Vicon ANAVIO VA-CNR05A-512 Quick Install Manual

Corner camera
Hide thumbs

Advertisement

Quick Links

Download this manual
Quick Install Guide
Corner Camera
VA-CNR05A-512

Advertisement

loading
Need help?

Need help?

Do you have a question about the ANAVIO VA-CNR05A-512 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon ANAVIO VA-CNR05A-512

Summary of Contents for Vicon ANAVIO VA-CNR05A-512

  • Page 1 Quick Install Guide Corner Camera VA-CNR05A-512...
  • Page 2 WARNING • This camera operates at 12 VDC/24 VAC/PoE (IEEE 802.3af Class 3). • Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty. • We are NOT liable of any damage arising either directly or indirectly from inappropriate installation which is not depicted within this documentation.

  • Page 3: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT Information to the user: This unit has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PRODUCT OVERVIEW PHYSICAL CHARACTERISTICS INSTALLATION AND MOUNTING PACKAGE CONTENTS INSTALLATION CHECKING APPEARANCE CONNECTING THE CABLES INSTALLING THE CAMERA INTO A CORNER...

  • Page 5: Product Overview

    1 PRODUCT OVERVIEW PHYSICAL CHARACTERISTICS 2.4 (60) 8.2 (208) FIGURE 1-1: PHYSICAL DIMENSIONS [IN. (MM)]...
  • Page 6 Camera Top Cover Speaker Camera Module Bottom Case FIGURE 1-2: PARTS OUTER VIEW...
  • Page 7 FIGURE 1-3: PARTS INNER VIEW Default Button Power Terminal Press the button for 5 seconds to restore The port is used to connect with the camera settings to factory default. external 24 VAC/12 VDC power supply. Reset Button Alarm/Audio Inputs and Outputs Press the button for approximately DI/DO (Digital Input/Digital Output) ports 1 second to reboot the camera.

  • Page 8: Installation And Mounting

    2 INSTALLATION AND MOUNTING PACKAGE CONTENTS Ensure all items listed below are included in the packing box. • Camera (Qty 1) • Screw Cover Plugs (Qty 3) • Plastic Anchor (Qty 3) • T20 Torx Wrench (Qty 1) • T20 Torx Screw (Qty 3) •...

  • Page 9: Connecting The Cables

    CONNECTING THE CABLES 1. Remove the rubber plugs from the rubber grommet on the bottom case by pulling the tabs off to access the holes. Only remove plug from holes that will be used. Pull all cables through the cable holes of rubber grommet. FIGURE 2-1: CABLE ACCESS...
  • Page 10 2. Terminate the cables as required with the appropriate connectors. For power options: • PoE (Class 3): Connect an Ethernet cable terminated with an RJ-45 connector to the Ethernet port for both power supply and network connectivity. • 24 VAC: Connect 24 VAC power cable to the terminal block and connect to the 24 VAC power port.

  • Page 11: Installing The Camera Into A Corner

    INSTALLING THE CAMERA INTO A CORNER 1. Use the camera’s bottom case to mark the location for the three mounting holes. Drill three holes on the selected mounting surface. Insert three plastic anchors (provided) into the three holes. Mounting Holes FIGURE 2-3: MOUNTING HOLES...
  • Page 12 Align the three holes on the bottom case with the three holes on the wall and use the Torx wrench to fasten the three T20 Torx screws to securely affix the camera to the wall. FIGURE 2-4 CAMERA INSTALLATION 3. Insert the two desiccants into the top cover as shown on the figure above.
  • Page 13 Align the three holes on the camera top cover with the three holes on the camera module. FIGURE 2-5: INSTALLING THE CAMERA MODULE...
  • Page 14 Tighten the three captive Torx screws using the Torx wrench. FIGURE 2-6: INSERT AND FASTEN THE TORX SCREWS Insert the three rubber plugs into the three holes on the camera top cover to seal the screw holes. FIGURE 2-7: INSERT THE PLUGS...
  • Page 15 Vicon Industries Inc. does not warrant that the functions contained 24-Hour Technical Support: in this equipment will meet your requirements or that the operation 800-34-VICON (800-348-4266) will be entirely error free or perform precisely as described in the UK: 44/(0) 1489-566300 Toll Free: 800-645-9116 documentation.
