EXCELA Installation Instructions
■ EXCELA
○ Basin unit
P1-EX** [1 Tap Type]
PT-EX** [Thermostat Type]
KF-EX*S** [S size]
KF-EX*** [Others]
KF-EX*
● The precautions listed here are to ensure that EXCELA can be installed safely, and to prevent any danger or risk to the person installing
EXCELA or those around them. All of these precautions are important for safety. Takara Belmont is not responsible for any damage or
risk to the person installing EXCELA or those around them due to accidents if EXCELA is install without adhering to the precautions.
Caution :
If EXCELA is installed after ignoring this symbol, "there is the risk of light or moderate injury or physical damage".
■ Option
○ Side Panel
KF-EXSP**
○ Mirror
KF-EXM800
○ Auto Neck Cushion
KF-NC
(Image is of 1 set of
P1-EX**/KF-EX3S*R/KF-EX3S*L/KF-EX380/KF-EX1200 )
To the installer:
● The instructions should be thoroughly read and understood
before installation to ensure that EXCELA is installed correctly.
● After installation, give this instructions to the customer.
To the customers:
● Customers must not install EXCELA by themselves.
● Customer must store these instructions in a safe place so as
not to lose them.
*The actual shape of EXCELA and the images and dimensions
listed in these instructions may be modified and are subject to
change without notice.
Contents
Before Installation
Name of Parts
Usage conditions
EXCELA packing
Carrying the basin unit
Version 1
2
4
7
8
9
9
10
11
12
13
14
14
15
16
17
18
19
19
20
2024.11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXCELA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Takara Belmont EXCELA

Summary of Contents for Takara Belmont EXCELA

  • Page 1: Table Of Contents

    ● The precautions listed here are to ensure that EXCELA can be installed safely, and to prevent any danger or risk to the person installing EXCELA or those around them. All of these precautions are important for safety. Takara Belmont is not responsible for any damage or risk to the person installing EXCELA or those around them due to accidents if EXCELA is install without adhering to the precautions.

  • Page 2: Before Installation

    Before Installation Overall layout diagram <Dimensional drawing> Basin unit: P1-EX** Platform: KF-EX380, KF-EX1200 Cabinet: KF-EX3S*R [3 door cabinet, right side] Mirror side panel: KF-EXSP*580 (Option) Cabinet: KF-EX3S*L[3 door cabinet, left side] Mirror: KF-EXM800 (Option) ■Top view Mirror Panel 580 Mirror Panel 580 (S size) Mirror Panel 580 Basin unit center Basin unit center...

  • Page 3: Side View

    1250 1450 model.Ensure that there is space between main 3: Bowl center to bowl center 1200 1300 1250 1450 unit and side wall, specially when installing EXCELA to the wall at both ends. 4: Total width 2800 2850 2900 3050...

  • Page 4: Name Of Parts

    Name of Parts ■Main Unit < 1 tap type (Picture shows 1 set) > ■Bowl (Temperature/Tap) Shower head holder Mirror (Option) Shower head Shampoo bottle Side pillar Shampoo Side Panel bowl (Option) Bottle holder Basin unit counter Control (Temperature panel /Tap) Neck Cabinet...
  • Page 5 < Piping diagram > ■Top view 125 75 L-shaped joint T-shaped joint Hot water supply: RC 1/2”(H=120) ■Front view Water supply: RC 1/2”(H=120) Bowl center Bowl center Drain: VU40 (H=120) 1200(*1) 125 75 1200(*1) ■Side view *Dimension differs from spec. of cabinet (S size, 450 size, L size, LL size). S size 450 size L size...
  • Page 6 ■ Floor surface ○ Ensure that the material or finishing of the floor surface is waterproof or has a waterproof coating applied. ○ Always ensure that the floor surface is horizontally level. ○ Ensure that the floor surface is smooth and free from bumps around the attachment areas. ○...

  • Page 7: Usage Conditions

    Hot water supply, ● Use a pressure set between 0.1 to 0.4 MPa (1 to 4 kgf/cm ). If multiple EXCELA water supply pressure are used, ensure that the pressure does not drop below 0.1 MPa (1 kgf/cm ●...

  • Page 8: Content Of Packaging

    EXCELA packing < Basin unit > ■ Accessories ■ Content of packaging □ Bottles (3) □ Operating manual, □ Basin unit wall installation manual fixing screw set (this document) □ Nozzle for replacement (3) □ Flexible pipe □ Nozzle packing (3) □...

  • Page 9: Installation Of Main Body

    Carrying the basin unit ■Carrying the platform ○Recommend to carry platform by 2 people as it is wide. Caution The platform is made of steel, so dragging it may damage the floor surface. Or strong shock may cause damage to the platform. ■Carrying the basin unit (Hold the basin unit back side handle and the bowl handle and carry the basin unit.) ○Do not take off...

  • Page 10: Install The Platform

    Install the platform 1. Install the platform (1) After removing protective tape on top and base part of the Connection platform, fix the platform by connection board. Pay board attention to the direction of the connection board. 2 pcs. of connection board and 6 pcs. of M4 x 10 screws to be used for each joint.

  • Page 11: Install The Cabinet (Left (Wall Side))

    Install the cabinet (left (wall side)) 1. Unpack the equipment *Check the spec. of the cabinet, if it is right or left side cabinet. To the left side, install left side cabinet. ■ Always have two people to do this operation. (1) Unpack the bottom part of the carton.

  • Page 12: Install The Basin Unit (First)

    Install the basin unit (first) ■Installation 1. Install the basin unit (1) Carry the unit by holding the basin unit back side handle and bowl handle,and place bowl unit on platform tentatively. Caution ●Do not drag bowl unit when carrying basin unit.It may cause damage on the floor surface or wall.

  • Page 13: Install The Cabinet (Center)

    (5) Attach cap on screw. *The cap is to conceal the screw head. (6)Put cabinet drawer in the cabinet and close the door. Washer Tapping screw Install the cabinet (center) 1. Install the cabinet (center) Caution Washer(φ5) ● When carrying cabinet, do not drag it. It may damage floor surface or cabinet.

  • Page 14: Install The Basin Unit (Second)

    Install the basin unit (second) 1. Install the basin unit (1) Hold the basin body back side handle and the bowl handle, and carry the basin unit. And place basin unit on platform tentatively. Caution ● Do not drag it while carrying basin unit. It may cause scratches on floor or basin unit,or it may cause damage to the bowl.

  • Page 15: Fix Basin Unit And Cabinet To Wall

    Fix basin unit and cabinet to wall Caution When removing drawer (3 door type), do not put drawer on the cabinet counter.It may cause scratch on the counter. Place soft cloth or blanket on the floor and put the drawer on it. Be careful not to lose any screws. 1.

  • Page 16: Attach Piping

    < Thermostat type > Caution Check valve with strainer ● Always attach the supplied packing. Using EXCELA without installing the supplied packing may cause water leaks. ● Do not connect the hot water supply pipe and water supply pipe in reverse.

  • Page 17: Checks After Installation Of Pipes

    Checks after installation of pipes 1. Test water flow Caution Always test the water flow to prevent accidents during use. * Test the water flow and inspect the following items. The hot water may be slightly tainted at the start of the water flow test,however this does not indicate any problem.

  • Page 18: Adjust And Remove/Attach Door

    Adjust and remove/attach door ■Position of attaching door ○Confirm if the door (front and back, right and left, tilt,up and down) is attached properly If the door is not attached properly, adjust it by the following process. *There are two adjustment points, upper and lower, on each door. Please adjust at both of them. Caution Loose screws may cause the door to drop or fall off.

  • Page 19: After Installation

    After installation Caution Always conduct the following inspections to prevent accidents during use. ■Inspection items (basin unit) ■Inspection items (cabinet) (1) Are there any screws that have not been (1) Are there any screws that have not been attached? attached? (2) Is there any rattling? (2) Is there any rattling? Check the attachment areas (screws) again if there...

  • Page 20: Attach Optional Parts

    Attach optional parts ■ Attach neck cushion (Option) Auto neck cushion 1. Remove dust, dirt, oil and so on from the Bowl side shampoo bowl attachment part and Suction cap suction cap. And wipe moisture from the shampoo bowl. 2. Confirm the direction of neck cushion as shown in the picture.
