Congratulations on the purchase of your new pressure washer. In
order to ensure you have the best possible experience, please read
through the following instructions. If you require any help, please
contact the customer service department at:
1-866-474-6664
Contact us for assistance; we're here to help.
3000 PSI / 2.4 GPM
PRESSURE WASHER
MODEL: XG06 / 039-8088-4
Use and Care Guide
IMPORTANT SAFETY
INSTRUCTIONS: SAVE THESE
INSTRUCTIONS
Version. 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XG06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simoniz XG06

Summary of Contents for Simoniz XG06

  • Page 1 3000 PSI / 2.4 GPM PRESSURE WASHER MODEL: XG06 / 039-8088-4 Use and Care Guide Congratulations on the purchase of your new pressure washer. In IMPORTANT SAFETY order to ensure you have the best possible experience, please read INSTRUCTIONS: SAVE THESE through the following instructions.

  • Page 2: Table Of Contents

    Table of Contents 1. Important Precautions ............... 3 1.1 Definitions ............................3 1.2 Safety Warnings ..........................3 2. Intended Applications ................. 7 3. Exploded View ................... 8 4. Parts List ................... 8 5. Assembly Instructions ................ 9 5.1 Surface Preparation ........................9 5.2 Water Supply (Cold Water Only) ....................

  • Page 3: Important Precautions

    MODEL : XG06 / 039-8088-4 Important Precautions 1. Important Precautions FLAMMABLE AND COMBUSTIBLE MATERIALS IMPORTANT, RETAIN FOR FUTURE REFERENCE AND READ CAREFULLY! Alerts against the presence of materials/gases which can be extremely flammable. Do not attempt to install or operate this device until you have read the safety instructions in this manual.
  • Page 4 1. Important Precautions CAUTION — HOT ENGINE AND MUFFLER 1.2 Safety Warnings THE ENGINE AND MUFFLER BECOME VERY HOT DURING AND AFTER USE. DANGER — WORK AREA SAFETY AVOID TOUCHING THE ENGINE OR THE AND EXHAUST FUMES MUFFLER DURING OR AFTER USE. •...
  • Page 5 MODEL : XG06 / 039-8088-4 1. Important Precautions CAUTION–ENGINE SAFETY 1.2 Safety Warnings • Certain components in this product and its related accessories contain chemicals which are known to FLAMMABLE AND POISONOUS cause cancer, birth defects, or other reproductive MATERIALS harm.
  • Page 6 Important Precautions 1. Important Precautions 1.2 Safety Warnings CAUTION — WATER CONNECTIONS • For use with fresh and clean water only. Do not use this product with other liquids. CAUTION — SPECIFIC SAFETY • The water supply system must be protected against backflow.

  • Page 7: Caution - Service

    For questions regarding other uses, please refer to misalignment or binding of moving parts, breakage our website at www.simoniz.ca or call us at 1-866-474-6664. of parts and other conditions that may affect the product’s operation. If damaged, have the product repaired before use.

  • Page 8: Exploded View

    3. Exploded View 4. Parts List Item # Part Name Qty. Part # Part Name Diagram Qty. Project Tips (x5) 1 set XG06-050-0003 Quick-connect Wand XG03-020-0002 Spark Plug Wrench Gun Assembly UG01-020-0003 Pressure Hose XG02-050-0004 Engine Oil Funnel Wheel Set VE30-050-0000...

  • Page 9: Assembly Instructions

    MODEL : XG06 / 039-8088-4 Assembly Instructions 5. Assembly Instructions 5.4 Assembly 5.1 Surface Preparation Before beginning any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture.
  • Page 10 Assembly Instructions Assembly Instructions 5. Assembly Instructions Attach the gun holder. Connect the garden hose to the pump inlet and the water supply respectively, then turn the water on. Connect the pressure hose to the pump outlet and the gun connector respectively.
  • Page 11 MODEL : XG06 / 039-8088-4 Assembly Instructions 5. Assembly Instructions Release the safety trigger if it is locked. PURGING 0˚ 15˚ 25˚ 40˚ Detergent To install tip, gently slide the collar back before inserting it, then release the collar to lock the tip.

  • Page 12: Engine Operation

    Engine Operation 6. Engine Operation 6.1 Adding/Checking Oil TIP: When adding oil use provided oil funnel. IMPORTANT Oil has been drained for shipping. Failure to fill engine with oil before starting engine will result in permanent damage and will void engine warranty. Add oil according to the instructions.

  • Page 13: Adding Fuel

    MODEL : XG06 / 039-8088-4 Engine Operation 6. Engine Operation 6.2 Adding Fuel 6.3 Checking Air Filter WARNING • Make sure there is enough fuel in the fuel tank before operating the pressure washer. • Use only clean, fresh, unleaded fuel. Use a minimum of 87 octane/87 AKI (91 RON).

  • Page 14: Starting Engine

    Engine Operation 6. Engine Operation 6.4 Starting Engine 1. Set the engine I/O switch to ON (I) position. 2. Move the throttle control to LEFT position. 3. Move the fuel valve to RIGHT position 4. Move the choke lever to LEFT position. 5.

  • Page 15: Stopping Engine

    MODEL : XG06 / 039-8088-4 Engine Operation 6. Engine Operation 6.5 Stopping Engine 3. Set the engine I/O switch to OFF (O) position. 1. To stop the engine move the choke lever to the LEFT position. IMPORTANT Restarting the engine after running it for over 5 minutes, place the choke lever to RIGHT position to restart the engine.

  • Page 16: Working With Detergent

    Do not use powdered soaps, which would clog the injection system. Follow the detergent manufacturer’s directions or call the Simoniz® toll-free number at 1-866-4SIMONIZ (1-866- 474-6664) if you have any questions or concerns. Engage the safety lock on the spray gun.

  • Page 17: Shutting Down And Cleaning Up

    MODEL : XG06 / 039-8088-4 Engine Operation 6. Operating Instructions 6.7 Shutting Down and Cleaning Up Turn off water supply and disconnect the CAUTION garden hose from the water inlet on the pressure washer. Failure to clean this product properly will cause the...

  • Page 18: Cleaning And Maintenance

    Cleaning and Maintenance 7. Cleaning and Maintenance 7.3 Engine Maintenance 7.1 Cleaning the Spray Tips Draining Engine Oil CAUTION The engine oil should be replaced after the first 20 hours of operation, or after the first month of use. After that, it should Clogging of the spray tip increases the water pressure be replaced every 100 hours or every 6 months.

  • Page 19: Short Term Storing

    MODEL : XG06 / 039-8088-4 Cleaning and Maintenance 7. Cleaning and Maintenance 7.4 Short Term Storing 7.3 Engine Maintenance (cont.) Store idle product out of the reach of children and do 2. Using provided spark plug wrench, remove the spark plug not allow persons unfamiliar with the product or these by turning it counter-clockwise.

  • Page 20: Winterizing And Long-Term Storage

    Winterizing 7. Cleaning and Maintenance 8. Winterizing and Long-Term Storage 7.5 Long Term Storing (cont.) 8.1 Optimum Winterizing Procedure 3. Drain Oil Winterizing your pressure washer will help protect and prolong its life. We strongly recommend you follow the below a.

  • Page 21: Technical Specifications

    MODEL : XG06 / 039-8088-4 Technical Specifications 9. Technical Specifications Peak Pressure: 3000 PSI Rated Max. Pressure: 2700 PSI Rated Water Flow: 2.4 GPM (9.0 LPM) Minimum Inlet Pressure: 30 PSI Maximum Inlet Pressure: 100 PSI Pump Type: Heavy-duty maintenance-free axial...

  • Page 22: Troubleshooting

    Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution The engine power switch is in the OFF (0) position. Ensure the switch is in the ON (I) position. No fuel. Fill the fuel tank with regular gasoline. Low oil shut down sensor tripped to protect engine.
  • Page 23 MODEL : XG06 / 039-8088-4 Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution Connect detergent siphon tube properly. Refer to the instruc- The detergent siphon tube is not connected. tion manual.

  • Page 24: Warranty

    The warranty is void if the equipment is used for commercial, rental or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-474-6664. Made in China...

  • Page 25: Icon Definitions

    MODEL : XG06 / 039-8088-4 Icons Definitions 12. Icon Definitions Hearing Protection This Way Up To protect hearing from the device noise, When handling product, arrows must always wear hearing protection while operating the point up. device. Store Indoors Stacking Limitation To avoid damage from freezing, store indoors Shows maximum stacking height, in units.
  • Page 26 Notes...
  • Page 27 MODEL : XG06 / 039-8088-4 Notes...
  • Page 28 IMPORTANT SAFETY INSTRUCTIONS: 3000 PSI / 2.4 GPM SAVE THESE INSTRUCTIONS PRESSURE WASHER MODEL: XG06 / 039-8088-4 Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8...
