- Page 1 Shadings Collection Dual Shade System Installation Instructions 24-0025-092 January 2025...
-
Page 2: Table Of Contents
Cordless Only: Install Pull Tassels (Optional) ...................11 STEP 4: Connect the Power Source, If Applicable .................12 Testing the Shading ...........................15 OPERATION ............................16 Operate the Shading ..........................16 Operating the LEVOLOR PREMIER App and Remote ..............18 ® ™ Resetting the Shading (If Necessary) ....................19 TROUBLESHOOTING ........................ -
Page 3: Getting Started
GETTING STARTED Product View Optional Dust Cover (For Outside Mount) Optional Back Cover (For Inside Mount) Installation Brackets Headrail Cordless Rear Roller Shade Front Shading Shading Bottom Rail Roller Shade Bottom Rail Handle Battery Wand Programming Button Cord Loop Cord Loop Cord Tensioner Cord Tensioner Front Shading... -
Page 4: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing the LEVOLOR ® PREMIER ™ Shadings Collection. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. If your shading has a protective cover on the fabric-covered headrail, keep the plastic in place until the shading is installed. -
Page 5: Installation
INSTALLATION INSTALLATION Installation Overview To install your shading, you will need to perform the following four steps: STEP 1: Mount the Installation Brackets STEP 2: Automated Smart Shades Only: Mount the Battery Wand (If Applicable) STEP 3: Install the Shading STEP 4: Automated Smart Shades Only: Connect the Power Source, If Applicable STEP 1: Mount the Installation Brackets The number of installation brackets required varies with shading width, as shown in the table. -
Page 6: Mount The Installation Brackets - Inside Mount
INSTALLATION INSTALLATION Mount the Installation Brackets — Inside Mount Back Cover Bracket Top Tab Prepare the Installation Brackets The purpose of the back cover bracket is to provide clearance for the battery wand for ■ Back Cover Automated Smart shadings. Slots Bottom Tab NOTE: Back cover is not available with Dual Shade system. -
Page 7: Mount The Installation Brackets - Outside Mount
INSTALLATION INSTALLATION Center the installation brackets on your marks and mark the location of the screw holes. ■ Jamb Allow sufficient rear clearance when positioning the brackets. ➤ NOTE: Rear clearance is the distance between the back of the installation Nearest bracket and the glass or frame. - Page 8 INSTALLATION INSTALLATION Use a ⁄ " drill bit to drill holes for the mounting screws. ■ CAUTION: Use drywall anchors when mounting into drywall. If no additional clearance is required, attach the installation brackets directly to the mounting ■ surface using the screws provided. IMPORTANT: The front edged of the installation brackets must be level and aligned to each other.
-
Page 9: Remove The Shipping Clip And Foam On Rail
INSTALLATION INSTALLATION Remove the Shipping Clip and Foam on Rail Shipping clips are used to stabilize the back panel bottom rail during shipping. Remove the Top of the Clip Grasp the headrail with one hand and hold the shipping clip with the other hand. ■... -
Page 10: Step 2: Smart Shade Automated Smart Shades Only: Mount The Battery Wand, If Applicable
INSTALLATION INSTALLATION STEP 2: Automated Smart Shades Only: Mount the Battery Wand, if Applicable For headrail-mounted battery wand and rechargeable battery wand, battery wand clips and battery wand/rechargeable battery wand mount are installed before the shading is installed. Any other power options, the power source will be connected after the shading is installed. - Page 11 INSTALLATION INSTALLATION Headrail-Mounted Rechargeable Battery Wand Install the Rechargeable Battery Wand Clips Rechargeable Front of Attach the battery wand clips to the headrail. Battery Wand Clip ■ Headrail Hook the battery wand clips onto the back channel of the ■ headrail.
-
Page 12: Step 3: Install The Shading
Center the dust cover over the top of the shading, above the previously placed dots. ■ Press the dust cover down onto the dots ■ Dust Cover Installed Attach the cord tensioner according to the Universal Cord Tensioner Installation Instructions on levolor.com/premier. ■... -
Page 13: Cordless Only: Install Pull Tassels (Optional)
INSTALLATION INSTALLATION Cordless Only: Install Pull Tassels (Optional) Pull tassels may be installed on the handles for the front shading and rear roller shade. The procedure is shown below on the shading handle. The roller shade handle looks different, but the installation procedure is the same. Rotate the bottom rail so that you can see the underside of the handle. -
Page 14: Step 4: Connect The Power Source, If Applicable
For an optional headrail-mounted rechargeable battery wand, see page 13. ➤ For an optional satellite-mounted rechargeable battery wand, see page 13. ➤ For an optional 18V DC Power Supply, see page 14. ➤ For any other LEVOLOR PREMIER power supplies, see applicable instructions. ® ™ ➤... - Page 15 INSTALLATION INSTALLATION Headrail-Mounted Rechargeable Battery Wand Insert the Rechargeable Battery Wand into the Battery Mount NOTE: The rechargeable battery wand ships fully charged, so it is ready to install out of the package. Match the direction of the arrow on the underside of the battery wand with the arrow on the battery mount. ■...
- Page 16 INSTALLATION INSTALLATION Install the Battery Wand into the Battery Mount NOTE: The rechargeable battery wand ships fully charged, so it is ready to install out of the package. Match the direction of the arrow on the underside of the battery wand with the arrow on the battery mount. ■...
-
Page 17: Control Button
If the bottom rail is not level or the shading starts to rub against either window jamb, immediately press the control button to stop the shading. See “Adjust the bottom rail weight (not applicable for Cordless shadings). See below.” on page 23. The control button can also be used in combination with the LEVOLOR ®... -
Page 18: Operation
INSTALLATION OPERATION Operate the Shading Whatever the operating system, the front shading and back roller shade are operated independently of each other. Shown below are a few examples of possible shading and shade positions. Shading lowered with vanes Shading lowered with vanes Shading lowered with vanes open, roller shade lowered open, roller shade partly raised... - Page 19 INSTALLATION OPERATION Cordless Control IMPORTANT: With cordless operating systems, the front shading must be raised before the back roller shade can be operated. Slowly and steadily pull down on the bottom rail handle to lower the shading or ■ roller shade. Front shading only: With your thumb on the front of the handle and fingers on the ■...
-
Page 20: Operating The Levolor Premier App And Remote
Further Operation and Programming Information LEVOLOR PREMIER App The LEVOLOR PREMIER App is required to program Automated Smart shades, remotes, and gateways. The App is compatible with Apple® and Android™ smartphones and tablets. For more information regarding setup and operation using the LEVOLOR PREMIER App, refer to levolor.com/premier. -
Page 21: Resetting The Shading (If Necessary)
The LEVOLOR PREMIER App may be used to modify or reset any shade programming to remotes and gateways. Shades may be added to or removed from Rooms in the App at any time. If necessary, shades may also be deleted from the LEVOLOR PREMIER App in the Advanced Options section of the Shade Settings menu. -
Page 22: Troubleshooting
TROUBLESHOOTING Troubleshooting If your shading is not operating correctly: With Automated Smart Shades shadings, first review the remote support documents at levolor.com/premier. ■ Refer to the following troubleshooting procedures for specific solutions for your shading. ■ For questions, please contact LEVOLOR PREMIER at 1-800-478-1538. - Page 23 IMPORTANT: A shade will not operate until it is joined to a group. Check that the correct group number is selected. The LED on that group number will light up. You can also check which group number the shade is joined to on the remote in the LEVOLOR PREMIER App.
- Page 24 TROUBLESHOOTING Problem Automated Smart Shades only: Rechargeable battery needs recharging (continued). Solution Recharging Via the Single Charger Remove the rechargeable battery wand from the mount, or insert the single charger cable without removing from the shading. Attach the plug adapter to the charger. ■...
- Page 25 Solution Pull down on the spring to relieve tension and pull the universal cord tensioner to the bottom of the cord loop. Properly mount the cord tensioner. See the Universal Cord Tensioner Installation Instructions on levolor.com/premier. Problem The shading raises or lowers evenly, the fabric rubs against one end of the headrail, or the bottom rail is uneven when fully raised.
- Page 26 TROUBLESHOOTING Problem Automated Smart Shades only: The bottom rail on the shade or shading does not raise or lower completely, or its location when fully lowered has changed over time. Solution The batteries may be low in the battery wand or satellite battery pack. Replace the batteries. Check that the power source is securely connected to the power cable and the cables are not pinched or caught in the headrail or installation brackets.
-
Page 27: Care
CAUTION: Be very careful not to tear or damage the fabric. Carefully pull the shading to remove it from the brackets. ■ Cleaning Procedures LEVOLOR PREMIER Shadings are made of 100% polyester, which means they are inherently durable and resilient. However, care ®... -
Page 28: Declarations
CE and UKCA Compliance Statement LEVOLOR PREMIER, One Duette Way, Broomfield, CO 80020, USA Hunter Douglas hereby declares that the PV33 is in compliance with the essential requirements and other relevant provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU and Radio Equipment Directive (RED) 2014/53/EU. -
Page 29: Child Safety
INSTALLATION CHILD SAFETY WARNING ADVERTENCIA Products with a Damaged, Productos con un Dispositivo Loose, or Missing Tension Tensor Dañado, Suelto o Device Pose a Strangulation Austente Presentan un Riesgo Risk to Children. de Estrangulatmiento Para los Niños. This Window Blind is equipped with a Tension Device Esta Persiana está... -
Page 30: Year Limited Warranty
• LEVOLOR PREMIER motorization components reinstallation. are covered for 5 years from the date of purchase. LEVOLOR PREMIER (or its licensed fabricator/distributor) will repair or replace the product or components found to be defective. TO OBTAIN WARRANTY SERVICE: • Contact your original dealer (place of purchase) for warranty assistance.
