*15G065280001AK*
P/N: 15G065280001AK V1.1
Quick Installation Guide
D1749NTD4U-4Q / D1749NTD4U-4T4O
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before installing server board components or change any
server board settings.
1.
Unplug the power cord from the wall socket before touching any components.
2.
To avoid damaging the server board's components due to static electricity, NEVER place the
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before handling the components.
3.
Hold components by the edges and do not touch the ICs.
4.
Whenever uninstall any component, place it on a grounded anti-static pad or in the bag that
comes with the component.
5.
When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2
Motherboard Layout
UID1
PSU_SMB1
USB 3.2
IPMI
Gen1
T: USB2
LAN
B: USB1
SFP28_2
SFP28_0
SFP28_1
SFP28_3
D1749NTD4U-4T4O only
LAN4
LAN3
D1749NTD4U-4T4O
only
X557-AT4
D1749NTD4U-4T4O only
LAN1
LAN2
PCIE7
PCIE6
41
40
39
IPMB1
FRONT_LED_LAN1
Dr.Debug
BMC
TPM1
ROM
38
3
I/O Panel
2
1
3
No. Description
1
UID Switch (UID1)
2
COM Port (COM1)
3
VGA Port (VGA)
4
LAN RJ-45 Port (IPMI_LAN)
5
USB 3.2 Gen1 Ports (USB3_1_2)
6
10/25G SFP28 (Fiber) (SFP28_2)
7
10/25G SFP28 (Fiber) (SFP28_0)
1
2
3
BATTERY1
FRNT_VGA1
SATAPWR1
CPU_SINK1
D1749NTD4U-4Q
D1749NTD4U-4T4O
NMI_BTN1
BMC_SMB1
RAID_1
HSBP1
PECI1
ME_RECOVERY1
1
1
1
1
37
36
35
34
33
32
4
6
8
5
7
9
No. Description
8
10/25G SFP28 (Fiber) (SFP28_3)
9
10/25G SFP28 (Fiber) (SFP28_1)
10
10G LAN RJ-45 Port (LAN4)
11
10G LAN RJ-45 Port (LAN3)
12
10G LAN RJ-45 Port (LAN2)
13
10G LAN RJ-45 Port (LAN1)
1
Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
5
4
24.4cm (9.6 in)
ATX12V1
ATX12V2
FAN5
FAN6
MSAS_HD0
MSAS_HD1
NUT_M2_1_80
NUT_M2_1_110
BIOS
ROM
MSAS_HD2
USB3_3_4
TPM_BIOS_PH1
AUX_PANEL1
CLRMOS1
SATA0
SATA1
SATA2
1
31
30
29
28
27
26
25
10
12
11
13
(D1749NTD4U-4T4O only)
(D1749NTD4U-4T4O only)
(D1749NTD4U-4T4O only)
(D1749NTD4U-4T4O only)
www.asrockrack.com
6
No.
Description
1
PSU SMBus (PSU_SMB1)
2
Front VGA Header (FRNT_VGA1)
SATA Power Connector (DC-IN Mode)
3
(SATAPWR1)
ATX4PIN1
4
ATX 12V Power Connector (ATX12V1)
5
ATX 12V Power Connector (ATX12V2)
DDR4_B1
6
Micro-Fit Power Connector (ATX4PIN1)
7
DDR4_B2
2 x 288-pin DDR4 DIMM Slots
7
8
DDR4_A1
(DDR4_A1, DDR4_B1)
2 x 288-pin DDR4 DIMM Slots
DDR4_A2
9
8
(DDR4_A2, DDR4_B2)
10
9
System Fan Connector (FAN5)
FAN2
11
FAN3
10
System Fan Connector (FAN2)
12
FAN4
11
System Fan Connector (FAN3)
13
FAN1
14
12
System Fan Connector (FAN4)
PWM_CFG1
1
15
13
CPU Fan Connector (FAN1)
14
System Fan Connector (FAN6)
SLIM1
16
15
PWM Configuration Header (PWM_CFG1)
SLIM2
16
Slimline NVMe Connector (SLIM1)
17
17
Slimline NVMe Connector (SLIM2)
18
MINI-SAS HD Connector (MSAS_HD0)
18
19
MINI-SAS HD Connector (MSAS_HD1)
20
MINI-SAS HD Connector (MSAS_HD2)
19
21
TPM-SPI Header (TPM_BIOS_PH1)
20
22
SATA SGPIO Connector (SATA_SGPIO3)
21
23
SATA3 Connector (SATA3)
PANEL1
SATA_SGPIO3
22
SATA3
24
System Panel Header (PANEL1)
25
SATA3 Connector (SATA2)
26
Clear CMOS Jumper (CLRMOS1)
24
23
27
SATA3 Connector (SATA1)
28
SATA3 Connector (SATA0)
29
Auxiliary Panel Header (AUX_PANEL1)
30
USB 3.2 Gen1 Header (USB3_3_4)
31
ME Recovery Jumper (ME_RECOVERY1)
Backplane PCI Express Hot-Plug Connector
32
(HSBP1)
33
Virtual RAID On CPU Header (RAID_1)
34
BMC SMB Header (BMC_SMB1)
35
Non Maskable Interrupt Button (NMI_BTN1)
36
CPU PECI Mode Jumper (PECI1)
Front LAN LED Connector
37
(FRONT_LED_LAN1)
38
External 80 Port Debug Header (TPM1)
Intelligent Platform Management Bus Header
39
(IPMB1)
40
M.2 Socket (M2_2) (Type 2280/22110)
41
M.2 Socket (M2_1) (Type 2280/22110)
D1749NTD4U-4Q
D1749NTD4U-4T4O
