- Page 1 Simple. Modern. American Made. Single Row Lockers Adult assembly only 2 Adults required for assembly Assemble completely before use...
- Page 2 A hammer can also be used with a scrap piece of wood or a cutting board placed over the surface being hammered for protection. PAGE 2 OF 8 QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. LK-6030-5x1...
- Page 3 Peg. Wipe o excess glue Insert Peg into slot on each door. with a damp cloth. Ensure to apply glue just before connecting parts together. GLUE PAGE 3 OF 8 DOCUMENT: AI-LK-5x1 WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022...
- Page 4 Hinge Clips are on the front-left. Top should be oriented with slots for Back in the back. HINGE CLIPS ON FRONT-LEFT TABS FOR BACK IN BACK PAGE 4 OF 8 QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. LK-6030-5x1...
- Page 5 With the help of another adult, carefully tilt assembly onto Back D . Push down on each corner to lock into place. When fully tightened, the edges should be ush. PAGE 5 OF 8 DOCUMENT: AI-LK-5x1 WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022...
- Page 6 Insert Shelf Pins N into holes at the desired height and rest Shelf J on Pins. Each locker should have (2) Shelves, and each Shelf will use (4) Pins. PAGE 6 OF 8 QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. LK-6030-5x1...
- Page 7 Locker Side Once in position, push the Hinge Q lever and rotate Hinge ush with the Locker Side until Hinge is locked into Hinge Clip P . Locker Side PAGE 7 OF 8 DOCUMENT: AI-LK-5x1 WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022...
- Page 8 To take Door H o push on lever and rotate Hinge Q to release it from Hinge Clip P . Locker Side Adjust Door H to align ush with outer edges of unit using the Adjustment Screws as shown below. ADJ.
