Sprout SFS30 Quick Start Manual

PARTS

A
(1) Back
B
(4) Horizontal Divider
C D
(29) Slot Divider (5) Vertical Divider
E
(1) Top
F
(1) Middle Shelf
G
(1) Bottom
H
(1) Toe
I J
(1) Left Side (1) Right Side
K
(2) Assembly Jig
QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601

BEFORE YOU START

Orient tabs so the side with the wider lip faces
*
the same direction as the notch in the slot.
WIDE LIP
NOTCH
SLOT TAB
NARROW LIP NARROW LIP
Place tab into open slot then lock tabs into the
*
notch as pictured below.
TAB
SLOT TAB LOCKED INTO SLOT
When fully tightened, the edges should be ush.
A rubber mallet can help push pieces together. A
hammer can also be used with a scrap piece of
wood or a cutting board placed over the surface
being hammered to protect it.

ASSEMBLY INSTRUCTIONS

D
Place Vertical Dividers D into slots of Horizontal
1
B
Dividers B , as shown.
D
B
MODEL NO. SFS30
H
Push tabs on Toe H into slots on Bottom G , then
2
tighten per * . *
Insert tabs of assembled Vertical and Horizontal
3
D B
Dividers D and B into slots of Right Side J , as
shown. Make sure Vertical Divider tabs are towards
front of unit.
B
D
SLOT FOR BACK
J
G
4
Place tabs for Bottom G and Middle Shelf F in slots
J
of Right Side J , as shown. Large slots on Middle
Shelf should be towards front of unit. Insert tabs of
Dividers into slots on Bottom and Middle Shelf, and
G
tighten Bottom G slightly.
F
G
J
DOCUMENT: AI-SFS30 WWW.SPROUT-KIDS.COM
G
Simple. Modern. American Made.
J
30-CUBBY
STUDENT FOLIO
STORAGE
TAB TOWARDS
FRONT
Adult assembly only
Assemble completely
before use
2 people recommended
for assembly
FRONT
T
RIGHT SIDE
TOP VIEW
F
Frustrated?
STOP
Need Help?
LARGE SLOTS
TOWARDS FRONT
Talk to our customer
service agent at:
+1 (833) 530-0033
Or watch our assembly
video at:
sprout-kids.com/sfs
COPYRIGHT QUARK ENTERPRISES 2021
