Installation Manual
Daikin System Manager
Quick Start Guide
Use with Daikin Intelligent Systems
Installer Responsibilities
The installation of this equipment shall be in accordance
with the regulations of authorities having jurisdiction and all
applicable codes. It is the responsibility of the installer to
determine and follow the applicable codes.
Receiving Inspection
When the device is received, all items should be carefully
checked against the bill of lading to be sure all packages
have been received.
Inspect the system manager for any shipping damage.
Report all shipping damage to the carrier and file a claim.
Figure 1: Included Items
A.
B.
™
Included Items
A. System Manager
B. 15.6" touch screen monitor
C. System Manager display bracket
D. 4 × screws and 4 × 10mm standoffs for VESA
E. Cables – VGA male to male plug, USB type A to type B
F. 120AC-12VDC adapter with screw lug power
Required Tools
• Screwdriver
• Controls screwdriver
C.
D.
©2017 Daikin Applied | (800) 432–1342 | www.DaikinApplied.com
IM 1255-1
Group: Controls
Part Number: IM 1255
Date: February 2017
mounting
connector
**Wall-mounting screws and anchors are not included
E.
F.
