User Manual
Blackbody Temperature Calibrator for
V1110B-THM-TEMP Thermal Body Temperature
Measurement Camera
XX300-35-00
Vicon Industries Inc. does not warrant that the functions contained in this equipment
will meet your requirements or that the operation will be entirely error free or perform
precisely as described in the documentation. This system has not been designed to be
used in life-critical situations and must not be used for this purpose.
Document Number: 8009-8300-35-00 Product specifications
subject to change without notice. Issued: 6/2020
Copyright © 2020 Vicon Industries Inc. All rights reserved.
Vicon Industries Inc.
Tel: 631-952-2288
Fax: 631-951-2288
Toll Free: 800-645-9116
24-Hour Technical Support:
800-34-VICON (800-348-4266) UK:
44/(0) 1489-566300
www.vicon-security.com
Advertisement
Table of Contents
Related Manuals for Vicon V1110B-THM-TEMP
Summary of Contents for Vicon V1110B-THM-TEMP
- Page 1 Vicon Industries Inc. Tel: 631-952-2288 Fax: 631-951-2288 Vicon Industries Inc. does not warrant that the functions contained in this equipment Toll Free: 800-645-9116 will meet your requirements or that the operation will be entirely error free or perform 24-Hour Technical Support: precisely as described in the documentation.
-
Page 3: Precautions
Blackbody User Manual Precautions Precautions Precautions Read this document completely before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place. -
Page 4: Table Of Contents
Blackbody Precautions User Manual Contents Precautions ......................i 1 Overview .......................1 1.1 Introduction ......................1 1.2 Unpacking ........................ 1 1.3 Environmental Conditions ..................1 1.4 Safety Information ..................... 2 2 Device ........................3 3 Operation ......................7 3.1 Procedure ........................7 3.2 Set Temperature ......................8 3.3 Calibration ........................ - Page 5 Blackbody User Manual Precautions...
-
Page 7: Overview
Blackbody User Manual Overview 1 Overview 1.1 Introduction The precision Blackbody is used as a temperature calibrator for adjusting no-contact (point) IR thermometers or thermal imagers in the lab. The instrument’s features are: ⚫Temperature is accurately and stably controlled by intelligent temperature controller. -
Page 8: Safety Information
Blackbody Overview User Manual 1.4 Safety Information ⚫DO NOT use this Blackbody for any application other than calibration work. The Blackbody was designed for temperature calibration. Any other use of the Blackbody may cause unknown hazards to the user. ⚫This Blackbody is intended to operate at ambient temperature 32º F – 104 º F (0º... -
Page 9: Device
Blackbody User Manual Device Device Figure 2-1 shows the device. Figure 2-1 Appearance Mounting screw hole IR target surface... - Page 10 Blackbody Device User Manual Figure 2-2 Installation dimensions [in. (mm)]...
- Page 11 Blackbody User Manual Device...
- Page 12 Blackbody Device User Manual Figure 2-3 Operation screen Temperature controller Power switch Power socket Cooling Fan Table 2-1 Specifications Description Parameters 86º F – 122 º F (30º C - 50º C) Temperature range Target diameter 2.8 x 2.8 in. (72 × 72 mm) 0.018 º...
-
Page 13: Operation
Blackbody User Manual Operation Operation 3.1 Procedure Plug the power cord of the instrument into a mains outlet of the proper voltage, frequency, and current capability. 1 is the measured temperature (PV); displays in the upper window. 2 is the set temperature (SV); displays in the window below 1. 3 is the set button;... -
Page 14: Set Temperature
Blackbody User Manual Operation 3.2 Set Temperature Press ∧ or ∨ to directly adjust the set temperature. The numbers will flash after pressing the up or down button and will take effect after the flashing stops. You can quickly set the temperature value by pressing the data move button (4). 10-20 minutes after the setting is completed, it can be used when the "real-time temperature"... -
Page 15: Troubleshooting
Blackbody User Manual Troubleshooting Troubleshooting Table 4-1 Troubleshooting list Description Parameters Fuse break →Replace fuse No display Fan damage →Return to factory Fan does not work Noise →Add lubricant oil Heating wire burnout →Return to factory After setting SV value, PV value is not SV value is close to room temperature →Increase responding...
