ALTAI A660-X Quick Setup Manual

Tri-radio wi-fi 6 mesh access point
Hide thumbs

Advertisement

Quick Links

Download this manual
Altai A660-X Tri-Radio
Wi-Fi 6 Mesh Access Point
________________________________________________
Quick Setup Guide
Version 1.0
Altai Technologies Ltd. All rights reserved
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the A660-X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ALTAI A660-X

Summary of Contents for ALTAI A660-X

  • Page 1 Altai A660-X Tri-Radio Wi-Fi 6 Mesh Access Point ________________________________________________ Quick Setup Guide Version 1.0 Altai Technologies Ltd. All rights reserved...

  • Page 2: Package Contents

    Quick Setup Guide Introduction Thank you for purchasing the Altai A660-X product. This guide provides instructions to install the product and set it up in AP mode with minimal effort. Package Contents Mounting Bracket A660-X Main Unit x 1 Wall Mount Anchor x 4...

  • Page 3: Hardware Overview

    Quick Setup Guide Hardware Overview Front View Back View 2.4G Top View Bottom View Left Side View Right Side View Altai Technologies Ltd. All rights reserved...
  • Page 4 Used for AP chassis grounding. Attach a ground wire of size 10 AWG (not included) to the chassis with a ground screw. Connect the other end of the wire to a reliable ground point on site for earthing. Altai Technologies Ltd. All rights reserved...
  • Page 5 SFP link connected Flashing Green Data transmitting/receiving via SFP LAN (Ethernet) disconnected LAN connected with ETH0 Green 10/100/1000/2500Mbps of Ethernet speed Flashing Green Data transmitting/receiving Green System bootup and ready to operate Green System power up Altai Technologies Ltd. All rights reserved...
  • Page 6 Console: It can be used for maintenance purpose. Connect RJ45 to UART console. WPS: Press the button to perform automatic connection between Access Point and Mesh Node. H: USB Connect external add-on device via USB port. Altai Technologies Ltd. All rights reserved...
  • Page 7 • A PoE injector (purchased separately) and a power cord; alternatively, an 802.3bt-compliant PoE switch to power up the A660-X Power Options and Cable Connection Instructions Follow one of the options below to power up the A660-X for configuration. Option 1: 802.3bt-Compliant PoE Switch 802.3bt – Compliant PoE Switch 1.
  • Page 8 AC Outlet Injector 1. Connect the PoE injector’s ports as follows with Ethernet cables. - PoE Port: To the A660-X - LAN Port: To a computer 2. Connect the PoE injector to the AC power socket using a power cord.
  • Page 9 For Windows 7/Windows 10/Windows 11 users, 1. Go to Control Panel, click Network and Sharing Center and then choose the Ethernet adapter that is in connection with the A660-X unit. Click it and then click Properties. 2. Under the Networking tab, select Internet Protocol Version 4 (TCP/IPv4) in the list box “This connection uses the following items”, and then click...
  • Page 10 Type 192.168.1.222 in the address bar and then hit Enter. 2. The login page will come up. Enter the default username and password as follows: • Username: admin • Password: admin 3. Click Login. Altai Technologies Ltd. All rights reserved...
  • Page 11 2.4G radio configuration only. The same procedures apply to 5G radio configuration. 1. Check the box to Enable Radio. Select AP for the Radio Mode. Then click Submit button. Altai Technologies Ltd. All rights reserved...
  • Page 12 2. Click the WLAN tab on the navigation bar. Check the box to Enable WLAN 0. Enter the SSID to name the wireless network you want to advertise, e.g. Altai A660-X. To secure a Wi-Fi network, you can use WPA2/WPA3 Personal or WPA2/WPA3 Enterprise. For simplicity, select WPA2/WPA3 Personal for Auth Mode and enter a string of 8-64 characters long for Passphrase.
  • Page 13 Follow the steps below to register your APs. 1. Go to Configuration > Network > General. Select Switch Mode for Network Setting. Make sure the A660-X can reach the Internet and communicate with AltaiCare by setting valid IP configuration via DHCP or with static IP configuration.
  • Page 14 5. Follow AltaiCare Quick Start Guide to register the A660-X in the cloud system. 6. The A660-X will come up online in AltaiCare if the connection is successful. Altai Technologies Ltd. All rights reserved...
  • Page 15 European Conformity (CE) – EU This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Altai Technologies Ltd. All rights reserved...
  • Page 16 Warning A660-X may require professional installation depending on the deployment scenario. Only use the optional power adaptor available for A660-X. Using a different power adaptor might damage the device. The metal chassis of the equipment may be hot. Pay special attention or use special protection before handling this equipment.
