the device and the background noise detected through time. Such data can be reached through the ‘Real time’ section relating to the programming of each wireless device or through the ‘Monitoring’ section which provides an overview of all the devices connected to the control panel. Installation and programming manual- 100...
-
Page 15: General Information
Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.it Web: www.inim.it The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work only on devices marketed under the brand Inim Electronics. 4.3 Simplified EU Declaration of Conformity Hereby, Inim Electronics S.r.l. declares that the radio equipment type Air2-MC400 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.inim.it. 4.4 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation of performance of this product or actual damage that results from the use of products, parts or other repla- ceable items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental, including without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defec- tive products or otherwise arising from the incorrect or otherwise improper installation or use of this product. This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover damage arising from improper maintenance or negligence, damage caused by fire, flood, wind or lightning, vandalism, fair wear and tear. Air2-MC400 | © 2024 Inim Electronics S.r.l. -
Page 16: Limited Warranty
4. General information Inim Electronics S.r.l. shall, at its option, repair or replace any defective products. Improper use, that is, use for purposes other than those mentioned in this manual will void the warranty. Contact Our authorized dea- ler, or visit our website for further information regarding this warranty. 4.5 Limited warranty Inim Electronics S.r.l. shall not be liable to the purchaser or any other person for damage arising from impro- per storage, handling or use of this product. Installation of this Product must be carried out by qualified persons appointed by Inim Electronics. Instal- lation of this Product must be carried out in accordance with Our instructions in the product manual. 4.6 Documents for the users Declarations of Performance, Declarations of Conformity and Certificates concerning to Inim Electronics S.r.l. products may be downloaded free of charge from the web address www.inim.it, getting access to Extended Access and then selecting "Certifications" or requested to the e-mail address info@inim.it or requested by ordinary mail to the address shown in this document. Manuals may be downloaded free of charge from the web address www.inim.it, getting access to the reser- ved area, after the login, and then to the section of each product. 4.7 Disposal of the product Informative notice regarding the disposal of electrical and electronic equipment (applicable in countries with differentiated waste collection systems) The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be ... - Page 17 4.7 Disposal of the product Air2-MC400 | © 2024 Inim Electronics S.r.l.
