SOSTA BED
PLATFORM & LEGS
ASSEMBLY GUIDE
PARTS
Included with Platform
Included with Full-size Included with Leg Purchase
Note
the "L"
(2x) End
D
E
(2x) Left Leg
(2x) Right Leg
+
G
(8x) 1.6"
Support
Hex Screw
Rib
Included with Full-size
C
Leg Purchase
+
(2x) Slat Roll
A
(2x) Side
I
J
F
Support
(2x) 1.2"
(12x) Phillips Screw
(6x) Phillips Screw
Leg
Hex Screw
INCLUDED TOOLS
REQUIRED
OR
4mm Hex
Hex
Phillips
Phillips
Power
Wrench
Bit
Bit
Screwdriver
Drill
Advertisement
Related Manuals for Sprout SOSTA
Summary of Contents for Sprout SOSTA
- Page 1 SOSTA BED PLATFORM & LEGS ASSEMBLY GUIDE PARTS Included with Platform Included with Full-size Included with Leg Purchase Note the “L” (2x) End (2x) Left Leg (2x) Right Leg (8x) 1.6” Support Hex Screw Included with Full-size Leg Purchase (2x) Slat Roll...
- Page 3 Full ASSEMBLY VIDEO Enjoy the best assembly experience sprout-kids.com/sosta/assembly If using a drill, set clutch on drill to LOW SETTING (around 3). If your drill has two speeds, set it to the SLOW SPEED (1). A high clutch setting will strip screw heads and render parts useless! CLUTCH TOO HIGH: If the drill twists dramatically in your hand when drilling.
- Page 4 Starting with one End , fully insert tabs of Sides into slots on Ends until ush. Repeat with other End OPTIONAL: A rubber mallet can help push pieces together. A hammer can also be used with a scrap piece of wood or a cutting board placed over the surface being hammered for protection.
- Page 5 ADDING LEGS If you didn’t purchase legs, proceed to Flip frame onto its side. Slide Left Leg d and Right Leg e into the left & right sides of Siderail a . Note the engraven “L” When adding legs, ensure they point away from the center of the bed.
- Page 6 Screw the (4x) 1.6” Hex Screws into the Legs until tight . Be careful to use the appropriate clutch setting per Step 1. Flip the frame around, and repeat Steps 6-7 with the other (2) Legs. Set frame upright.
- Page 7 ADDING RIB & SUPPORT LEG If you purchased a twin bed, skip to Line up the hole on each end of the Support Rib H with the hole in the center of each End B . Screw through the top of each End B and into the Support Rib H using a Phillips Screw F for each end.
- Page 8 ADDING SLAT ROLLS With webbing face up, align the Slat Roll holes with the Holes in Side as you lay one of the Slat Rolls onto one half of the bed frame. Insert the tips of (2x) Phillips Screws through the Slat Roll holes and vertically into the holes of Side...
- Page 9 Screw the (2x) Phillips Screws into the holes on the side of the Slat Roll near the middle of the bed. Set the tips of the additional (2x) Phillips Screws through the other Slat Roll holes and screw them into the holes of Side...
- Page 10 Repeat steps 11-14 to attach remaining Slat Roll FULL-SIZE SLAT ROLLS If you purchased a twin bed, skip to After completing steps 11-15, screw (4x) Phillip Screws F into the remaining holes along the middle of the Slat Rolls C .
- Page 11 12” away from any wall. Those under the age of 3 may be at greater risk. MUST BE GREATER THAN 12” For additional Safety Regulations and Standards: sprout-kids.com/fb/safety If you have questions, reach out to support@sprout-kids.com...
- Page 12 WWW.SPROUT-KIDS.COM SPROUT 2025 PO BOX 1123, PROVO, UT 84601 DOCUMENT: AI-SBT-Platform&Legs...
