Summary of Contents for Daikin Shinka
- Page 1 SHINKA CONTROLLER User interface quick guide www.daikinapplied.eu...
- Page 2 Safety Information and General Warnings Improper installation, operation, or maintenance of this device may result in property damage, serious injury, or installation. Warnings Electrical Hazard result in electric shock, injury or death. licensed electrician or HVAC technician. Improper installation could damage the unit or connected systems. Wear protective equipment and use insulated tools to avoid electrical hazards.
-
Page 3: Content Of The Box
Rear panel with terminal blocks (Figure 2) Quick guide The Shinka user interface must be combined with the fan coil control PCB (FWEDA) for proper operation of the Daikin control system. Technical Data Display LCD TFT RGB 480x272, 16bit, 4.3”... -
Page 4: Installation
Ensure that the Shinka controller is compatible with the existing fan coil system. Check the voltage and connections indicated in the device's installation and operation manual. Mounting Methods: The Shinka fan coil controller can be installed in two ways, directly on the wall or by integrating it into an electrical junction box (product not included). - Page 5 2. Mounting with Electrical Box (not supplied) Mounting with electrical box is suitable for walls that already have a standard junction box (Figure 4 for box 503 and Figure 5 for box 502). This mode allows for secure and stable attachment when an electrical box is present. Align the base plate of the device with the holes in the electrical box, making sure it is perfectly centered and horizontal.
- Page 6 The system language The full brightness of the display The date and time otherwise it can be done in a guided way through the same user interface, following the instructions on the screen. Download the Daikin Shinka Manager Mobile App coil units).
- Page 7 Once every Unit Composition has been completed for each fan coil unit within a Zone, it is possible to proceed with For any additional and more comprehensive information, please refer to the Shinka Controller Installation and Operation Manual available on the Daikin Applied Europe website or contact your local Daikin representative.
