Summary of Contents for Vicon ANAVIO VA-DFE12A-1TB

  • Page 1 Quick Install Guide Fisheye Camera VA-DFE12A-1TB...
  • Page 2 WARNING • This camera operates at 12 VDC/24 VAC/PoE+ (IEEE 802.3at Class 4). • Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty. • We are NOT liable of any damage arising either directly or indirectly from inappropriate installation which is not depicted within this documentation.
  • Page 3: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT Information to the user: This unit has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS PRODUCT OVERVIEW PHYSICAL CHARACTERISTICS INSTALLATION AND MOUNTING PACKAGE CONTENTS INSTALLATION CHECKING APPEARANCE MOUNTING THE CAMERA...
  • Page 5: Product Overview

    1. PRODUCT OVERVIEW PHYSICAL CHARACTERISTICS Ø5 (150) 1.9 (49.19) Ø5 (150) 2.3 (57.5) 2.1 (55.4) 5.6 (141.26) 1.6 (41.5) 0.6 (14.88) 1.6 (41.5) 1.6 (41.5) FIGURE 1-1: PHYSICAL DIMENSIONS [IN. (MM)]...
  • Page 6 FIGURE 1-2: OUTER VIEW PICTORIAL INDEX...
  • Page 7 Mounting Thread Hole Dome Cover With the standard female ¼-20, the hole is The upper dome-shape cover provides for attaching an additional bracket (sold protection. separately) for installation flexibility. Lens The proprietary fisheye lens provides wide Security Lock hemispheric view. The proprietary security lock design ensures camera is mounted securely onto Cabling Cutout...
  • Page 8 FIGURE 1-3: INNER VIEW PICTORIAL INDEX DI/DO Terminal Ports Default and Reset Button Connect to several external devices for Press the button for less than 1 second audio and alarm input/output functions. to reboot the camera; pressing for 6 seconds restores the camera to factory default settings.
  • Page 9 FIGURE 1-4: I/O PORT DEFINITIONS Function Port Audio In AU/I Audio Out AU/O Alarm In AL/I Alarm Out AL/O Power supply terminal/adaptor for IO connectors and field wiring should comply with the Class 2 Circuit standard for ensuring safety from electrical fires and providing acceptable protection against electrical shock.
  • Page 10: Installation And Mounting

    2. INSTALLATION AND MOUNTING PACKAGE CONTENTS Ensure all items listed below are included in the packing box. • Fisheye Camera (Qty 1) • Flat Bracket (Qty 1) • Safety Wire (Qty 1) • Plastic Anchor (Qty 4) • Tapping Screws (Qty 4) •...
  • Page 11: Mounting The Camera

    MOUNTING THE CAMERA Attach the supplied guide pattern to a mounting surface. Drill 4 relative holes on a clean flat surface (ceiling or wall) and insert 4 plastic anchors into the drilled holes. The correct size holes for TP4 screws with plastic anchors are Ǿ6.35 mm (0.25 in.) NOTE: Seal up waterproof hole with plug when no cable is in...
  • Page 12 Rubber Plug Waterproof Grommet FIGURE 2-1: MOUNTING THE CAMERA Feed the unterminated CAT5 cable through the hole in the solid grommet and terminate the cable with the appropriate connector. To maintain watertight integrity/warranty, be sure to use the appropriate NOTE: grommet.
  • Page 13 Security Lock After mounting the camera onto the flat bracket, bolt the security lock by fastening the security screw counterclockwise, so that camera will be mounted to bracket securely. To disassemble camera from flat bracket, loosen the security screw clockwise. Security Lock Security Screw FIGURE 2-2: SECURITY LOCK SETTLEMENT...
  • Page 14 Safety Wire Preparation In order to prevent the camera from accidentally falling, connect the included safety wire with one end on the mounted bracket and the other end to the safety-wire screw on the camera. Fasten the metal-circle end of wire with the safety-wire screw onto the rear side of camera and attach the other wire end to the hook of mounted bracket.
  • Page 15 24-Hour Technical Support: Vicon Industries Inc. does not warrant that the functions contained 800-34-VICON (800-348-4266) in this equipment will meet your requirements or that the operation UK: 44/(0) 1489-566300 will be entirely error free or perform precisely as described in the Toll Free: 800-645-9116 documentation.
