  • Page 1 BUILDING CONTROLS FOR DEDICATED EQUIPMENT MODELS: AGZ-D, AGZ-E, AMZ, AWS, AWV, WCC, WDC. WMC, WME GEN 1, WME-C, WSC, DAH, DFSA, DPS, DPSA, MPS, RAH, RDS, RDT, RFS, RPS, SWT, AND SWP LEARN MORE AT DAIKINAPPLIED.COM ©2025 DAIKIN APPLIED | (800) 432.1342...

  • Page 2: Table Of Contents

    ©2025 Daikin Applied, Minneapolis, MN. All rights reserved throughout the world.This document contains the most current product information as of this printing. Daikin Applied Americas Inc. has the right to change the information, design, and construction of the product represented within the document without prior notice.

  • Page 3: Safety Information

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his or her own expense. Daikin disclaims any liability resulting from any interference or for the correction thereof.

  • Page 4: Introduction

    NOTICE MicroTech II Chiller models WCC, WDC, WMC and WSC must have the latest version of HMI Touchscreen hardware, which uses either an Axiomtek or a Siemens touchscreen PC. Update kits are available through Daikin Applied Service offices. DAIKIN APPLIED...

  • Page 5: Siteline Gateway Kit Primary Components

    INTRODUCTION SiteLine Gateway Kit Primary Power Supply Components For most applications, the SiteLine Modem can be powered using 24VDC available within the unit control panel. A power cable is included for this purpose. In cases where the modem must be CAUTION located remotely, a 110VAC to 24VDC plug-in power supply is Extreme temperature hazard can cause damage to components.

  • Page 6: Installation

    WARNING Sharp edges on sheet metal and fasteners can cause personal injury. This equipment must be installed, operated, and serviced only by an experienced installation company and fully trained personnel. DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 7 INSTALLATION Figure 1: Component Locations - AGZ D/E Small Panel CAUTION To avoid damaging wires or components, verify clearance in and around the point of penetration prior to any drilling During any drilling, ensure that resultant metal shavings are not allowed to contact unit electronics.
  • Page 8 INSTALLATION Figure 5: Component Locations – AWV Large Panel Figure 7: Typical AWS Large Panel Layout Figure 8: Typical WMC Unit Control Panel Layout Figure 6: Component Locations – AWS Small Panel DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 9 INSTALLATION Figure 9: Typical WSC, WDC, and WCC Unit Control Panel Figure 11: Typical AMZ Control Panel Layout Layout Figure 12: SiteLine Gateway with Mounting Flange Figure 10: Typical WME Gen 1 Unit Control Panel Layout WWW.DAIKINAPPLIED.COM IM 1398...

  • Page 10: Installing Power Supply

    Next, drill pilot holes, through the marks just created. Finally, attach the power supply to the backplane using two of the sheet metal screws provided in the hardware packet. Figure 13: Power Supply DAIKIN APPLIED SITELINE BUILDING CONTROLS...

  • Page 11: Wiring

    HMI touchscreen hardware, which uses either an Axiomtek or a be cut-to-fit and placed over the lower voltage rated cables and conductors to Siemens touchscreen PC. Update kits are available through Daikin Applied increase their rating to 600V.

  • Page 12: Connection Of Power Supply

    Block Adapter and tighten. Once both connections are secure, insert the DC Terminal Block Adapter into the “DC IN” port on the SiteLine Gateway, then turn it 1/4 turn clockwise to lock the adapter in place (Figure 19). DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 13 INSTALLATION Figure 20: AGZ-D and AGZ-E 120VAC Wiring Figure 21: AWV and AWS 120VAC Wiring WWW.DAIKINAPPLIED.COM IM 1398...
  • Page 14 INSTALLATION Figure 22: WMC 120VAC Wiring Figure 23: WSC, WDC, and WCC 120VAC Wiring DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 15 INSTALLATION Figure 24: WME Gen 1 120VAC Wiring Figure 25: AMZ 120VAC Wiring WWW.DAIKINAPPLIED.COM IM 1398...
  • Page 16 Ethernet LAN, see document section titled, “SiteLine Gateway Ethernet LAN Configuration.” NOTICE The SiteLine Gateway will not communicate with the cloud if the Ethernet cable is connected to the incorrect port on the gateway. DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 17 INSTALLATION Figure 28: The ‘Operator’ Icon Figure 29: The ‘API Server Enable’ Field on the HMI WWW.DAIKINAPPLIED.COM IM 1398...

  • Page 18: Field-Installed Siteline Modem On Chillers

    A and B. 2 . Temporarily connect the provided plug-in power supply to location D on the modem (this will later be replaced with direct wiring to a power source within the control panel). DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 19 INSTALLATION Mount/Install SiteLine Modem NOTICE The +24VDC conductor has red shrink-wrap For chiller model WME-C, the modem can be mounted on top of the unit control panel using the provided hook-and-loop mounting NOTICE squares to secure it in place (Figure 33).
  • Page 20 If the statuses are not reading as expected after the additional 30 minutes, or if the SiteLine parameters are not present on the HMI, contact the Daikin Applied Controls Support Group at CTLTechSupport@ daikinapplied.com or (800) 432-1342.

  • Page 21: Ethernet Configuration

    INSTALLATION (Settings tab) of the Interface screen (Figure Figure 42: WAN/LAN Switch Selected Figure 40: SiteLine Parameters on HMI Figure 41: Chiller Serial Number 8 . This completes configuration of the SiteLine Modem and 3 . Change the Interface Mode dropdown from WAN to LAN, Chiller HMI for cellular applications.

  • Page 22: Field-Installed Siteline Gateway On Aah

    5 inches of clearance between all cables and conductors with 300V-rated insulation or less and areas of the control enclosure containing higher voltage components and conductors, such as 575V. DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 23 INSTALLATION Figure 46: MPS Bracket Mounting Location Figure 48: Roofpak Mounting Location Figure 47: DPSA Mounting Location Figure 49: SWP Control Enclosure Example (460V, 6-Compressor Unit) WWW.DAIKINAPPLIED.COM IM 1398...

  • Page 24: Wire Routing

    The antenna provided with the kit (Figure 57) is omnidirectional containing higher voltage components and conductors. If 300V or and has two coaxial leads. Install the antenna on top of the lower rated cables and conductors cannot be practically isolated DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 25 INSTALLATION unit with enough clearance from the edge to avoid accidental Figure 53: Rebel Applied Cabinet Knockouts contact or damage and avoiding interference from structures. The antenna is held in place by its magnetic base. Once installed, route the antenna cables through the conduit bushings into the control panel.
  • Page 26 Discharge any static electrical charge by touching the bare metal inside the control panel before performing any service work. Never unplug cables, circuit board terminal blocks, or power plugs while power is applied to the panel. DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 27 INSTALLATION Connection of Power Supply Neutral (blue) conductor to terminal TB1A-5, 6, 7, 8, or 9 (Figure 64). On a SWP or SWT unit, connect the Line (brown) conductor NOTICE to terminal TB1A-1, 2, 3, or 4, and the Neutral (blue) conductor to terminal TB1A-5, 6, 7, or 8 (Figure 65).
  • Page 28 INSTALLATION Figure 62: Typical Maverick II 120VAC Wiring Figure 63: Typical Rebel Applied 120VAC Wiring Figure 64: Typical RoofPak Unit 120VAC Wiring Figure 65: Typical SWP and SWT Unit 120VAC Wiring DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 29 INSTALLATION SiteLine Gateway Connection to Antennas Prior to Commissioning Gateway As described previously, the antenna cables must be fed from the Before commissioning the gateway, it is important to know the outside of the unit through the control enclosure to the SiteLine expected LED Behavior.
  • Page 30 The SiteLine Gateway should only be configured for Ethernet LAN connectivity if certain that Ethernet LAN was specified at the time of order. If unsure, contact the salesperson or Daikin Applied Controls Technical Response Center. Prior to configuring the M2M Gateway for Ethernet LAN, please refer to the Appendix of this document for required IT information.
  • Page 31 INSTALLATION Figure 68: Online Commissioning Tool Login Figure 69: SiteLine Gateway Serial Number Entered WWW.DAIKINAPPLIED.COM IM 1398...
  • Page 32 INSTALLATION Figure 70: SiteLine Gateway Record Located Figure 71: Commissioning Tool Confirming Gateway Operation DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 33 INSTALLATION Figure 72: SiteLine Gateway Confirmed as Operational Figure 73: Change Network Settings Screen WWW.DAIKINAPPLIED.COM IM 1398...
  • Page 34 INSTALLATION Figure 74: Ethernet Addressing Entered Figure 75: Unit Setup Screen – Diagnostics Passed DAIKIN APPLIED SITELINE BUILDING CONTROLS...
  • Page 35 INSTALLATION Figure 76: Equipment Serial Number Entered Figure 77: Gateway Power Prompt WWW.DAIKINAPPLIED.COM IM 1398...

  • Page 36: Commissioning The Siteline Gateway Or Siteline

    Login (Figure 78). If you have not been given access to the unit Gateway, please contact Daikin Applied. Once logged in, the user interface displays a building list and map of all assigned units (Figure 79).
  • Page 37 INSTALLATION Figure 80: Buildings List Figure 81: Unit List Figure 82: Unit Details WWW.DAIKINAPPLIED.COM IM 1398...
  • Page 38 INSTALLATION Figure 83: Thirty Day Message Figure 84: Commissioning Procedures Screen DAIKIN APPLIED SITELINE BUILDING CONTROLS...

  • Page 39: Troubleshooting

    • Verify power at the unit terminal board • Check for LED activity on SiteLine Gateway’s ‘ETH2’ port • Verify power supply wires are properly installed to unit • Contact Daikin Applied terminal block • Verify power supply is properly connected to the SiteLine...

  • Page 40: Appendix

    • iedata.daikinapplied.com on port 3199 • 52 .176 .101 .12 • 192 .168 .1 .40 • 192 .168 .1 .42 • 192 .168 .1 .220 • 192 .168 .1 .45 • 192 .168 .1 .132 DAIKIN APPLIED SITELINE BUILDING CONTROLS...
