20130115_rev1.1_A2_Configuration_Manual_-_1.0.6.48.doc
Altai A2 WiFi Access Point/Bridge
Configuration Manual
for

Firmware Version 1.0.6.48

Version 1.1
Date: December 17, 2012
Commercially Confidential
1
