(2x)
A
Side
(2x)
B
End
(2x)
C
Slat Roll
INCLUDED TOOLS
4mm Hex
Hex
Wrench
SOSTA BED
PLATFORM & LEGS
ASSEMBLY GUIDE
PARTS
Included if you purchased legs
(2x)
Left Leg
Phillips Screw
Phillips
Bit
Bit
Note
the "L"
D
Right Leg
(12x)
F
1.6" Hex Screw
REQUIRED
OR
Phillips
Screwdriver
(2x)
E
(8x)
G
Power
Drill
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sprout SOSTA BED PLATFORM & LEGS
Summary of Contents for Sprout SOSTA BED PLATFORM & LEGS
- Page 1 SOSTA BED PLATFORM & LEGS ASSEMBLY GUIDE PARTS (2x) Side Included if you purchased legs Note (2x) the “L” (2x) (2x) Left Leg Right Leg (12x) (8x) (2x) 1.6” Hex Screw Slat Roll Phillips Screw INCLUDED TOOLS REQUIRED 4mm Hex Phillips Phillips Power...
- Page 2 ASSEMBLY VIDEO Enjoy the best assembly experience sprout-kids.com/platform Lay out (2x) Sides and (2x) Ends as shown. Starting with one End , fully insert tabs of Sides into slots on Ends until ush. Repeat with other End OPTIONAL: A rubber mallet can help push pieces together.
- Page 3 ADDING LEGS If you didn’t purchase legs, proceed to Flip frame over. If using a drill, set clutch on drill to LOW SETTING (around 3). If your drill has two speeds, set it to the SLOW SPEED (1). A high clutch setting will strip screw heads and render parts useless! CLUTCH TOO HIGH: If the drill twists dramatically in your hand when drilling.
- Page 4 Slide the (2x) Left Legs into Sides at opposite corners as shown. Note the engraven “L” When adding legs, ensure they point away from the center of the bed.
- Page 5 Screw the (4x) 1.6” Hex Screws in the (2x) Left Legs Repeat steps 6 - 7 with the (2x) Right Legs Flip frame over.
- Page 6 ADDING SLAT ROLLS With webbing face up, align the Slat Roll holes with the Holes in Side as you lay one of the Slat Rolls onto one half of the bed frame. Insert the tips of (2x) Phillips Screws through the Slat Roll holes and vertically into the holes of Side...
- Page 7 Screw the (2x) Phillips Screws into the holes on the side of the Slat Roll near the middle of the bed. Set the tips of the additional (2x) Phillips Screws through the other Slat Roll holes and screw them into the holes of Side...
- Page 8 12” away from any wall. Those under the age of 3 may be at greater risk. MUST BE GREATER THAN 12” For additional Safety Regulations and Standards: sprout-kids.com/sosta/safety If you have questions, reach out to support@sprout-kids.com WWW.SPROUT-KIDS.COM QUARK ENTERPRISES 2022 PO BOX 1123, PROVO, UT 84601 DOCUMENT: AI-SBT-Platform&Legs...
